Summary of Contents for LG GR-L207QRFA
- Page 2 (In the UK Only) The wires in this mains lead are coloured in accordance with the following code : As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows : The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is marked with the letter E or by the earth symbol(b) or coloured Green or Green and Yellow.
- Page 3 Table of contents...
-
Page 4: Important Safety Instruction
Entry The model and serial numbers are found on the inner case or back of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. -
Page 5: Identification Of Parts
DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer: Take off the doors but leave the shelves in place so that children may not easily climb inside. The appliance is not intended for use by young children or infirm persons without supervision. -
Page 6: Where To Install
Where to Install 1. Place your appliance where it is easy to use. 2. Avoid placing the unit near heat sources, direct sunlight or moisture. 3. Air must circulate properly around your appliance to ensure efficient operation. If your appliance is placed in a recessed area in the wall, allow at least a 12 Inches (30 cm) or greater clearance above the appliance and 2 inches (5 cm) or more... -
Page 7: Door Removal
Door removal Electric Shock Hazard Disconnect electrical supply to refrigerator before installing. Failure to do so could result in death or serious injury. If your access door is too narrow for the refrigerator to pass through, remove the refrigerator door and pass the refrigerator laterally. Remove the lower cover by lifting upward, and then pull up the feed water tube while pressing area... -
Page 8: Door Replacement
Pass the refrigerator laterally through the access door as shown in the right figure. Door replacement Mount them in the reverse sequence of removal after they pass through the access door. Feed water pipe installation Automatic ice maker operation needs water pressure of 147~834 kPa (1.5~8.5 kgf/cm ) (That is, an instant paper cup (180 cc) will be fully filled within 3 sec.). -
Page 9: Height Adjustment
Height adjustment Level the door by inserting flat ( - type) driver into the groove of the left height adjusting screw and rotate it clockwise ( ). Level the door by inserting flat ( - type) driver into the groove of the right height adjusting screw and rotate it clockwise ( ). -
Page 10: Adjusting The Temperatures And Functions
Starting When your refrigerator is first installed, allow it to stabilize at normal operating temperatures for 2-3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting the temperatures and functions... - Page 11 You can adjust temperature of and freezer room and refrigerator room. Middle(-19 C) Middle strong(-22 Middle(3 C) Middle strong(2 Whenever pressing button, setting is repeated in the order of (Middle) (Middle Strong) (Strong) (Weak) The actual inner temperature varies depending on the food status, as the indicated setting temperature is a target temperature, not actual temperature within refrigerator.
- Page 12 The icemaker can automatically make 8 pieces of ice cubes at anyone time, approximately 80 pieces per day. However these quantities may vary according to certain conditions. E.g. the duration and amount of times the refrigerator door is opened. The Ice making proceeds ceases automatically when the ice storage bin is full. If you choose not to use the automatic ice making function, repositioned the icemaker selection switch to the off position or the on position for reselection.
-
Page 13: Door Open Warning
Door open warning 3 times of warning sounds at the interval of 30 seconds if a minute passes with the door of refrigerator and the hombar door opened or completely closed. Please contact with the local service center if warning continue to sound even after closing the door. - Page 14 As demonstrated below, it displays the months left in units of 30 days until the filter replacement is required, starting from when the refrigerator power usage is authorized. After 6 months, the following sentence and part of the LED. "Press for 3 seconds after replacing filter" After 6 months have passed, and if the filter has been replaced or you want to reset the filter condition display, press the filter replacement button for more than 3 seconds and it will reset to the initial Power On state.
-
Page 15: Refreshment Center (Applicable To Some Models Only)
Refreshment center (Applicable to some models only) Open the refreshment center door. You can access the refreshment center without opening refrigerator door and thus saving electricity. Inner lamp is lit in refrigerator compartment when the refreshment center door opens. Thus it is easy to identify the contents. Never use the refreshment center door as a chopping board and take care not to damage it with sharp tools. -
Page 16: Shelf (Applicable To Some Models Only)
Shelf (Applicable to some models only) You can store taller items such as a gallon container or bottles by simply pushing in front half of shelf underneath back half of shelf. Pull toward you to return to a full shelf. Wine holder (Applicable to some models only) Bottles can be stored laterally with this wine corner. -
Page 17: Humidity Control In The Vegetable Compartment
Humidity control in the vegetable compartment The humidity can be controlled by adjusting the humidity control switch to the left/right when storing vegetables or fruits. Close Open Close Open Convert into a vegetable or meat compartment (Applicable to some models only) The bottom drawer in the refrigerator can be converted into a vegetable or meat compartment The meat compartment maintains the temperature at a lower point than the... -
Page 18: Miracle Zone Temperature Transition Corner (Applicable To Some Models Only)
Miracle Zone Temperature Transition Corner (Applicable to some models only) By pressing the button, store vegetables, fruits or other types of food such as meat to be defrosted, raw fish, etc. Temperature Change at Miracle Zone (Applicable to some models only) You can select optimum temperature range depending on types of foods stored. -
Page 19: Location Of Foods
Location of foods (Refer to identification of parts) Store wine. Store small foods such as bread, snacks, etc.. Store various frozen foods such as meat, fish, ice cream, frozen snacks, etc.. Store small packed frozen food. Temperature is likely to increase as door opens. -
Page 20: Storing Foods
Storing foods Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, and melons. -
Page 21: How To Dismantle Parts
How to dismantle parts Dismantling is done in the reverse sequence of assembly. • Be sure to unplug the power plug before dismantling and assembly. Never apply severe force to dismantle parts. Parts may be damaged. Separate the lamp by pulling it out ( ) while slightly striking ( ) and rotating ( ) the lamp cover. - Page 22 To remove the lamp cover, press the protrusion under the lamp cover to the front and then pull the lamp cover out. Turn the bulb counterclockwise. Max. 40 W bulb for refrigerator is used and can be purchased at a service center. Separate the bin ( ) to upward.
-
Page 23: General Information
General information During average length vacations, you will probably find it best to leave the refrigerator in operation. Place freezable items in freezer for longer life. When you plan not to operate, remove all food, disconnect the power cord, clean the interior thoroughly, and leave each door OPEN to prevent odor formation. -
Page 24: Troubleshooting
Trouble shooting Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Runing of refrigerator Refrigerator control is off. Refrigerator is in defrost cycle. - Page 25 Thermostat is keeping the refrigerator at a constant temperature. Temperatures are too cold Freezer control is set too cold Refrigerator control is set too cold. Refrigerator control is set too cold. Meat should be stored at a temperature just below the freezing point of water (32˚F, 0˚C) for maximum fresh storage time.
- Page 26 Sound and noise Today’s refrigerators have increased storage capacity and maintain more even temperatures. Refrigerator operates at higher pressures during the start of the ON cycle. Floor is uneven or weak. Refrigerator rocks on the floor when it is moved slightly. Items placed on the top of the refrigerator are vibrating.
- Page 27 Odors in refrigerator Interior needs to be cleaned. Food with strong odor is in the refrigerator. Some containers and wrapping materials produce odors. Opening/Closing of doors/Drawers Food package is keeping door open. Door was closed too hard, causing other door to open slightly. Refrigerator is not level.
- Page 28 Ice has melted and frozen around auger due to infrequent use, temperature fluctuations and/or power outrages. Ice cubes are jammed between the ice maker arm and back of the bin. Ice cubes are frozen together. Ice cubes that have been purchased or made in some other way have been used in the dispenser.
