DEMO MANUAL DC2028A
Dc2028A DetAiLs – top
Table 1. DC2028A - Default Switch Configuration (Default Position Shown in Grey in the Figure Above)
REFERENCE DESIGNATOR
JP3 (Bottom)
S1
16
SIGNAL NAME
A0, A1, A2
DIP Switch Used to Set the Address Offset
CONTROL0
Switch Used to Enable/Disable the CONTROL0
Input Pin of LTC2977
USAGE
DEFAULT
OPEN
RUN
