U.S. Boiler Company ALPINE ALP500C Installation, Operating And Service Instructions

Condensing high efficiency direct vent gas - fired hot water boiler
Hide thumbs Also See for ALPINE ALP500C:
Table of Contents

Advertisement

Quick Links

http://waterheatertimer.org/Two-water-heaters.html#boiler
http://waterheatertimer.org/What-size-indirect-heater.html
inSTaLLaTiOn, OPEraTing anD
SErViCE inSTrUCTiOnS FOr
COnDEnSing HigH EFFiCiEnCY
GAS - FIRED HOT WATER BOILER
Size range - 399 MBH through 800 MBH
alpine "C" Models:
• ALP399C
• ALP500C
• ALP600C
• ALP700C
• ALP800C
Warning:
Improper installation, adjustment, alteration, service or maintenance can cause property damage,
injury, or loss of life. For assistance or additional information, consult a qualified installer, service agency or the
gas supplier. This boiler requires a special venting system. Read these instructions carefully before installing.
106307-02 - 2/17
aLPinE™
DirECT VEnT
9700609
Price - $5.00
1
