- Page 1 Shor-Pet Grooming Table P R O D U C T G U I D E Save This Guide For Future Reference PN: 006.3230.00 MAY 2021...
- Page 2 INTRODUCTION INTRODUCTION Introduction Thank you for purchasing Shor-Line products. As a leader in animal care equipment, our commitment to provide quality products and personable customer service is the same as it was in 1927. This Guide provides information regarding the installation, use, and care of your Shor-Line product.
-
Page 3: Table Of Contents
Lift Table Safe Use Practices .................... 10 Lift Function ........................11 General Maintenance & Care ................... 12 Maintenance Recommendations ................12 Care Recommendations .................... 12 SECTION FOUR, TERMS & CONDITIONS Terms And Conditions ..................13 Damaged Freight Procedures ..................13 Limited Warranty ..................14 Contact Information ..................15 Shor-Line.com... -
Page 4: General Information
Refer to the Guide, images and content to assist with the installation of the product. Throughout the Guide, safety notices provide help for a successful installation. SAFETY FIRST! Shor-Line uses the following symbols and signal words to identify potential hazards or unsafe practices: Safety Alert Symbol Indicates a potential personal injury hazard exists. -
Page 5: Safety Warnings Included In This Guide
Steel parts may have sharp edges, stay clear of and DO NOT TOUCH exposed edges which, if not avoided, could result in MINOR to MODERATE INJURY. NOTICE When not in use, store the table in its closed position and unplug the unit. Shor-Line.com... -
Page 6: Safety Decal Locations
SAFETY DECAL, Warning - Proposition 65 Read all warning, danger and caution decals before equipment is operated. Never use equipment if decals are missing, hidden, improperly placed, damaged or altered. Keep safety decals clean and legible. Contact Shor-Line (800.444.1579) for replacement safety decals. Shor-Line.com... -
Page 7: Section One, Pre-Assembly
While verifying the shipment contents, take a moment to inspect each component for damage. This should be done before the shipment is signed received and accepted. If damaged components are apparent, follow the instructions within Shor-Line’s Damage and Freight Procedures. -
Page 8: Component Parts List
Hydraulic Lift Actuator (pedal) 062.3715.20 Leveling Foot Screw 051.0000.00 Leveling Foot Scuff Pad 803.3221.08 Fixed Grooming Arm Assembly (Not Shown) Optional Accessory 140.0001.32 Grooming Loop (Not Shown) Optional Accessory Contact Shor-Line for table model and finish options at (800.444.1579) Shor-Line.com... -
Page 9: Section Two, Assembly Procedures Installation
STEP 2: Thread the leveling screws (feet) into the bottom of the frame. Leave 1/2" of screw threading exposed. See FIGURE 2.2 LEVELING FEET STEP 3: Slip a scuff pad over each leveling foot. FIGURE 2.2 - Adjustable Leveling Feet Shor-Line.com... - Page 10 FIGURE 2.4 - Fixed Arm Bracket to help aid in the scuff ball installation. STEP 4: Follow the adjustable arm procedures to complete the installation of the fixed grooming arm, lower slide stop pin and the scuff ball. Shor-Line.com...
- Page 11 FIGURE 2.7 - Lower Slide Stop Pin Component Replacement If the hydraulic actuator replacement is required: Installation and repair of table components must be performed by a qualified contractor. Failure to comply will result in a void of Shor- Line warranties. Shor-Line.com...
- Page 12 SECTION TWO Maintenance Notes Shor-Line.com...
-
Page 13: Section Three, Use And Care
Keep personnel and animals clear of the foot operated lift control pedal, unintentional table functions (movement) could occur. Failure to do so could result in SERIOUS INJURY or DEATH. NOTICE When not in use, store the table in its closed position and unplug the unit. Shor-Line.com... -
Page 14: Lift Function
FIGURE 3.1 - Hydraulic Lift Do NOT exceed the weight limitations (250 lbs) of the table. Exceeding the weight limit NOTICE may cause equipment failure. When not in use, store the grooming table in the down position. Shor-Line.com... -
Page 15: General Maintenance & Care
Shor-Line Technical Services for direction. Do NOT attempt to repair hydraulic leaks. Care Recommendations NOTICE Routine product care will extend the quality and life of Shor-Line products and aids in protecting animals from transmittable diseases and infections. It is the owners responsibility to set-up scheduled cleaning programs, depending on use of the equipment. -
Page 16: Section Four, Terms & Conditions
Shor-Line. If products are damaged, defective, shorted or appear not to conform to the order, Customer shall discontinue their use and immediately notify the carrier and Shor-Line of such condition and afford a reasonable opportunity to inspect the same. -
Page 17: Limited Warranty
SECTION FOUR Limited Warranty In the event the Customer is not fully satisfied with the quality or workmanship of a product, Shor-Line in its sole discretion may arrange either to credit Customer's account (excluding shipping and handling costs) or replace the product. -
Page 18: Contact Information
Vale of Glamorgan CF71 7PF Kansas City, Kansas 66105, USA United Kingdom PHONE: 800.444.1579 PHONE: +44 1446 77 20 41 LOCAL: 913.281.1500 FAX: +44 1446 77 36 68 FAX: 913.281.5339 EMAIL: quality@shor-line.co.uk EMAIL: guides@shor-line.com WEB ADDRESS: SHOR-LINE.co.uk WEB ADDRESS: SHOR-LINE.com Shor-Line.com …...
