- Page 1 RollLite RL21-75 / RL31-100 / RL31-150...
-
Page 2: Table Of Contents
Contents In the Box Controller Overview Set Up X-Mount & How to Connect How to Install Clamp Shoe Technical Specifications Notice & Warranty Inapplicable Warranty Please read this operation instruction before using the product. Stop using this product when abnormal operation is detected and contact the authorized dealer of its purchase location. -
Page 3: In The Box
In the Box RL21 Kit X-Mount Bracket Controller Kit Bag RL21-75 (2m) (5m) Extension Cable Power Supply Power Cord(5m) Clamp Shoe RL31 Kit X-Mount Bracket Controller Kit Bag (2m) RL31-100 / RL31-150 (5m) Extension Cable Power Supply Power Cord(5m) Clamp Shoe... -
Page 4: Controller Overview
Controller Overview DC Input ON/OFF Switch DMX Out USB ( 5V DC Out ) DMX In ( If DMX connection works properly, the status indicator will turn on green ) CCT Knob – Color Temperature Adjustment Output Port Dimmer Knob - Brightness Adjustment Battery Plate ( Standard: V-Mount, Optional: Gold Mount ) DETAIL Button Control Guide... -
Page 5: Set Up X-Mount & How To Connect
Set Up X-Mount The included X-Mount frame can be quickly and easily mounted to the RollLite using the push-pin one-touch locking inserts. How to Connect Please connect the power supply or battery in the following order. Power Supply Power Cord Extension Cable Controller Battery... -
Page 6: How To Install Clamp Shoe
How to Install Clamp Shoe Mount the clamp with the Clamp Shoe to a light stand then, the controller. -
Page 7: Technical Specifications
Technical Specifications Spec. RL21-75 RL31-100 RL31-150 Light Output 1500lux @1m; 2700K, 2000lux @1m; 2700K, 3100lux @1m; 2700K, 1720lux @1m; 6500K 2300lux @1m; 6500K 3500lux @1m; 6500K Power Consumption 100W 150W CRI / TLCI CRI 96~98 / TLCI 98 Color Temperature 2700K~6500K Dimmer 0~100% DIM / DMX 512 / Manual... -
Page 8: Notice & Warranty
Fomex product’s use. If a defect of the product arises and a valid claim is received within the warranty period, Fomex will either repair the defect at no charge, using new or refurbished replacement parts, or exchange the product with a product that is new or which has been manufactured from new or serviceable used parts and is at least functionally equivalent to the original product. -
Page 9: Inapplicable Warranty
Inapplicable Warranty 1. Expired warranty period 2. Breakage or damage caused by inappropriate usage, repair, maintenance and accident. 1) Installation and removal with improper external equipment or improper usage. 2) Damage to the product caused by external fault or any accident. 3) Exposure to the extreme environment such as abnormal temperature, a solvent, an acid, a base, a flood and a humidity. - Page 10 Unit701, 31-18Gil, Seongsui-ro, Seongdong-gu, Seoul Korea 04787 Tel: +82 2 545 0004 Fax: +82 2 3444 9399 E-mail: info@fomex.com All product specifications are subject to change without notice. VER.201903...
