PRODUCT NO.
BASE MODEL NO.
FRS26KF6CB0
FRS26KF6C
FRS26KF6CQ0
FRS26KF6C
FRS26KF6CW0
FRS26KF6C
MARKET
North America
ENERGY GUIDE - 240592225
OWNER'S GUIDE - 240389311
SERVICE DATA SHEET - 240389610
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
bisque
R134a
white
Publication No.
5995389169
030416
-EN/SERVICE/KHB
357
PARTS CATALO
VOLTS
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26KF6C
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26KF6C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRS26KF6C

Summary of Contents for Frigidaire FRS26KF6C

  • Page 1 PRODUCT NO. BASE MODEL NO. FRS26KF6CB0 FRS26KF6C FRS26KF6CQ0 FRS26KF6C FRS26KF6CW0 FRS26KF6C MARKET North America ENERGY GUIDE - 240592225 OWNER’S GUIDE - 240389311 SERVICE DATA SHEET - 240389610 ELECTROLUX HOME PRODUCTS, INC. P.O. BOX 212378, Augusta, GA 30917 SERIES COLOR R134a...

  • Page 2: Freezer Door

    Publication No. FRS26KF6C 5995389169 FREEZER DOOR 04/03...
  • Page 3 A = FRS26KF6C (FRS26KF6CB0) B = FRS26KF6C (FRS26KF6CQ0) C = FRS26KF6C (FRS26KF6CW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS26KF6C FREEZER DOOR PART NO DESCRIPTION 240390606 A - - Gasket-frzr door,black ,magnetic 240390602 - B C Gasket-frzr door,white ,magnetic...

  • Page 4: Refrigerator Door

    Publication No. FRS26KF6C 5995389169 REFRIGERATOR DOOR 04/03...
  • Page 5 A = FRS26KF6C (FRS26KF6CB0) B = FRS26KF6C (FRS26KF6CQ0) C = FRS26KF6C (FRS26KF6CW0) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FRS26KF6C REFRIGERATOR DOOR PART NO DESCRIPTION 240390605 A - - Gasket-refr door,black ,magnetic 240390601 - B C Gasket-refr door,white ,magnetic...
  • Page 6 Publication No. FRS26KF6C 5995389169 CABINET 04/03...
  • Page 7 A = FRS26KF6C (FRS26KF6CB0) B = FRS26KF6C (FRS26KF6CQ0) C = FRS26KF6C (FRS26KF6CW0) POS. NO 14 # 14A# 66B* 100* # = Fast-moving Parts * = Non-Illustrated Parts FRS26KF6C CABINET PART NO DESCRIPTION 240435902 A B C Cover-air duct 240475902 A B C...
  • Page 8 Publication No. FRS26KF6C 5995389169 SHELVES 04/03...
  • Page 9 A = FRS26KF6C (FRS26KF6CB0) B = FRS26KF6C (FRS26KF6CQ0) C = FRS26KF6C (FRS26KF6CW0) POS. NO 16A* 42A* 42A* 42A* 101* # = Fast-moving Parts * = Non-Illustrated Parts FRS26KF6C SHELVES PART NO DESCRIPTION 240434604 A B C Trim-basket 240338802 A B C...
  • Page 10 Publication No. FRS26KF6C 5995389169 CONTROLS 04/03...
  • Page 11 A = FRS26KF6C (FRS26KF6CB0) B = FRS26KF6C (FRS26KF6CQ0) C = FRS26KF6C (FRS26KF6CW0) POS. NO 13 # 21 # 137* 139* 199* # = Fast-moving Parts * = Non-Illustrated Parts FRS26KF6C CONTROLS PART NO DESCRIPTION 5308000010 A B C Fan Blade,red ,evaporator fan...
  • Page 12 Publication No. FRS26KF6C 5995389169 SYSTEM 04/03...
  • Page 13 A = FRS26KF6C (FRS26KF6CB0) B = FRS26KF6C (FRS26KF6CQ0) C = FRS26KF6C (FRS26KF6CW0) POS. NO 14 # 15 # 29 # 30 # 55 # 60 # 61 # # = Fast-moving Parts * = Non-Illustrated Parts FRS26KF6C SYSTEM PART NO...
  • Page 14 Publication No. FRS26KF6C 5995389169 DISPENSER 04/03...
  • Page 15 A = FRS26KF6C (FRS26KF6CB0) B = FRS26KF6C (FRS26KF6CQ0) C = FRS26KF6C (FRS26KF6CW0) POS. NO 38A# 38C* 38C* # = Fast-moving Parts * = Non-Illustrated Parts FRS26KF6C DISPENSER PART NO DESCRIPTION 218976409 A B C Tube-water 218976901 A B C Tube-water inlet, inlet valve to ice maker...

  • Page 16: Ice Container

    Publication No. FRS26KF6C 5995389169 ICE CONTAINER 04/03...
  • Page 17 A = FRS26KF6C (FRS26KF6CB0) B = FRS26KF6C (FRS26KF6CQ0) C = FRS26KF6C (FRS26KF6CW0) POS. NO 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts FRS26KF6C ICE CONTAINER PART NO DESCRIPTION 5304428402 A B C Auger-ice 5304404343 A B C...

  • Page 18: Ice Maker

    Publication No. FRS26KF6C 5995389169 ICE MAKER 04/03...
  • Page 19 A = FRS26KF6C (FRS26KF6CB0) B = FRS26KF6C (FRS26KF6CQ0) C = FRS26KF6C (FRS26KF6CW0) POS. NO 11 # 12 # 13 # 15 # 17 # 55 # # = Fast-moving Parts * = Non-Illustrated Parts FRS26KF6C ICE MAKER PART NO DESCRIPTION...

  • Page 20: Wiring Schematic

    Publication No. FRS26KF6C 5995389169 WIRING SCHEMATIC 04/03...

  • Page 21: Wiring Diagram

    FRS26KF6C Publication No. 5995389169 WIRING DIAGRAM # = Fast-moving Parts 04/03 * = Non-Illustrated Parts...
