- Page 1 Manual E / Dp / HDp Series...
-
Page 2: Table Of Contents
Contents Part names and functions of control panel - - - - - - - - Operating procedure - - - - - - - - - - - - - - - - - - - - - - - - Model button control guide Replacement and maintenance - - - - - - - - - - - - - - - -... -
Page 3: Part Names And Functions Of Control Panel
Part Names & Functions of Control panel Protection cap Lighting grip Modeling(Halogen) lamp Stand stud joint part Flash tube(Xenon Tube) Handle for fastening Locking knob for accessory assembly Wireless control port Slave sensor Control panel... - Page 4 TEST button : To test or to manually MODEL button : discharge the flash. Modeling lamp control dial : Controls E series : ON/OFF Dp/HDp series : RED, GREED, OFF the brightness of the modeling lamp. O.C Signal : Overcharge signal lamp Flash power control dial : Controls the turns on when over charged.
-
Page 5: Operating Procedure
Operating procedure The settings MODEL / BEEP / CELL buttons are OFF and the modeling & flash power dials are at a minimum. Install the modeling lamp to the flash unit. Be careful not to allow any fingerprint or dust stains on the lamp. Connect the synchro cord to the synchro socket. -
Page 6: Replacement And Maintenance
Replacement and maintenance A. How to replace a modeling lamp. Screw type (Base : E-11) Turn OFF the power and unplug the power cord from the AC socket. Turn it counterclockwise and remove the modeling lamp. Turn the new modeling lamp clockwise to install. (Please make sure your hands are dry.) Be careful not to allow any fingerprints, dust or stains on the lamp. -
Page 7: Technical Specifications
Technical Specifications E series Dp series HDp series Power Control 6steps in 1/10 f-stops Power Range Display 4.0 ~ 10 Digital Flash Head Color Temperature 5,500K (±150K) Over Temperature Display (E0) on the FND / Warning Buzzer Warning Over Charge Warning... -
Page 8: Notice
Never open this unit, high voltage inside. No internal serviceable parts. The separation distance of the product is 0.5m at least. Fomex accepts no responsibility for electric shock or equipment damage due to unauthorized modification and repairs. Keep out of children’s reach. -
Page 9: Halogen Lamps Safety Measures
Check if the power cord is properly connected. There’s no The Power Supply is interrupted Check if the contact of the socket reaction at all. is loose. Check if the fuse is blown. Other trouble Please contact your local dealer or contact FOMEX directly. shoots... -
Page 10: Warranty
Or, it will be replaced with a new product or a functionally equivalent refurbished product. This warranty applies only to products manufactured by Fomex that can be identified by the trademark, trade name, or logo affixed to the product. - Page 11 7th Floor, Seongsui-ro, Seongdong-gu, Seoul Korea 04787 Tel: +82 2 545 0004 Fax: +82 2 3444 9399 E-mail: info@fomex.com VER.202107(EN)
