For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM3396AC-2PK
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Page 1 of 5
(Included)
Rev: 18-05-19
Advertisement
Related Manuals for Furniture of America CM3396AC-2PK
Summary of Contents for Furniture of America CM3396AC-2PK
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM3396AC-2PK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being easy and 5 being difficult). For some Allen Wrench products, two persons are recommended.
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 4pcs x 2 #1 x 1pc x 2 Chair Back Bolt Ø5/16" x 3-1/8" #B x 4pcs x 2 #2 x 1pc x 2 Seat Cushion...
- Page 4 Align seat (#2) to the holes of the chair back (#1), then secure two middle holes by using bolts (#B) with washers (#D,E). #B x 2pcs #D x 2pcs #E x 2pcs DO NOT FULLY TIGHTEN BOLTS/SCREWS UNTIL ALL ASSEMBLY IS COMPLETED. Secure corner holes of the seat (#2) to chair back (#1) by using bolts (#A) with washers (#D,E).
- Page 5 #C x 4pcs #D x 4pcs #E x 4pcs Align front legs (#3) to the holes of the seat (#2), then secure by using hex nuts (#C) with washers (#D,E). #B x 2pcs #D x 2pcs #E x 2pcs #G x 2pcs Align arms (#4) to the hole of the seat (#2), then secure by using bolts (#B)
