Bathtub Faucet
Model TBXM1B V201
For best results, be sure to follow the installation intructions and use the product only as described in the manual.
Installation Manual
Important Safeguards............... 1
Replacement Parts...........................
Before installation...........................
Specifications ..............................
Rough-In.......................................
Installation procedure............... 5
Check the product...........................
2
2
3
3
4
9
13
14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Toto NEOREST TBXM1B V201
Summary of Contents for Toto NEOREST TBXM1B V201
-
Page 1: Table Of Contents
Installation Manual Bathtub Faucet Model TBXM1B V201 For best results, be sure to follow the installation intructions and use the product only as described in the manual. Important Safeguards…………… 1 Replacement Parts……………………… Before installation……………………… Specifications ………………………… Rough-In………………………………… Installation procedure…………… 5 Trial Run and Temperature Adjustment …10 Check the product………………………... -
Page 2: Important Safeguards
Important Safeguards (For your safety please follow the instructions below) Read the “Important Safeguards” section thoroughly before installing the product. Read the “Important Safeguards” section thoroughly before installing the product. The following symbols indicate safe and proper use of the product. Failure to observe them may result in injury or property damage. -
Page 3: Replacement Parts
Caution Do not strike violently. If the product is broken, property damamge, scalding and other injuries may occur due to water leakage. Do not install the product outdoors or in a place Do Not Freezing where freeze likely occurs. Parts may be broken and water may leak to give damage to your property by wetting household goods. -
Page 4: Before Installation
Before installation Set the hot water supply temperature at least 10°C higher than the temperature of the water to be used. Make sure the water pressure is higher, or matches hot water output pressure. If flow pressure exceeds 0.5 MPa, a pressure reducing valve must be installed. Specifications Part No. -
Page 5: Rough-In
Rough-In 120.5 95.5 133.5 (mm) -
Page 6: Installation Procedure
Installation procedure Installation procedure Remove the protective covers (A). Make sure the connectors does not drop below the frame (B). Fasten the shower hanger (C) to the base plate (D). After fastening the shower hanger, remove the cardboard (E). 3.0mm... - Page 7 Join the connectors according to color. Fasten the base plate (D). To prevent bolt (F) burn-in, do not use an impact wrench. To prevent warping, tighten tentatively before tightening firmly. 3.0mm...
- Page 8 Install the shower base (G) and the cover plate (H). Connect the shower head (I).
- Page 9 Check the thickness of the tiles. Please make the choice of included replacement parts based on the thickness of the tiles. The parts listed in the thick bordered table are included with this product. 10mm 10 15mm 15 20mm 20 25mm Connect the handle (J).
- Page 10 Connect the spout (N). Depending on the thickness of the tiles, replace the adapter (O) if necessary. 3.0mm...
-
Page 11: Trial Run And Temperature Adjustment
Trial Run and Temperature Adjustment 1. Trial Run Make sure the water from the spout (N) and the shower (I) is released normally for one minute. - Page 12 2. Temperature Adjustment 1. Trial Run Adjust the temperature control handle (J). 2.5mm 2.5mm...
- Page 13 3. Cleaning the filter 1. Trial Run Remove the cap, the set screw of the handle and then the handle itself. Remove the shower head, the locknut, 2.5mm the gasket, and then the cover plate. 2.5mm Close 2 stop valves. Close Remove 2 check valve units.
- Page 14 Reinstall the check valve units in their original position. Open 2 stop valves. Open Reinstall in reverse order. * Be sure to check that the switch can be pressed smoothly after attaching 2.5mm 2.5mm...
-
Page 15: Check The Product
Check the product Check the following items after installation. Hand Shower Handle Connector Spout Body Filter Spout Stop Valve Spout Filter Checking the flow rate Checking for water leak Check for any water leak. If the flow rate is low, check the following points: Are the hand shower and the hose connected Is the filter clogged with dust? fast? - Page 16 2010.6 03F02 T3E...
