ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FRS26KF6DB0 FRS26KF6DQ0 FRS26KF6DW0
Series
R134a
Color
black
Volts
115
Wiring Diagram
241526901
Owner's Guide
241572800
Market
North America North America
Energy Guide
241538773
Service Data Sheet 240389618
Publication No.
5995412755
04/07/08
(EN/SERVICE/KHB)
357
R134a
R134a
bisque
white
115
115
241526901
241526901
241572800
241572800
North America
241538773
241538773
240389618
240389618
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS26KF6D
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FRS26KF6D
Summary of Contents for Frigidaire FRS26KF6D
- Page 1 241526901 241526901 241526901 241572800 241572800 241572800 North America North America North America 241538773 241538773 241538773 240389618 240389618 SIDE-BY-SIDE REFRIGERATOR Model No. FRS26KF6D Publication No. 5995412755 04/07/08 (EN/SERVICE/KHB) © Copyright 2004 Electrolux Home Products, Inc. All rights reserved.
-
Page 2: Freezer Door
Publication No: 5995412755 FRS26KF6D FREEZER DOOR N58FCCBBB2 07/04... - Page 3 240352102 240470401 240552102 5303918256 # Functional Parts * Non-Illustrated Parts FRS26KF6D FREEZER DOOR A FRS26KF6D (FRS26KF6DB0) B FRS26KF6D (FRS26KF6DQ0) C FRS26KF6D (FRS26KF6DW0) DESCRIPTION A - - Gasket-frzr door, black, magnetic - B C Gasket-frzr door, white, magnetic A B C...
-
Page 4: Refrigerator Door
Publication No: 5995412755 07/04 FRS26KF6D REFRIGERATOR DOOR N58RCCBBB5... - Page 5 240356401 240421701 218396700 215503200 # Functional Parts * Non-Illustrated Parts FRS26KF6D REFRIGERATOR DOOR A FRS26KF6D (FRS26KF6DB0) B FRS26KF6D (FRS26KF6DQ0) C FRS26KF6D (FRS26KF6DW0) DESCRIPTION A - - Gasket-refr door, black, magnetic - B C Gasket-refr door, white, magnetic A B C...
- Page 6 Publication No: 5995412755 07/04 FRS26KF6D CABINET N58BAAAAB1...
- Page 7 240479601 240481601 5303305345 5304414035 5303305324 # Functional Parts * Non-Illustrated Parts FRS26KF6D CABINET A FRS26KF6D (FRS26KF6DB0) B FRS26KF6D (FRS26KF6DQ0) C FRS26KF6D (FRS26KF6DW0) DESCRIPTION A B C Cover-air duct A B C Cover-evap coil, lower A B C Plug-hole, factory test...
- Page 8 Publication No: 5995412755 07/04 FRS26KF6D SHELVES N58SJCIBC11...
- Page 9 241561201 215005100 218867405 218867406 240430501 # Functional Parts * Non-Illustrated Parts FRS26KF6D SHELVES A FRS26KF6D (FRS26KF6DB0) B FRS26KF6D (FRS26KF6DQ0) C FRS26KF6D (FRS26KF6DW0) DESCRIPTION A B C Shelf-freezer, flip-up A B C Shelf-freezer, fixed wire A B C Shelf-freezer, fixed wire...
- Page 10 Publication No: 5995412755 FRS26KF6D CONTROLS 07/04...
- Page 11 240397601 240398501 3205266 240427201 240470401 # Functional Parts * Non-Illustrated Parts FRS26KF6D CONTROLS A FRS26KF6D (FRS26KF6DB0) B FRS26KF6D (FRS26KF6DQ0) C FRS26KF6D (FRS26KF6DW0) DESCRIPTION A B C Fan Blade, red, evaporator fan A B C Bushing-motor mtg, (2) A B C...
- Page 12 Publication No: 5995412755 FRS26KF6D SYSTEM 07/04...
- Page 13 5304421068 240553501 240409302 5303918213 5303918222 # Functional Parts * Non-Illustrated Parts FRS26KF6D SYSTEM A FRS26KF6D (FRS26KF6DB0) B FRS26KF6D (FRS26KF6DQ0) C FRS26KF6D (FRS26KF6DW0) DESCRIPTION A B C Condenser A B C Block-evap coil, styrofoam, (2) A B C Drier-filter, R134a System...
-
Page 14: Ice And Water Dispenser
Publication No: 5995412755 FRS26KF6D ICE & WATER DISPENSER 07/04... - Page 15 5304421831 5304421850 5303918256 5304426535 # Functional Parts * Non-Illustrated Parts FRS26KF6D ICE & WATER DISPENSER A FRS26KF6D (FRS26KF6DB0) B FRS26KF6D (FRS26KF6DQ0) C FRS26KF6D (FRS26KF6DW0) DESCRIPTION A B C Tube-water A B C Tube-water inlet, inlet valve, to ice maker A B C...
-
Page 16: Ice Container
Publication No: 5995412755 07/04 FRS26KF6D ICE CONTAINER 37A 34 34 33 N58YDAAAC0... - Page 17 5304404361 5304404331 241561502 241551601 240562101 241561601 # Functional Parts * Non-Illustrated Parts FRS26KF6D ICE CONTAINER A FRS26KF6D (FRS26KF6DB0) B FRS26KF6D (FRS26KF6DQ0) C FRS26KF6D (FRS26KF6DW0) DESCRIPTION A B C Auger-ice A B C Cam-drive A B C Container-ice, bucket only A B C...
-
Page 18: Ice Maker
Publication No: 5995412755 07/04 FRS26KF6D ICE MAKER INSTALLATION PARTS N58I115T... - Page 19 241523503 55 # 240531101 218709100 # Functional Parts * Non-Illustrated Parts FRS26KF6D ICE MAKER A FRS26KF6D (FRS26KF6DB0) B FRS26KF6D (FRS26KF6DQ0) C FRS26KF6D (FRS26KF6DW0) DESCRIPTION A B C Tube-water A B C Tube-water inlet, inlet valve, to ice maker A B C...
- Page 20 Publication No: 5995412755 07/04 FRS26KF6D ICE MAKER INSTALLATION PARTS N58I115T...
- Page 21 5304436611 5304436612 218888001 240599901 241583301 # Functional Parts * Non-Illustrated Parts FRS26KF6D ICE MAKER A FRS26KF6D (FRS26KF6DB0) B FRS26KF6D (FRS26KF6DQ0) C FRS26KF6D (FRS26KF6DW0) DESCRIPTION A B C Screw-shoulder A B C Cap-water valve A B C Screw, hex washer head, 8-15A x 1.000, (2) A B C Clamp, 0.31 ID, steel, copper wtr line...
-
Page 22: Wiring Schematic
Publication No: 5995412755 FRS26KF6D WIRING SCHEMATIC 07/04... -
Page 23: Wiring Diagram
FRS26KF6D Publication No: 5995412755 WIRING DIAGRAM 07/04 # Functional Parts * Non-Illustrated Parts...
