Summary of Contents for fomex flexible LED FL1200
- Page 1 LED FL1200...
-
Page 2: Table Of Contents
Contents .................. In the box ..............Accessories (Optional) ................. How to connect ............... How to install X-Mount ..............How to use Controller ......How to install Accessory (Softbox or Barn Door) ............How to install Clamp Shoe ................Specification ..................Notice ................... -
Page 3: In The Box
In the box FL 1200 Kit LED Mat 1’x2’ (30x58cm) X-Mount Bracket Controller Kit Bag Power Supply Power Cord(5m) Output Cable(2m) Extension Cable(5m) Clamp Shoe Accessories (Optional) Softbox with Quick Frame Barn Door with Quick Frame Boom Pole 3 Sections Shoulder Strap... -
Page 4: How To Connect
How to connect Please connect to Power Supply in the following order. Output Cable(2m) ※ Extension Cable(5m) LED Mat Controller Power Supply Power Cord(5m) ※ Please use only the supplied extension cable from us when using the extension cable. How to install X-Mount Insert X-Mount in the rear corner of LED Mat Clips. -
Page 5: How To Use Controller
How to use Controller DETAIL How to use buttons To Set LOCK Mode : 2~3 seconds press ‘MODE ’ button once, on the LCD display window 'LOCK' displays and is set. (Note : when ‘LOCK’ mode is set, CCT and DIM can’t be changed) To Unlock : In ‘LOCK’... -
Page 6: How To Install Accessory (Softbox Or Barn Door)
Turn on/off with ON/OFF switch on the left. Adjust color temperature with the left CCT dial. The value from 2700k to 6500k will be displayed on the LCD display window. Connect the Light output cable (2m) to light output port, then connect the cable to LED Mat. Adjust brightness with the right DIM dial. -
Page 7: Specification
Specification Model FL 1200 Light Output 3800lux @1m; 2700K / 4000lux @1m; 6500K Power Consumption 120W CRI / TLCI CRI 96~98 / TLCI 98 Color Temperature 2700K- 6500K Dimmer 0~100% DIM / DMX 512 / Manual Color Temperature 100K Steps Light Output Connector 4Pin Waterproof IP Rating... -
Page 8: Notice
Notice 1. Must use supplied Power Supply only. Otherwise, it may cause a problem. 2. Do not use in rain or in a humid place. 3. Do not close to flammable objects. 4. Operating temperature range is 0°C ~ 40°C. 5. - Page 9 Inapplicable Warranty 1. Expired warranty period. 2. Breakage or damage caused by inappropriate usage, repair, maintenance and accident. 1) Installation and removal with improper external equipment or improper usage. 2) Fall and external shock. 3) Exposure to the extreme environment of abnormal temperature, a solvent, an acid, a base, a flood and a humid.
- Page 10 Unit701, 31-18Gil, Seongsui-ro, Seongdong-gu, Seoul 04787 Korea Tel : +82 2 545 0004 Fax : +82 2 3444 9399 E-mail : info@fomex.com...
