Frigidaire FRS26KF5D Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS26KF5D:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Use and Care Manual
N58L00001.eps N58FCCBBB2.eps N58RCCBBB5.eps N58BAAAAA0.eps
N58SJCIBC12.eps N58TAAAAB4.eps N58CAAAAA4.eps N58XDAAAA1.eps
N58YDAAAC0.eps N58I115T.eps W241526901A.eps S241526901A.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378
Augusta, GA 30917
Product No.
FRS26KF5DS3 FRS26KF5DS4 FRS26KF5DS5
Series
R134a
Color
stainless
Volts
115
Wiring Diagram
241526901
Owner's Guide
241570101
Market
North America North America North America
Energy Guide
241585912
Service Data Sheet 240389618
Publication No.
5995429767
05/02/23
(EN/SERVICE/KHB)
357
R134a
R134a
stainless
stainless
115
115
241526901
241526901
241570101
241570101
241585912
241585912
240389618
240389621
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS26KF5D
©
Copyright
All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS26KF5D

Summary of Contents for Frigidaire FRS26KF5D

  • Page 1 Product No. FRS26KF5DS3 FRS26KF5DS4 FRS26KF5DS5 Series R134a R134a R134a Color stainless stainless stainless Volts Wiring Diagram 241526901 241526901 241526901 Owner's Guide 241570101 241570101 241570101 Market North America North America North America Energy Guide 241585912 241585912 241585912 Service Data Sheet 240389618 240389618 240389621 SIDE-BY-SIDE...

  • Page 2: Freezer Door

    Publication No: 5995429767 FRS26KF5D FREEZER DOOR N58FCCBBB2 02/05...
  • Page 3 FRS26KF5D Publication No: 5995429767 FREEZER DOOR Model Index: A FRS26KF5D (FRS26KF5DS3) B FRS26KF5D (FRS26KF5DS4) C FRS26KF5D (FRS26KF5DS5) POS. NO PART NO. DESCRIPTION 241569806 A B C Gasket-frzr door, black, magnetic 240334201 A B C Bin-door, frzr-upper 240351601 A B C Bin-door 240554228 A B -...

  • Page 4: Refrigerator Door

    Publication No: 5995429767 FRS26KF5D REFRIGERATOR DOOR N58RCCBBB5 02/05...
  • Page 5 FRS26KF5D Publication No: 5995429767 REFRIGERATOR DOOR Model Index: A FRS26KF5D (FRS26KF5DS3) B FRS26KF5D (FRS26KF5DS4) C FRS26KF5D (FRS26KF5DS5) POS. NO PART NO. DESCRIPTION 241569805 A B C Gasket-refr door, black, magnetic 240323001 A B C Bin-door, pseudo, bottom 240326203 A B C Door-dairy 240581905 A B C...
  • Page 6 Publication No: 5995429767 FRS26KF5D CABINET 02/05...
  • Page 7 FRS26KF5D Publication No: 5995429767 CABINET Model Index: A FRS26KF5D (FRS26KF5DS3) B FRS26KF5D (FRS26KF5DS4) C FRS26KF5D (FRS26KF5DS5) POS. NO PART NO. DESCRIPTION 240435908 A B C Cover-air duct 240475907 A B C Cover-evap coil, lower 5303208309 A B C Plug-hole, factory test 14 # 240505801 A B C...
  • Page 8 Publication No: 5995429767 FRS26KF5D SHELVES N58SJCIBC12 02/05...
  • Page 9 FRS26KF5D Publication No: 5995429767 SHELVES Model Index: A FRS26KF5D (FRS26KF5DS3) B FRS26KF5D (FRS26KF5DS4) C FRS26KF5D (FRS26KF5DS5) POS. NO PART NO. DESCRIPTION 240338802 A B C Shelf-freezer, flip-up 240338702 A B C Shelf-freezer, fixed wire 240338704 A B C Shelf-freezer, fixed wire 241555401 A B C Light Bulb...
  • Page 10 Publication No: 5995429767 FRS26KF5D CONTROLS 02/05...
  • Page 11 FRS26KF5D Publication No: 5995429767 CONTROLS Model Index: A FRS26KF5D (FRS26KF5DS3) B FRS26KF5D (FRS26KF5DS4) C FRS26KF5D (FRS26KF5DS5) POS. NO PART NO. DESCRIPTION 5308000010 A B C Fan Blade, red, evaporator fan 215474201 A B C Washer, "slinger", nylon, evap fan shaft 241563601 A B C Bushing-motor mtg, (2)
  • Page 12 Publication No: 5995429767 FRS26KF5D SYSTEM N58CAAAAA4 02/05...
  • Page 13 FRS26KF5D Publication No: 5995429767 SYSTEM Model Index: A FRS26KF5D (FRS26KF5DS3) B FRS26KF5D (FRS26KF5DS4) C FRS26KF5D (FRS26KF5DS5) POS. NO PART NO. DESCRIPTION 240333603 A B C Condenser 218679607 A B C Block-evap coil, styrofoam, (2) 218944001 A B C Drier-filter, R134a System 241586801 A - C Harness-wiring, machine compt...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995429767 FRS26KF5D ICE & WATER DISPENSER 02/05...
  • Page 15 FRS26KF5D Publication No: 5995429767 ICE & WATER DISPENSER Model Index: A FRS26KF5D (FRS26KF5DS3) B FRS26KF5D (FRS26KF5DS4) C FRS26KF5D (FRS26KF5DS5) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976903 A B C Tube-water inlet, inlet valve, to filter...

  • Page 16: Ice Container

    Publication No: 5995429767 FRS26KF5D ICE CONTAINER 37A 34 34 33 N58YDAAAC0 02/05...
  • Page 17 FRS26KF5D Publication No: 5995429767 ICE CONTAINER Model Index: A FRS26KF5D (FRS26KF5DS3) B FRS26KF5D (FRS26KF5DS4) C FRS26KF5D (FRS26KF5DS5) POS. NO PART NO. DESCRIPTION 5304428402 A B C Auger-ice 5304404343 A B C Cam-drive 241561301 A B C Container-ice, bucket only 5304404346 A B C Drum-ice disp 241561401...

  • Page 18: Ice Maker

    Publication No: 5995429767 FRS26KF5D ICE MAKER INSTALLATION PARTS N58I115T 02/05...
  • Page 19 FRS26KF5D Publication No: 5995429767 ICE MAKER Model Index: A FRS26KF5D (FRS26KF5DS3) B FRS26KF5D (FRS26KF5DS4) C FRS26KF5D (FRS26KF5DS5) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976901 A B C Tube-water inlet, inlet valve, to ice maker 218976903 A B C Tube-water inlet, inlet valve, to filter 218976907 A B C...
  • Page 20 Publication No: 5995429767 FRS26KF5D ICE MAKER INSTALLATION PARTS N58I115T 02/05...
  • Page 21 FRS26KF5D Publication No: 5995429767 ICE MAKER Model Index: A FRS26KF5D (FRS26KF5DS3) B FRS26KF5D (FRS26KF5DS4) C FRS26KF5D (FRS26KF5DS5) POS. NO PART NO. DESCRIPTION 240363601 A B C Screw-shoulder 240542901 A B C Cap-water valve 5303207328 A B C Screw, hex washer head, 8-15A x 1.000, (2) 5303001549 A B C Clamp, 0.31 ID, steel, copper wtr line...

  • Page 22: Wiring Schematic

    Publication No: 5995429767 FRS26KF5D WIRING SCHEMATIC 02/05...

  • Page 23: Wiring Diagram

    FRS26KF5D Publication No: 5995429767 WIRING DIAGRAM 02/05 # Functional Parts * Non-Illustrated Parts...
