Components

Part Number Description
4000113 Splice Foot X, Kit, Mill
4000162 Splice Foot XL, Kit, Mill

Tools overview

Chalk Line
8mm hex socket 13mm socket
or Phillips head

Roofing Systems and Attachments

Before choosing any mounting and/or flashing system be sure to properly inspect and qualify the roof
type and condition for the appropriate use of structural attachment and waterproofing products. K2
Systems provides many roof attachment products though it is solely the responsibility of the installer to
choose compatible, code compliant products for the roofing and racking systems in use.
For a list of products and roofing best practice resources visit: https://k2-systems.com/en-US/base-
camp or call +1.760.301.5300 (verify and use main office line) for technical support from a K2 Systems
representative.

Important Note

The Splice Foot X & XL can be installed as rafter attached or deck attached. Rafter attached requires that
two screws be installed into the rafters using the center holes on the Splice Foot base. Deck attached
requires that four screws be installed into all four corners of the Splice Foot base.
2
Tape Measure Compatible
Sealant
