Wen GN6000 Instruction Manual page 36

ENGINE
NO. PART NO.
1 56500-017
2 56500-102
3 56500-103
4 56500-104
5 56500-105
6 56500-106
7 56500-107
8 56500-108
9 56500-109
10 56500-110
11 56500-111
12 56500-112
13 56500-113
14 56500-114
15 56500-115
16 56500-116
17 56500-117
18 56500-022
19 56500-119
20 56500-1120 Shroud Mounting Clasp
GN6000-
21
122
22 56500-123
23 56500-124
24 56500-125
25 56500-126
26 56500-127
27 56500-128
28 56500-129
29 56500-130
30 56500-131
31 56500-132
32 56500-133
33 56500-134
34 56500-135
36
EXPLODED VIEW & PARTS LIST
DESCRIPTION
Bolt, M6×25
Valve Cover
Breather Hose
Gasket, Valve Cover
Rivet, M3×8
Breather Plate
Breather Valve
Inner Cover, Valve Cover
Screw, M5×12
Gasket, Valve Cover
Rocker Arm Assembly
Rocker Arm Base
Valve Locker
Valve Spring Seat
Valve Spring
Intake Valve Seal
Nut, M8
Bolt, M6×12
Shroud
Cylinder Head
Spark Plug F6TC (NGK
BP6ES)
Stud
Stud, M6×90
Gasket, Carburetor
Insulator
Insulator
Gasket, Carburetor
Carburetor
Gasket Carburetor
Air Filter Assembly
Air Filter Base Assembly
Air Filter Baffle
Air Filter Element
Air Filter Cover
QTY. NO. PART NO.
7 35 56500-136
1 36 56500-137
1 37 56500-138
1 38 56500-139
2 39 56500-140
1 40 56500-141
1 41 56500-142
1 42 56500-143
4 43 56500-144
1 44 56500-145
2 45 56500-146
1 46 56500-147
4 47 56500-148
2
48 56500-149
2
49 56500-150
1
50 56500-151
4
51 56500-1151
15
52 56500-152
1
53 56500-153
1
54 56500-155
1
55 56500-156
56 56500-157
1
57 56500-158
2
58 56500-159 Oil Seal, 25×41.25×6mm
2
59 56500-160
60 56500-161
1
61 56500-163
1
62 56500-162
1
63 56500-164
1
64 56500-165
1
65 56500-166
1
66 56500-167
1
67 56500-168
1
68 56500-169
1
1
DESCRIPTION
Bolt
Nut, M6
Stud, M8×60
Gasket, Cylinder Head
Pin, 10×14mm
Intake Valve
Exhaust Valve
Piston Ring Set
Push Rod
Tappet
Piston
Circlip
Piston Pin
Connecting Rod Assem-
bly
Oil Sensor
Bolt, M6×18
Crankshaft Bearing
Crankshaft Assembly
Woodruff Key
Camshaft
Pin, 8×14mm
Gasket, Crankcase
Crankcase Cover
Bolt, M8x35
Dipstick Assembly
Dipstick
O-Ring, 15.8×2.5mm
Governor Gear
Governor Gear Shaft
O-Ring, 5.2x1.9mm
Oil Seal, 6x11x4mm
Cotter Pin
Governor Lever
QTY.
1
2
4
1
2
1
1
1
2
2
1
2
1
1
1
2
2
1
1
1
2
1
1
1
8
1
1
1
1
1
1
1
1
1
