Frigidaire FRS26KF7A Factory Parts Catalog

Frigidaire FRS26KF7A Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS26KF7A:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Use and Care Manual, Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRS26KF7AB5
FRS26KF7A
FRS26KF7AQ5
FRS26KF7A
FRS26KF7AW5
FRS26KF7A
MARKET
North America
WIRING DIAGRAM - 240389607
OWNER'S GUIDE - 240389307
SERVICE DATA SHEET - 240389607
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
bisque
R134a
white
Publication No.
5995376877
020814
-EN/SERVICE/KHB
357
PARTS CATALO
VOLTS
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26KF7A
©2002, Electrolux Home Products Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26KF7A and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS26KF7A

Summary of Contents for Frigidaire FRS26KF7A

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS26KF7AB5 FRS26KF7A R134a black FRS26KF7AQ5 FRS26KF7A R134a bisque FRS26KF7AW5 FRS26KF7A R134a white MARKET North America WIRING DIAGRAM - 240389607 OWNER’S GUIDE - 240389307 SERVICE DATA SHEET - 240389607 SIDE BY SIDE REFRIGERATOR ELECTROLUX HOME PRODUCTS, INC Model No.

  • Page 2: Freezer Door

    Publication No. FRS26KF7A 5995376877 FREEZER DOOR 08/02...
  • Page 3 FRS26KF7A Publication No. 5995376877 FREEZER DOOR A = FRS26KF7A (FRS26KF7AB5) B = FRS26KF7A (FRS26KF7AQ5) C = FRS26KF7A (FRS26KF7AW5) POS. NO PART NO DESCRIPTION 240390606 A - - Gasket-frzr door,black ,magnetic 240390602 - B C Gasket-frzr door,white ,magnetic 240334201 A B C Bin-door,frzr-upper 240351601 A B C...

  • Page 4: Refrigerator Door

    Publication No. FRS26KF7A 5995376877 REFRIGERATOR DOOR 08/02...
  • Page 5 FRS26KF7A Publication No. 5995376877 REFRIGERATOR DOOR A = FRS26KF7A (FRS26KF7AB5) B = FRS26KF7A (FRS26KF7AQ5) C = FRS26KF7A (FRS26KF7AW5) POS. NO PART NO DESCRIPTION 240390605 A - - Gasket-refr door,black ,magnetic 240390601 - B C Gasket-refr door,white ,magnetic 240323001 A B C Bin-door,pseudo ,bottom 240326203 A B C...
  • Page 6 Publication No. FRS26KF7A 5995376877 CABINET 08/02...
  • Page 7 FRS26KF7A Publication No. 5995376877 CABINET A = FRS26KF7A (FRS26KF7AB5) B = FRS26KF7A (FRS26KF7AQ5) C = FRS26KF7A (FRS26KF7AW5) POS. NO PART NO DESCRIPTION 240435902 A B C Cover-air duct 240475902 A B C Cover-evap coil,lower 5303208309 A B C Plug-hole,factory test 14 # 240505801 A B C...
  • Page 8 Publication No. FRS26KF7A 5995376877 SHELVES 08/02...
  • Page 9 FRS26KF7A Publication No. 5995376877 SHELVES A = FRS26KF7A (FRS26KF7AB5) B = FRS26KF7A (FRS26KF7AQ5) C = FRS26KF7A (FRS26KF7AW5) POS. NO PART NO DESCRIPTION 240434604 A B C Trim-basket 240338802 A B C Shelf-freezer,flip-up 240338702 A B C Shelf-freezer,fixed wire 240338704 A B C Shelf-freezer,fixed wire 240324101 A B C...
  • Page 10 Publication No. FRS26KF7A 5995376877 CONTROLS 08/02...
  • Page 11 FRS26KF7A Publication No. 5995376877 CONTROLS A = FRS26KF7A (FRS26KF7AB5) B = FRS26KF7A (FRS26KF7AQ5) C = FRS26KF7A (FRS26KF7AW5) POS. NO PART NO DESCRIPTION 5308000010 A B C Fan Blade,red ,evaporator fan 5300157666 A B C Bushing-motor mtg,(2) 5303292396 A B C Bracket-motor mtg,front 13 # 240315803...
  • Page 12 Publication No. FRS26KF7A 5995376877 SYSTEM 08/02...
  • Page 13 FRS26KF7A Publication No. 5995376877 SYSTEM A = FRS26KF7A (FRS26KF7AB5) B = FRS26KF7A (FRS26KF7AQ5) C = FRS26KF7A (FRS26KF7AW5) POS. NO PART NO DESCRIPTION 240333603 A B C Condenser 218679607 A B C Block-evap coil,styrofoam ,(2) 218944001 A B C Drier-filter,R134a System 240346402 A B C Harness-wiring,machine compt...
  • Page 14 Publication No. FRS26KF7A 5995376877 DISPENSER 08/02...
  • Page 15 FRS26KF7A Publication No. 5995376877 DISPENSER A = FRS26KF7A (FRS26KF7AB5) B = FRS26KF7A (FRS26KF7AQ5) C = FRS26KF7A (FRS26KF7AW5) POS. NO PART NO DESCRIPTION 218976409 A B C Tube-water 218976901 A B C Tube-water inlet, inlet valve to ice maker 218976903 A B C Tube-water inlet, inlet valve to filter 218976907 A B C...

  • Page 16: Ice Container

    Publication No. FRS26KF7A 5995376877 ICE CONTAINER 08/02...
  • Page 17 FRS26KF7A Publication No. 5995376877 ICE CONTAINER A = FRS26KF7A (FRS26KF7AB5) B = FRS26KF7A (FRS26KF7AQ5) C = FRS26KF7A (FRS26KF7AW5) POS. NO PART NO DESCRIPTION 5304428402 A B C Auger-ice 5304404343 A B C Cam-drive 218815300 A B C Container-ice,bucket only 5304404346 A B C Drum-ice disp 5304422805...

  • Page 18: Ice Maker

    Publication No. FRS26KF7A 5995376877 ICE MAKER 08/02...
  • Page 19 FRS26KF7A Publication No. 5995376877 ICE MAKER A = FRS26KF7A (FRS26KF7AB5) B = FRS26KF7A (FRS26KF7AQ5) C = FRS26KF7A (FRS26KF7AW5) POS. NO PART NO DESCRIPTION 218976409 A B C Tube-water 218976901 A B C Tube-water inlet, inlet valve to ice maker 218976903 A B C Tube-water inlet, inlet valve to filter 218976907...

  • Page 20: Wiring Schematic

    Publication No. FRS26KF7A 5995376877 WIRING SCHEMATIC 08/02...

  • Page 21: Wiring Diagram

    FRS26KF7A Publication No. 5995376877 WIRING DIAGRAM # = Fast-moving Parts 08/02 * = Non-Illustrated Parts...
