N58L00001.eps N58FCCBBB2.eps N58RCCBBB11.eps N58BAAAAA0.eps
N58SJCHAB12.eps N58TAAAAB4.eps N58CAAAAA10.eps N58XDAAAA1.eps
N58YBAAAA4.eps N58I1151.eps W241708401.eps S241708401.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS26KF6EB9 FRS26KF6EM9 FRS26KF6EW9
Series
R134a
Color
black
Volts
115
Wiring Diagram
241708401
Owner's Guide
241856000
Market
North America North America
Energy Guide
241615424
Service Data Sheet 240389629
Publication No.
5995497103
07/08/10
(EN/SERVICE/KHB)
137
R134a
R134a
silver mist
white
115
115
241708401
241708401
241856000
241856000
North America
241615424
241615424
240389629
240389629
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS6KF6E
©
Copyright
All rights reserved.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRS6KF6E
Summary of Contents for Frigidaire FRS6KF6E
- Page 1 Product No. FRS26KF6EB9 FRS26KF6EM9 FRS26KF6EW9 Series R134a R134a R134a Color black silver mist white Volts Wiring Diagram 241708401 241708401 241708401 Owner's Guide 241856000 241856000 241856000 Market North America North America North America Energy Guide 241615424 241615424 241615424 Service Data Sheet 240389629 240389629 240389629 SIDE-BY-SIDE...
-
Page 2: Freezer Door
Publication No: 5995497103 FRS6KF6E FREEZER DOOR N58FCCBBB2 08/07... - Page 3 FRS6KF6E Publication No: 5995497103 FREEZER DOOR Model Index: A FRS26KF6E (FRS26KF6EB9) B FRS26KF6E (FRS26KF6EM9) C FRS26KF6E (FRS26KF6EW9) POS. NO PART NO. DESCRIPTION 241786006 A B - Gasket-frzr door, black, magnetic 241786002 - - C Gasket-frzr door, white, magnetic 240334201 A B C Bin-door, frzr-upper 240351601 A B C...
-
Page 4: Refrigerator Door
Publication No: 5995497103 FRS6KF6E REFRIGERATOR DOOR N58RCCBBB11 08/07... - Page 5 FRS6KF6E Publication No: 5995497103 REFRIGERATOR DOOR Model Index: A FRS26KF6E (FRS26KF6EB9) B FRS26KF6E (FRS26KF6EM9) C FRS26KF6E (FRS26KF6EW9) POS. NO PART NO. DESCRIPTION 241786005 A B - Gasket-refr door, black, magnetic 241786001 - - C Gasket-refr door, white, magnetic 240323002 A B C Bin-door, pseudo, bottom 240326203 A B C...
- Page 6 Publication No: 5995497103 FRS6KF6E CABINET 08/07...
- Page 7 FRS6KF6E Publication No: 5995497103 CABINET Model Index: A FRS26KF6E (FRS26KF6EB9) B FRS26KF6E (FRS26KF6EM9) C FRS26KF6E (FRS26KF6EW9) POS. NO PART NO. DESCRIPTION 240435912 A B C Cover-air duct 241719711 A B C Cover-evap coil, lower 5303208309 A B C Plug-hole, factory test 240505801 A B C Switch, light/lamp...
- Page 8 Publication No: 5995497103 FRS6KF6E SHELVES N58SJCHAB12 08/07...
- Page 9 FRS6KF6E Publication No: 5995497103 SHELVES Model Index: A FRS26KF6E (FRS26KF6EB9) B FRS26KF6E (FRS26KF6EM9) C FRS26KF6E (FRS26KF6EW9) POS. NO PART NO. DESCRIPTION 241657602 A B C Shelf, flip up, wire 241657502 A B C Shelf, fixed, freezer 241657504 A B C Shelf, fixed, upper, freezer 240324101 A B C...
- Page 10 Publication No: 5995497103 FRS6KF6E CONTROLS 08/07...
- Page 11 FRS6KF6E Publication No: 5995497103 CONTROLS Model Index: A FRS26KF6E (FRS26KF6EB9) B FRS26KF6E (FRS26KF6EM9) C FRS26KF6E (FRS26KF6EW9) POS. NO PART NO. DESCRIPTION 5308000010 A B C Fan Blade, red, evaporator fan 215474201 A B C Washer, "slinger", nylon, evap fan shaft 241563601 A B C Bushing-motor mtg, (2)
- Page 12 Publication No: 5995497103 FRS6KF6E SYSTEM N58CAAAAA10 08/07...
- Page 13 FRS6KF6E Publication No: 5995497103 SYSTEM Model Index: A FRS26KF6E (FRS26KF6EB9) B FRS26KF6E (FRS26KF6EM9) C FRS26KF6E (FRS26KF6EW9) POS. NO PART NO. DESCRIPTION 240333603 A B C Condenser 218679607 A B C Block-evap coil, styrofoam, (2) 218944001 A B C Drier-filter, R134a System 241586801 A B C Harness-wiring, machine compt...
-
Page 14: Ice And Water Dispenser
Publication No: 5995497103 FRS6KF6E ICE & WATER DISPENSER 08/07... - Page 15 FRS6KF6E Publication No: 5995497103 ICE & WATER DISPENSER Model Index: A FRS26KF6E (FRS26KF6EB9) B FRS26KF6E (FRS26KF6EM9) C FRS26KF6E (FRS26KF6EW9) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube, water, door 218976915 A B C Tube-water inlet, inlet valve, to filter 218976418 A B C Tube-water inlet, inlet valve, to filter...
-
Page 16: Ice Container
Publication No: 5995497103 FRS6KF6E ICE CONTAINER 37A 34 34 33 N58YBAAAA4 08/07... - Page 17 FRS6KF6E Publication No: 5995497103 ICE CONTAINER Model Index: A FRS26KF6E (FRS26KF6EB9) B FRS26KF6E (FRS26KF6EM9) C FRS26KF6E (FRS26KF6EW9) POS. NO PART NO. DESCRIPTION 241716101 A B C Auger-ice 241685201 A B C Cam-drive 241734001 A B C Container-ice, bucket only 241685101 A B C Drum-ice disp 241734201...
-
Page 18: Ice Maker
Publication No: 5995497103 FRS6KF6E ICE MAKER 08/07... - Page 19 FRS6KF6E Publication No: 5995497103 ICE MAKER Model Index: A FRS26KF6E (FRS26KF6EB9) B FRS26KF6E (FRS26KF6EM9) C FRS26KF6E (FRS26KF6EW9) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube, water, door 218976915 A B C Tube-water inlet, inlet valve, to filter 218976418 A B C Tube-water inlet, inlet valve, to filter 218976419...
- Page 20 Publication No: 5995497103 FRS6KF6E ICE MAKER 08/07...
- Page 21 FRS6KF6E Publication No: 5995497103 ICE MAKER Model Index: A FRS26KF6E (FRS26KF6EB9) B FRS26KF6E (FRS26KF6EM9) C FRS26KF6E (FRS26KF6EW9) POS. NO PART NO. DESCRIPTION 240363602 A B C Screw-shoulder 240542901 A B C Cap-water valve 5303207328 A B C Screw, hex washer head, 8-15A x 1.000, (2) 5304456686 A B C Bracket-leveling, ICE MAKER...
-
Page 22: Wiring Schematic
Publication No: 5995497103 FRS6KF6E WIRING SCHEMATIC 08/07... -
Page 23: Wiring Diagram
FRS6KF6E Publication No: 5995497103 WIRING DIAGRAM 08/07 # Functional Parts * Non-Illustrated Parts...
