- Page 1 Installation Guide IntelliHaul Integrated Towing Assistance Package IOB 7” Radio Wireless Camera Kit...
-
Page 2: Prior To Installation
Installation Guide 19367548 Integrated Towing Assistance Package Prior to Installation Cover all surfaces with tape or plastic protection film to protect against scratching and damage. EchoMaster is in no way responsible for any damage that may occur during installation. This product has been validated in the vehicles listed on the application guide only. Care must be taken when installing this accessory to ensure damage does not occur to the vehicle. -
Page 3: Recommended Tools
Installation Guide 19367548 Integrated Towing Assistance Package Vehicle Preparation & Protection CAUTION Consult your vehicle owner’s manual to disconnect the battery. Do not disconnect ANY airbag connectors or indicators. Doing so may result in activating a diagnostic code. These codes will require the dealer to perform the reset procedure which may incur a reset fee. - Page 4 Installation Guide 19367548 Integrated Towing Assistance Package Removing the Radio (IOB 7” screen) Step 1 Using a nylon trim removal tool, remove the LCD display trim panel. Step 2 Remove the 4 x 7mm bolts from around the LCD display. Once screws have been removed, remove the unit from the dash.
- Page 5 Installation Guide 19367548 Integrated Towing Assistance Package Removing the Door Sill(s) Step 1 Remove passenger front and rear door sill plastics. Set aside. Route Camera Extension Harness Route 16-pin main camera extension cable down below the dash. This should pass through hole located in the back portion of the radio cavity and exit from bottom of dash.
- Page 6 Installation Guide 19367548 Integrated Towing Assistance Package Route Camera Extension Harness (Rear) Route extension harness(s) to the rear of the vehicle (passenger side only). Remove 1 x 7mm bolt from C-pillar panel and remove panel. Route wire to bottom corner of rear window and secure with zip ties. email - gmsupport@echomaster.com (US) - tel - 866-766-2267 Illustrations are typical and may not match exact vehicle details...
- Page 7 Installation Guide 19367548 Integrated Towing Assistance Package Installing Wireless Receiver Plug in wireless receiver module. Use double sided adhesive tape to mount to the glass WARNING Be sure to orient the plug correctly otherwise damage will occur. Use two sided tape to fasten to rear window.
-
Page 8: Module Connections
Installation Guide 19367548 Integrated Towing Assistance Package 2018-19 (only) Module Connections t-harness for VBM Connect 8-pin power t-harness, the 16-pin main camera extension cable, the 4-pin VBM t-harness (2018-19), and the LVDS teal colored connector to the module. Fasten harnesses to the bracket using zip ties through the holes provided. - Page 9 Installation Guide 19367548 Integrated Towing Assistance Package LVDS Connection Disconnect the Grey and Gold connector from the radio module along with the black LVDS connector with the Blue cable. Connect the Grey and Gold connector t-harness to the radio module and the radio harness. Connect the loose male LVDS connector into female EchoMaster connector.
- Page 10 Operation/Installation Guide 19367548 Integrated Towing Assistance Package Accessing Camera and Installation settings Press and hold the “HOME” button for more than 2 seconds to enter the TC camera view (input 3). The camera view is accessible after 7 seconds while in reverse. Press and hold the “HOME”...
-
Page 11: Wiring Diagram
Installation Guide 19367548 Integrated Towing Assistance Package Wiring Diagram email - gmsupport@echomaster.com (US) - tel - 866-766-2267 Illustrations are typical and may not match exact vehicle details. - Page 12 AGREEMENT: End user agrees to use this product in compliance with the instructions and terms of use above and with all State and Federal laws. EchoMaster provides instructions and safety warnings with respect to this product and disclaims all liability for any use not in conformity with those instructions or other misuse of its product.
