Summary of Contents for LG GRL1960TQA
-
Page 2: Table Of Contents
Table of contents Introduction Entry Important safety instruction Identification of parts Installation Where to install Door removal Door replacement Feed water pipe installation Height adjustment Operation Starting Adjusting the temperatures and functions Shelf Egg box Humidity control in the vegetable compartment Convert into a vegetable or meat compartment Location of foods Suggestion on... -
Page 3: Introduction
Introduction Entry The model and serial numbers are found on the inner case or back of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. -
Page 4: Identification Of Parts
Introduction Child entrapment DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer: warning Take off the doors but leave the shelves in place so that children may not easily climb inside. The appliance is not intended for use by young children or infirm persons without supervision. -
Page 5: Installation
Installation Where to Install 1. Place your appliance where it is easy to use. Select a good location 2. Avoid placing the unit near heat sources, direct sunlight or moisture. 3. To ensure proper air circulation around the fridge -freezer, please maintain sufficient space on both the sides as well as top and maintain at least 2 inches (5 cm) from the rear wall. -
Page 6: Door Removal
Installation Door removal Electric Shock Hazard Warning Disconnect electrical supply to refrigerator before installing. Failure to do so could result in death or serious injury. If your access door is too narrow for the refrigerator to pass through, remove the Lower cover refrigerator door and pass the refrigerator laterally. -
Page 7: Door Replacement
Installation Pass the refrigerator laterally through the access Pass the refrigerator door as shown in the right figure. TEMP TEMP Door replacement Mount them in the reverse sequence of removal after they pass through the access door. Feed water pipe installation Before Automatic ice maker operation needs water pressure of 147~834 kPa (1.5~8.5 installation... -
Page 8: Height Adjustment
Installation Height adjustment If the freezer Level the door by inserting flat ( - type) driver into the groove of the left height adjusting screw and rotate it clockwise ( ). compartment door is lower than the refrigerator compartment door If the freezer Level the door by inserting flat ( - type) driver into the groove of the right height compartment door... -
Page 9: Operation
Operation Starting When your refrigerator is first installed, allow it to stabilize at normal operating temperatures for 2-3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting the temperatures and functions Function display board EXPRESS DISPENSER... - Page 10 Operation You can adjust temperature of and freezer room and refrigerator room. C) ➔ Middle (-19 FREEZER How to adjust the C) ➔ Middle strong (-22 temperature in C) ➔ Strong (-23 TEMP the freezer C) ➔ Weak (-15 compartment Middle weak (-17 C) ➔...
- Page 11 Operation The icemaker can automatically make 8 pieces of ice cubes at anyone time, Automatic ice approximately 80 pieces per day. However these quantities may vary according to maker certain conditions. E.g. the duration and amount of times the refrigerator door is opened.
- Page 12 Operation The other Door open warning functions 3 times of warning sounds at the interval of 30 seconds if a minute passes with the door of refrigerator and the hombar door opened or completely closed. Please contact with the local service center if warning continue to sound even after closing the door.
- Page 13 Operation 6 Filter condition FILTER ST TER STATUS After 6 months have passed the filter change icon will appear (filter replacement on the display. cycle) display function Cautions Throw away the ice (about 20 pieces) and water (about 7 glasses) first made after refrigerator installation.
-
Page 14: Shelf
Operation Shelf Folding Shelf You can store taller items such as a gallon container or bottles by simply pushing in front half of shelf underneath back half of shelf. Pull toward you to return to a full shelf. Egg box You can move the egg box to wherever you want. -
Page 15: Humidity Control In The Vegetable Compartment
Operation Humidity control in the vegetable compartment The humidity can be controlled by adjusting the humidity control switch to the left/right when storing vegetables or fruits. High humidity HUMIDITY CONTROL HIGH L O W Low humidity H I G HUMIDITY CONTROL HIGH Convert into a vegetable or meat compartment The bottom drawer in the refrigerator can be converted into a vegetable or meat... -
Page 16: Suggestion On Food Storage
Suggestion on food storage Location of foods (Refer to identification of parts) Snack drawer Store small foods such as bread, snacks, etc.. Freezer Store various frozen foods such as meat, fish, compartment ice cream, frozen snacks, etc.. shelf Store small packed frozen food. Freezer Temperature is likely to increase as door compartment... -
Page 17: Storing Foods
Suggestion on food storage Storing foods Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, and melons. -
Page 18: Care And Maintenance
Care and maintenance How to dismantle parts NOTE Dismantling is done in the reverse sequence of assembly. • Be sure to unplug the power plug before dismantling and assembly. Never apply severe force to dismantle parts. Parts may be damaged. Freezer Separate the lamp by pulling it out (➂) while compartment... - Page 19 Care and maintenance To remove the lamp cover, press the protrusion under the lamp cover to the front and Lamp in then pull the lamp cover out. refrigerator Turn the bulb counterclockwise. Max. 40 W bulb for refrigerator is used and can be compartment purchased at a service center.
-
Page 20: General Information
Care and maintenance 0 Suggestion on food storage General information During average length vacations, you will probably find it best to leave the refrigerator Vacation time in operation. Place freezable items in freezer for longer life. When you plan not to operate, remove all food, disconnect the power cord, clean the interior thoroughly, and leave each door OPEN to prevent odor formation. -
Page 21: Trouble Shooting
Care and maintenance Trouble shooting Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Occurrence Possible cause Solution Runing of refrigerator... - Page 22 Care and maintenance Occurrence Possible cause Solution Refrigerator Thermostat is keeping the refrigerator This is normal. The refrigerator goes on compressor at a constant temperature. and off to keep the temperature constant. does not run. Temperatures are too cold Temperature in the Set the freezer control to a warmer Freezer control is set too cold freezer is too cold...
- Page 23 Care and maintenance Possible cause Solution Occurrence Sound and noise Louder sound Today’s refrigerators have increased It is normal for sound levels to be higher. levels when storage capacity and maintain more refrigerator is on. even temperatures. Louder sound Refrigerator operates at higher pressures This is normal.
- Page 24 Care and maintenance Occurrence Possible cause Solution Odors in refrigerator Clean interior with sponge,warm water Interior needs to be cleaned. and baking soda. Cover food completely. Food with strong odor is in the refrigerator. Some containers and wrapping materials Use a different container or brand of produce odors.
- Page 25 Care and maintenance Occurrence Possible cause Solution Ice has melted and frozen around auger Remove ice storage bin, and thaw and Dispenser will not dispense due to infrequent use, temperature the contents. Clean bin, wipe dry and ice. fluctuations and/or power outrages. replace in proper position.
- Page 26 P/NO : MFL35906608 Printed in Korea...
