21/11/2011
Ins-30085 Net2Air Ethernet bridge
Technical Support
01273 811011
Technical help is available:
Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/
Net2Air wireless communication
The access control unit connects to the Net2 software running on the PC using Paxton Net2Air proprietary wireless
technology. A Net2Air bridge enables communication from the Net2 software to the Paxton family of wireless
products.
Radio signals do not always behave as you might expect. For example, a mobile phone that displays a full signal
on one part of the site will lose signal completely only a few metres away. These problems can be addressed by
using the Net2 site surveyor kit (690-200).
See also:
XAN1095 - Net2 nano - How does it work? < http://paxton.info/974 >
X
AN1096 - How to plan a Net2 nano installation < http://paxton.info/975 >
X
Ins-30096 - Net2Air site surveyor < http://paxton.info/1015 >
Radio frequency
The unit is set to channel 11 (2.405 GHz). This product should not be installed within 3 metres of any other radio
(LAN/Wi-Fi) equipment to reduce the possibility of interference.
Net2 Server
Software - Requires Net2 v4.14 or later.
Enclosure
The unit should be mounted vertically in the
supplied base to achieve the optimum range.
Power over Ethernet.
This unit can be powered over the ethernet
link with POE compatible hardware.
Net2Air Ethernet bridge
The unit is powered from a
supplied mains power adaptor
via a plug connection.
Access hole for reset button
TCP/IP LAN
connection
support@paxton.co.uk
Monday - Friday from 07:00 - 19:00 (GMT)
Saturday from 09:00 - 13:00 (GMT)
Paxton
Access
Paxton
Reader
Control unit
Power
Server Connected - The TCP/
IP interface is communicating
with the PC Net2 server
Net2Air activity
Page 1
Advertisement
Table of Contents
Related Manuals for Paxton Ins-30085 Net2Air
Summary of Contents for Paxton Ins-30085 Net2Air
- Page 1 Documentation on all Paxton products can be found on our website - http://www.paxton.co.uk/ Net2Air wireless communication The access control unit connects to the Net2 software running on the PC using Paxton Net2Air proprietary wireless technology. A Net2Air bridge enables communication from the Net2 software to the Paxton family of wireless products.
- Page 2 Connecting to the PC via the Ethernet port The IP address should be assigned a fixed value, or should be given a DHCP reservation. Unreserved IP addresses issued by DHCP servers are not guaranteed to be constant, leading to potential failure of communication between Net2 software and the bridge.
- Page 3 100 mm The declaration of conformity is available on request. Contact details are provided at: http://paxton.info/596 This product is not suitable for retail sale. All warranties are invalid if this product is not installed by a competent person. Page 3...
