PRODUCT NO.
BASE MODEL NO.
PLCS389DCA
PLCS389D
MARKET
North America
WIRING DIAGRAM - # 318045091
OWNER'S GUIDE - # 318200873
TIMER INSTRUCTION SHEET - # 318200195
INSTALLATION INSTRUCTIONS - # 318201661
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
FACTORY NO.
SERIES
37957393H43S1
30" slide-in
Publication No.
5995395497
030910
-EN/SERVICE /ECL
377
RANGE
COLOR
stainless
DUAL FUEL
RANGE
Model No.
PLCS389D
©2003 Electrolux Home Products, Inc.
All rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire PLCS389D
Summary of Contents for Frigidaire PLCS389D
- Page 1 PRODUCT NO. BASE MODEL NO. PLCS389DCA PLCS389D MARKET North America WIRING DIAGRAM - # 318045091 OWNER’S GUIDE - # 318200873 TIMER INSTRUCTION SHEET - # 318200195 INSTALLATION INSTRUCTIONS - # 318201661 ELECTROLUX HOME PRODUCTS, INC. P.O. BOX 212378, Augusta, GA 30917 FACTORY PARTS CATALOG FACTORY NO.
- Page 2 Publication No. PLCS389DCA 5995395497 BACKGUARD 09/03...
- Page 3 POS. NO 20 # # = Functional Parts * = Non-Illustrated Parts PLCS389DCA BACKGUARD PART NO DESCRIPTION 318235001 Console,assy. ,black ,w/ end caps 318239701 Panel,control assy. ,black/stainless ,w/ membrane 318224404 Panel,control mtg. 316272206 Clock/Timer,electronic ,ES500/ES550 318233710 Retainer,control panel ,black 318229311 Knob,control ,black 318224301 Trim,vent ,black ,bottom...
- Page 4 Publication No. PLCS389DCA 5995395497 BURNER 09/03...
- Page 5 POS. NO 2A # 2B # 2C # 10 # 10A# 10B# 10C# 11 # 11A# 11B# 11C# 13 # 14 # # = Functional Parts * = Non-Illustrated Parts PLCS389DCA BURNER PART NO DESCRIPTION 318226100 Pipe,manifold 318233920 Valve,top burner ,11000 btu 318233930 Valve,top burner ,14000 BTU 318233900...
- Page 6 Publication No. PLCS389DCA 5995395497 BODY 09/03...
- Page 7 POS. NO 12 # 37 # 66 # 67 # 89 # 108# 125# 141# 141B 161# 219# # = Functional Parts * = Non-Illustrated Parts PLCS389DCA BODY PART NO DESCRIPTION 318066402 Panel,main back 318225100 Panel,main back ,upper 318227600 Shield,oven top 318225200 Panel,bodyside ,upper RH 318225201...
- Page 8 Publication No. PLCS389DCA 5995395497 TOP/DRAWER 09/03...
- Page 9 POS. NO 20 # 81 # 84 # 153A 153B 153C # = Functional Parts * = Non-Illustrated Parts PLCS389DCA TOP/DRAWER PART NO DESCRIPTION 318142500 Drawer,warmer 318143335 Deflector,warmer drawer ,RH 318143334 Deflector,warmer drawer ,LH 318143203 Deflector,warmer drawer ,rear 318108025 Liner,drawer 318107903 Panel,drawer ,stainless 318229900...
- Page 10 Publication No. PLCS389DCA 5995395497 DOOR 09/03...
- Page 11 POS. NO # = Functional Parts * = Non-Illustrated Parts PLCS389DCA DOOR PART NO DESCRIPTION 318056802 Shield,insulation 318133781 Insulation,oven door 318157011 Liner,door 5303311174 Screw,10-24 x 3/8 318053103 Gasket,oven door seal 318187917 Stainless Panel,oven door ,w/ glass/nmplt 318041603 Panel,glass ,inner oven door 318042102 Spacer,glass 318053001...
-
Page 12: Wiring Diagram
Publication No. PLCS389DCA 5995395497 WIRING DIAGRAM 09/03...
