Philips 32PFG5509/78 Service Manual page 30

EN 30 6. TPM14.2L LA
Picture mode Screen size
Warm (6500K) 32PFG5509/78 128
32PHG5509/78 125
40PFG5509/78 231
40PFG6309/78 239
42PFG5909/78 231
42PFG6519/78 236
42PFG6809/78 235
47PFG5909/78 218
47PFG6519/78 255
47PFG6809/78 255
48PFG5509/78 243
48PFG6309/78 235
55PFG6519/78 240
55PFG6809/78 255
This group setting of colour temperature will be applied
automatically to the TV / VGA / HDMI / AV sources.
6.4 Option Settings
6.4.1 Introduction
The microprocessor communicates with a large number of I
ICs in the set. To ensure good communication and to make
digital diagnosis possible, the microprocessor has to know
which ICs to address. The presence / absence of these
MT5580 ICs is made known by the option codes.
Notes:
• After changing the option(s), save them by pressing the OK
button on the RC before the cursor is moved to the left,
select STORE and press OK on the RC.
• The new option setting is only active after the TV is
switched "off" / "stand-by" and "on" again with the mains
switch (the NVM is then read again).
6.4.2 Option Code Overview
Enter SAM mode to check the option codes. they could be
edited in the NVM.
6.4.3 Display Code Overview
Press the following key sequence on a standard RC
transmitter: "062598" directly followed by MENU and "xxx",
where "xxx" is a 3 digit decimal value of the panel type: see
column "Display Code" in
Code, restart the set immediately.
Table 6-3 Display code overview
CTN_ALT BOM#
32PFG5509/78
32PHG5509/78
40PFG5509/78
40PFG6309/78
42PFG5909/78
42PFG6519/78
42PFG6809/78
47PFG5909/78
47PFG6519/78
47PFG6809/78
48PFG5509/78
48PFG6309/78
55PFG6519/78
55PFG6809/78
2014-Feb-28
Alignments
Colour temperature
Red Green
128 122
115 128
255 216
220 241
236 255
255 246
253 255
229 255
246 251
255 136
227 255
196 255
210 255
251 252
Table 6-3. After resetting the Display
Panel Type Display Code
TPT315B5-EUJFFA 098
TPT315B5-DXJSFE 097
TPT400LA-HM06 092
TPT400LA-HF05 090
TPT420H2-DUJSGE 091
TPT420H2-DUJSGK 3S1B 089
TPT420H2-DUJSGK 3S1A 088
TPT470H1-DUJSGE 087
TPT470H1-DUJSGK 3S1B 085
TPT470H1-DUJSGK 3S1A 084
TPT480LS-HN03 100
TPT480LS-HJ02 086
TPT550J1-DUJSGK S1C 099
TPT550J1-DUJSGK S1B 102
6.5 Reset of Repaired SSB
A very important issue towards a repaired SSB from a Service
Blue
repair shop (SSB repair on component level) implies the reset
of the NVM on the SSB.
A repaired SSB in Service should get the service Set type
"00PF0000000000" and Production code "00000000000000".
Also the virgin bit is to be set. To set all this, you can use the
ComPair tool or use the "NVM editor" and "Dealer options"
items in SAM (do not forget to "store").
After a repaired SSB has been mounted in the set (set repair
on board level), the type number (CTN) and production code of
the TV has to be set according to the type plate of the set. For
this, you can use the NVM editor in SAM. The loading of the
CTN and production code can also be done via ComPair
(Model number programming).
In case of a display replacement, reset the "Operation hours
display" to "0", or to the operation hours of the replacement
display.
Remark:
- After the NVM has been replaced, go to SAM and scroll to the
<Reload MAC address> (see figure 1*).
- Select the item and press <OK> on the RC.
