Condensing high efficiency direct vent, gas-fired hot water boiler
Hide thumbs
Table of Contents

Advertisement

Quick Links

INSTALLATION, OPERATING AND
SERVICE INSTRUCTIONS FOR
CONDENSING HIGH EFFICIENCY
GAS - FIRED HOT WATER BOILER
9700609
Space Heating Models:
• ASPN-085
• ASPN-110
• ASPN-155
• ASPN-205
• ASPN-270
Combi Domestic Hot Water
and Space Heating Model:
• ASPNC-155
TO THE INSTALLER: Affix these instructions adjacent to boiler.
TO THE CONSUMER: Retain these instructions for future reference.
As an ENERGY STAR
®
STAR
guidelines for energy efficiency established by the United States Environmental Protection Agency (EPA).
®
Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury, or
loss of life. For assistance or additional information, consult a qualified installer, service agency or the gas
supplier. This boiler requires a special venting system. Read these instructions carefully before installing.
107362-01 - 8/17
ASPEN™
DIRECT VENT
Partner, U.S. Boiler Company has determined that the ASPEN™ Series meets the ENERGY
WARNING
Price - $5.00
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASPEN ASPN-085 and is the answer not in the manual?

Questions and answers

Related Manuals for U.S. Boiler Company ASPEN ASPN-085

Summary of Contents for U.S. Boiler Company ASPEN ASPN-085

  • Page 1 TO THE INSTALLER: Affix these instructions adjacent to boiler. TO THE CONSUMER: Retain these instructions for future reference. As an ENERGY STAR Partner, U.S. Boiler Company has determined that the ASPEN™ Series meets the ENERGY ® STAR guidelines for energy efficiency established by the United States Environmental Protection Agency (EPA).
  • Page 2 IMPORTANT INFORMATION - READ CAREFULLY NOTE: The equipment shall be installed in accordance with those installation regulations enforced in the area where the installation is to be made. These regulations shall be carefully followed in all cases. Authorities having jurisdiction shall be consulted before installations are made.
  • Page 3 WARNING Asphyxiation Hazard. Fire Hazard. Explosion Hazard. This boiler requires regular maintenance and service to operate safely. Follow the instructions contained in this manual. WARNING Asphyxiation Hazard. This boiler requires regular maintenance and service to operate safely. Follow the instructions contained in this manual. Improper installation, adjustment, alteration, service or maintenance can cause property damage, personal injury or loss of life.
  • Page 4 Special Installation Requirements for Massachusetts A. For all sidewall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes and where the sidewall exhaust vent termination is less than seven (7) ft. above grade, the following requirements shall be satisfied: 1.
  • Page 5 WARNINGS FOR THE HOMEOWNER FOLLOW ALL INSTRUCTIONS and warnings unless alarms or other safeguards are in place to printed in this manual and posted on the boiler. prevent such damage. MAINTAIN THE BOILER. To keep your boiler safe DO NOT BLOCK AIR FLOW into or around the and efficient, have a service technician maintain boiler.

  • Page 6: Table Of Contents

    Table of Contents Product Description Specifications III. Before Installing Locating The Boiler Mounting The Boiler Air For Ventilation VII. Venting A. Vent System Design Design Requirements Unique to Horizontal Twin Pipe Venting Systems Design Requirements Unique to Vertical Venting Systems D.

  • Page 7: Product Description

    I. Product Description This boiler is a stainless steel gas fired condensing boiler designed for use in forced hot water heating systems requiring supply water temperatures of 180°F or less. It is designed for installation on a wall. This boiler may be vented vertically or horizontally with combustion air supplied from outdoors.
  • Page 8 II. Specifications (continued) Combustion Air Blower Air Proving Switch Gas Valve Programmed Transformer Display Supply Sensor Blocked Vent Switch 24V Fuse Circulator Fuse Return Sensor Flue Temperature Low Voltage PCB Sensor High Voltage PCB Figure 2.2: Boiler Internal Component Locations Table 2.3: Specifications Maximum D.O.E.

  • Page 9: Before Installing

    II. Specifications (continued) Table 2.4: Vent Lengths Nominal Approx. Model Min Vent Length Max Vent Vent/Intake Size Derate at Max Vent Size (in) Length (ft) (in) 11.3 See Section VII “Venting” for additional requirements and details. III. Before Installing 1. Safe, reliable operation of this boiler depends upon installation by a professional heating contractor in strict accordance with this manual and the requirements of the authority having jurisdiction.

  • Page 10: Locating The Boiler

    III. Before Installing (continued) DANGER • Do not attempt to operate this boiler on LP gas without converting it using the proper conversion kit. • Do not attempt to convert this boiler to LP gas without the use of a combustion analyzer. •...
  • Page 11 IV. Locating the Boiler (continued) 2 " This boiler is listed for closet installation with the following clearances from the boiler jacket to combustible construction: Top: 11-5/8", Sides: 1/2", Front: 1/2", Bottom: 6" This above clearances also apply to non-combustible walls, doors, ceilings and oors.

  • Page 12: Mounting The Boiler

    V. Mounting The Boiler A. Wall Mounting CAUTION • Two people are required to safely lift this boiler onto the wall mounting hook. • Make sure that wall mounting hook is anchored to a structure capable of supporting the weight of the boiler and attached piping when filled with water. Jurisdictions in areas subject to earthquakes may have special requirements for supporting this boiler.
  • Page 13 V. Mounting The Boiler (continued) Figure 5.1 Wall Layout / Mounting Hole Location 107362-01 - 8/17...
  • Page 14 V. Mounting The Boiler (continued) Figure 5.2 Boiler Mounting Bracket Installation / Boiler Wall Mounting 107362-01 - 8/17...

  • Page 15: Air For Ventilation

    VI . Air for Ventilation WARNING Outdoor combustion air must be piped to the air intake. Never pipe combustion air from areas containing contaminates such as swimming pools and laundry room exhaust vents. Contaminated combustion air will damage the boiler and may cause property damage, personal injury or loss of life. Air for combustion must always be obtained directly from outdoors.

  • Page 16: Venting

    VII. Venting WARNING Asphyxiation Hazard. Failure to vent this boiler in accordance with these instructions could cause products of combustion to enter the building resulting in severe property damage, personal injury or death. Do not interchange vent systems or materials unless otherwise specified. The use of thermal insulation covering vent pipe and fittings is prohibited.
  • Page 17 VII. Venting A. Vent System Design (continued) Figure 7.0a: Horizontal Twin Pipe Figure 7.0b: Vertical Twin Pipe Figure 7.0c: Split Venting 107362-01 - 8/17...
  • Page 18 VII. Venting A. Vent System Design (continued) 1. Listed Vent Systems and Materials – The following materials and vent systems may be used to vent this boiler: • CPVC – Use only CPVC listed to ASTM F441. In Canada, this pipe must also be listed to ULC S636. •...
  • Page 19 VII. Venting A. Vent System Design (continued) NOTICE Do not exceed maximum vent/combustion air system length. Refer to Tables 7.1 and 7.13 in this section for maximum vent/combustion air system length. Use only vent and combustion air terminals and terminal locations shown in Tables 7.5, 7.13, and 7.21 and related Figures in this section.
  • Page 20 VII. Venting A. Vent System Design (continued) Supporting Pipe - Vertical and horizontal sections of pipe must be properly supported. Maximum support spacing is as follows: • Support CPVC/PVC horizontally and vertically every 4 feet. • Support DuraVent PolyPro horizontally near the female end of each straight section of pipe and vertically every 10 feet. •...
  • Page 21 VII. Venting A. Vent System Design (continued) Figure 7.3a Figure 7.3b Figure 7.3c Figure 7.3: Expansion Loops for CPVC/PVC Pipe Figure 7.4: Wall Penetration Clearances for PVC Vent Pipe 107362-01 - 8/17...

  • Page 22: Design Requirements Unique To Horizontal Twin Pipe Venting Systems

    VII. Venting B. Design Requirements Unique to Horizontal Twin Pipe Venting Systems (continued) B. Design Requirements Unique to Horizontal Twin Pipe Venting Systems Table 7.5 summarizes all horizontal twin pipe vent options. Illustrations of horizontal twin pipe vent systems are shown in Figures 7.6 –...
  • Page 23 VII. Venting B. Design Requirements Unique to Horizontal Twin Pipe Venting Systems (continued) Table 7.5: Summary of Horizontal Twin Pipe Venting Options Vent Option 7.6, 7.7, 7.6, 7.7, Illustrated in Figure 7.9, 7.10 7.9, 7.10 Pipe Vent Wall Wall Wall Wall Wall Wall...
  • Page 24 VII. Venting B. Design Requirements Unique to Horizontal Twin Pipe Venting Systems (continued) 2. Horizontal Vent and Air Intake Terminal Location - Observe the following limitations on the vent terminal location (also see Figure 7.11). When locating a concentric terminal, observe the limitations outlined below for “vent terminals”. •...
  • Page 25 VII. Venting B. Design Requirements Unique to Horizontal Twin Pipe Venting Systems (continued) Figure 7.7: Horizontal CPVC/PVC Venting with Low Profile Terminal, (Vent Options #1 & 2, Terminal Options B & C) Figure 7.8: Horizontal CPVC/PVC Venting with Concentric Vent Terminal, (Vent Options #1 &...
  • Page 26 VII. Venting B. Design Requirements Unique to Horizontal Twin Pipe Venting Systems (continued) Figure 7.9: Duravent PolyPro, Selkirk, Polyflue or Centrotherm InnoFlue Horizontal Venting (Vent Option #3 - 8, Terminal Option A) Figure 7.10: Duravent PolyPro Horizontal Venting with Concentric Terminal, (Vent Options #3 &...
  • Page 27 VII. Venting B. Design Requirements Unique to Horizontal Twin Pipe Venting Systems (continued) 107362-01 - 8/17...

  • Page 28: Design Requirements Unique To Vertical Venting Systems

    VII. Venting C. Design Requirements Unique to Vertical Venting Systems (continued) Figure 7.12: Snorkel Terminal Configuration (CPVC/PVC Vent Systems Only) C. Design Requirements Unique to Vertical Venting Systems Table 7.13a summarizes all vertical twin pipe vent options. Table 7.13.b summarizes vent options in which an abandoned B-vent chimney is used both as a chase for the vent pipe and as a conduit for combustion air.
  • Page 29 VII. Venting C. Design Requirements Unique to Vertical Venting Systems (continued) Table 7.13a: Summary of Vertical Twin Pipe Venting Options Option Illustrated in Figure 7.15, 717 7.15, 7.17 7.17, 7.18 7.17, 7.18 7.17 7.17 7.17 7.17 Pipe Vent Roof Roof Roof Roof Roof...
  • Page 30 VII. Venting C. Design Requirements Unique to Vertical Venting Systems (continued) Table 7.13b: Summary of Vertical “B-Vent Air Chase” Vent Options (B-Vent Chase MUST Be Sealed) Option Illustrated in Figure 7.19 7.19 7.20 7.20 Vent Roof Roof Roof Roof Pipe Penetration Through Structure Intake Roof...
  • Page 31 VII. Venting C. Design Requirements Unique to Vertical Venting Systems (continued) Terminal Option J: Diversitech Concentric Terminal (Acceptable for Vent Options 10 & 11) - This terminal is shown in Figure 7.16 and may be used with CPVC/PVC vent systems. See Part VII-E of this manual and the Diversitech instructions provided with the terminal, for installation details.
  • Page 32 VII. Venting C. Design Requirements Unique to Vertical Venting Systems (continued) Table 7.14: Equivalent Length of Flex Pipe Equivalent Length (ft) Flex Vent (1 ft): 2" DuraVent PolyPro Flex 2.0 ft 2" Centrotherm InnoFlue Flex 2.0 ft 2" Selkirk Polyflue 2.0 ft 3"...
  • Page 33 VII. Venting C. Design Requirements Unique to Vertical Venting Systems (continued) Figure 7.15: Vertical CPVC/PVC Venting (Vent Options 10 & 11, Terminal Option H) Figure 7.16: Vertical CPVC/PVC Venting with IPEX Concentric Vent Terminal (Vent Options #10 & 11, Terminal Option I, J) 107362-01 - 8/17...
  • Page 34 VII. Venting C. Design Requirements Unique to Vertical Venting Systems (continued) Figure 7.17: Duravent PolyPro, Selkirk Polyflue or Centrotherm InnoFlue Vertical Single Wall PP Venting (Vent Options #12-17, Terminal Option H) Figure 7.18: Duravent PolyPro Vertical Venting with Concentric Terminal (Vent Options #12 &...
  • Page 35 VII. Venting C. Design Requirements Unique to Vertical Venting Systems (continued) Figure 7.19: Duravent PolyPro B-Vent Air Chase System (Vent Options #18 & 19) Figure 7.20: Centrotherm InnoFlue B-Vent Air Chase System (Vent Options #20 & 21) 107362-01 - 8/17...

  • Page 36: Design Requirements Unique To Split Vent Systems

    VII. Venting D. Design Requirements Unique to Split Vent Systems (continued) D. Design Requirements Unique to Split Vent Systems Table 7.21 summarizes all split vent options. Illustrations of split vent systems are shown in Figures 7.22, 7.23, and 7.24. In addition to the requirements in Part VII-A, observe the following design requirements: 1.
  • Page 37 VII. Venting D. Design Requirements Unique to Split Vent Systems (continued) Example: A 110MBH model is to be installed as using Vent Option 34 in a masonry chimney as shown in Figure 7.23. The following components are used: Vent: 3" DuraVent Poly-Pro (Rigid) – 4ft 3"...
  • Page 38 VII. Venting D. Design Requirements Unique to Split Vent Systems (continued) Table 7.21: Summary of Split Vent System Options Option # Illustrated in Figure 7.22 7.22 7.22 7.22 7.22 7.22 Vent Roof Roof Roof Roof Roof Roof Pipe Penetration Through Structure Intake Wall Wall...
  • Page 39 VII. Venting D. Design Requirements Unique to Split Vent Systems (continued) Table 7.21: Summary of Split Vent System Options (continued) Option # Illustrated in Figure 7.22 7.22 7.23, 7.24 7.23, 7.24 Vent Roof Roof Roof Roof Pipe Penetration Through Structure Intake Wall Wall...
  • Page 40 VII. Venting D. Design Requirements Unique to Split Vent Systems (continued) Option # Illustrated in Figure 7.23, 7.24 7.23, 7.24 7.23, 7.24 7.23, 7.24 7.23, 7.24 Vent Roof Roof Roof Roof Roof Pipe Penetration Through Structure Intake Wall Wall Wall Wall Wall Selkirk...
  • Page 41 VII. Venting D. Design Requirements Unique to Split Vent Systems (continued) Figure 7.22: Split Rigid Vent System (Vent Options 25-32) Figure 7.23: Split Vent System (Flex in B-Vent Chase) Vent Options 33-38) 107362-01 - 8/17...
  • Page 42 VII. Venting D. Design Requirements Unique to Split Vent Systems (continued) Figure 7.24a: Split Vent System (PP Flex in Abandoned Masonry Chimney) (Vent Options 33-38) 107362-01 - 8/17...
  • Page 43 VII. Venting D. Design Requirements Unique to Split Vent Systems (continued) WARNING Venting of Other Appliances (Or Fireplace) into Chase or Adjacent Flues Prohibited! Figure 7.24b: Flexible PP Masonry Chimney Chase Requirements 107362-01 - 8/17...
  • Page 44 VII. Venting D. Design Requirements Unique to Split Vent Systems (continued) Figure 7.25a: Split Vent System (SS Flex in Abandoned Masonry Chimney) (Vent Option 39) WARNING Venting of Other Appliances (Or Fireplace) into Chase Prohibited! Figure 7.25b: Flexible SS Masonry Chimney Chase Requirements 107362-01 - 8/17...

  • Page 45: Assembly Of Cpvc/Pvc Vent Systems

    VII. Venting E. Assembly of CPVC/PVC Vent Systems E. Assembly of CPVC/PVC Vent Systems WARNING Failure to follow this warning could result in asphyxiation and/or carbon monoxide poisoning. Correct venting material and installation is required for proper vent operation. PVC Vent Systems must include at least 30 inches of CPVC and one CPVC elbow between the boiler and PVC vent piping.
  • Page 46 VII. Venting E. Assembly of CPVC/PVC Vent Systems (continued) Figure 7.26: Vent Connections and Flue Gas Sample Cap Location h. Maintain the clearances from the vent pipe outlined in Part VII-A of this manual. If exiting the exterior wall using PVC pipe, use half of an appropriately sized wall thimble (or a sheet metal plate) on the exterior of the building, to provide a weather tight seal while maintaining the proper clearance in the wall penetration.
  • Page 47 VII. Venting E. Assembly of CPVC/PVC Vent Systems (continued) Figure 7.27: Installation of Standard Horizontal Terminals Figure 7.28: Installation of Standard Vertical Terminals 107362-01 - 8/17...
  • Page 48 VII. Venting E. Assembly of CPVC/PVC Vent Systems (continued) 4. Installation of Vertical Fitting Terminals (Terminal Option H): a. See Figure 7.28 for the proper orientation of twin pipe vertical terminals. b. The coupling is used to secure the rodent screen to the end of the vent pipe. c.
  • Page 49 VII. Venting E. Assembly of CPVC/PVC Vent Systems (continued) Figure 7.29: Installation of IPEX Low Profile Terminal Through Sidewall Figure 7.30: Installation of Diversitech Low Profile Terminal Through Sidewall 107362-01 - 8/17...
  • Page 50 VII. Venting E. Assembly of CPVC/PVC Vent Systems (continued) Figure 7.31: Cutting IPEX and Diversitech Concentric Vent Terminals Figure 7.32: Installation of IPEX and Diversitech Concentric Terminal through Sidewall 107362-01 - 8/17...
  • Page 51 VII. Venting E. Assembly of CPVC/PVC Vent Systems (continued) Figure 7.33: Installation of IPEX and Diversitech Concentric Terminal Through Roof b. For vertical installations, cut a hole in the roof large enough to clear the concentric terminal at the location of the terminal (see Part VII-C of this manual for permitted terminal locations).

  • Page 52: Assembly Of Duravent Polypro Vent Systems

    VII. Venting F. Assembly of DuraVent PolyPro Vent Systems (continued) F. Assembly of DuraVent PolyPro Vent Systems 1. This boiler has been listed for use with the DuraVent PolyPro single wall PolyPropylene vent system to be provided by the installer. WARNING Asphyxiation Hazard.
  • Page 53 VII. Venting F. Assembly of DuraVent PolyPro Vent Systems (continued) 3. Installation of Air Intake System - Start assembly of the PVC air intake system at the boiler. Assembly of the air intake system is done in the same manner as the vent system except as follows: a.
  • Page 54 VII. Venting F. Assembly of DuraVent PolyPro Vent Systems (continued) Figure 7.35: Installation of Duravent PolyPro UV Resistant Single Wall Horizontal Terminal Figure 7.36: Installation of Duravent PolyPro UV Resistant Single Wall Vertical Terminal 107362-01 - 8/17...
  • Page 55 VII. Venting F. Assembly of DuraVent PolyPro Vent Systems (continued) 6. Installation of DuraVent PolyPro Horizontal Concentric Vent Terminal (Terminal Option D) - Install PolyPro Horizontal Concentric Termination Kit #2PPS-HK or #3PPS-HK (Figure 7.38) as follows: a. At the planned location cut a 4-1/8" round hole for the 2" terminal or a 5-1/8" round hole for the 3" terminal in the exterior wall.
  • Page 56 VII. Venting F. Assembly of DuraVent PolyPro Vent Systems (continued) Figure 7.38: Installation of Duravent PolyPro Concentric Vent Terminal Through Sidewall Figure 7.39: Installation of Duravent PolyPro Concentric Terminal Through Roof 107362-01 - 8/17...

  • Page 57: Assembly Of Selkirk Polyflue Vent Systems

    VII. Venting F. Assembly of DuraVent PolyPro Vent Systems (continued) Installations using PolyPro-flex (Vent Options 18,19,33,34): WARNING Asphyxiation Hazard. When using PolyPro flex, observe the following precautions: • PolyPro flex may be damaged by handling at low temperatures. Do not bend, uncoil, or attempt to install if it has been stored at a temperature below 42°F without allowing it to warm to a higher temperature first.
  • Page 58 VII. Venting G. Assembly of Selkirk Polyflue Vent Systems (continued) e. Support each pipe section as described in Polyflue manual at intervals not exceeding the following: Pipe size Horizontal Vertical 2" 30in 16ft 3" 39in 16ft 3. Installation of Air Intake System - Start assembly of the PVC air intake system at the boiler. Assembly of the air intake system is done in the same manner as the vent system except as follows: a.
  • Page 59 VII. Venting G. Assembly of Selkirk Polyflue Vent Systems (continued) 6. Installations using flexible Polyflue (Vent Options 35,36): WARNING Asphyxiation Hazard. When using Polyflue flex, observe the following precautions: • Polyflue flex may be damaged by handling at low temperatures. Do not bend, uncoil or attempt to install if it has been stored at a temperature below 42°F without allowing it to warm to a higher temperature first.
  • Page 60 VII. Venting G. Assembly of Selkirk Polyflue Vent Systems (continued) Figure 7.41: Installation of Selkirk Polyflue UV Resistant Single Wall Horizontal Terminal Figure 7.42: Installation of Selkirk Polyflue UV Resistant Single Wall Vertical Terminal 107362-01 - 8/17...

  • Page 61: Assembly Of Centrotherm Innoflue Vent Systems

    VII. Venting H. Assembly of Centrotherm InnoFlue Vent Systems 1. This boiler has been listed for use with the Centrotherm InnoFlue single wall PolyPropylene vent system to be provided by the installer. WARNING Asphyxiation Hazard. Follow these instructions and the installation instructions included by the original PolyPropylene venting component manufacturers, Centrotherm.
  • Page 62 VII. Venting H. Assembly of Centrotherm InnoFlue Vent Systems 3. Installation of Air Intake System - Start assembly of the PVC air intake system at the boiler. Assembly of the air intake system is done in the same manner as the vent system except as follows: a.
  • Page 63 VII. Venting H. Assembly of Centrotherm InnoFlue Vent Systems Figure 7.44: Installation of Centrotherm InnoFlue UV Stabilized Single Wall Horizontal Terminal Figure 7.45: Installation of Centrotherm InnoFlue UV Stabilized Single Wall Vertical Terminal 107362-01 - 8/17...
  • Page 64 6. Installations using InnoFlue Flex (Vent Options 20,21,37,38): WARNING Asphyxiation Hazard. When using InnoFlue Flex, observe the following precautions: • InnoFlue Flex may be damaged by handling at low temperatures. Do not bend, uncoil or attempt to install if it has been stored at a temperature below 42°F without allowing it to warm to a higher temperature first.

  • Page 65: Assembly Of Stainless Steel Vent Systems

    This boiler has been listed for use with DuraVent FasNSeal Flex Stainless Steel vent systems to be provided by the installer. WARNING Asphyxiation Hazard. Follow these instructions and the installation instructions included by the original stainless steel venting component manufacturer, DuraVent. Failure to do so could cause products of combustion to enter the building, resulting in severe property damage, personal injury or death.
  • Page 66 d. When flexible stainless steel pipe is used for combustion product venting, it must be installed at vertical or near vertical orientation. This will insure proper condensate flow back towards the boiler. e. Follow flexible stainless steel pipe manufacturer specific instructions regarding application/listing, permits, minimum clearances to combustibles, installation details (proper joint assembly, pipe support and routing, gasket and fitting installation, optional tooling availability/usage, routing through masonry combustion of combustion product venting and combustion air supply).

  • Page 67: Condensate Trap And Drain

    VII. Venting J. Condensate Trap and Drain Line All condensate which forms in the boiler or vent system passes through the heat exchanger and out of a bottom drain port which is connected to the field-installed condensate trap. This trap allows condensate to drain from the heat exchanger while retaining flue gases in the boiler.
  • Page 68 VII. Venting J. Condensate Trap and Drain Line (continued) Condensate Drain Bottom of Boiler Connector through knockout to low voltage wiring harness. Float Switch Worm Gear Condensate Trap Bracket Assembled Condensate Trap #8-18 Thread Forming Screw (1/4" Long) Connector from Low Voltage Wiring Harness To Low...

  • Page 69: Removing An Existing Boiler From Common Chimney

    VII. Venting K. Removing an Existing Boiler From a Common Chimney K. Removing an Existing Boiler From a Common Chimney This section only applies if this boiler is replacing an existing boiler that is being removed from a common chimney. In some cases, when an existing boiler is removed from a common chimney, the common venting system may be too large for the remaining appliances.

  • Page 70: Gas Piping

    VIII. Gas Piping WARNING Explosion Hazard. Failure to properly pipe gas supply to boiler may result in improper operation or leaks of flammable gas. Gas supply to boiler and system must be absolutely shut off prior to installing or servicing boiler gas piping. Always assure gas piping is absolutely leak free and of the proper size and type for the connected load.
  • Page 71 VIII. Gas Piping (continued) CAUTION Support the weight of the gas line piping independently from the boiler gas connection fitting located on the bottom of the boiler. If an additional regulator is used to reduce boiler inlet pressure below 1/2 psig (3.4 kPa) it must be at least 6 to 10 ft.

  • Page 72: System Piping
