PRODUCT NO.
BASE MODEL NO.
GLCS376ABA
GLCS376A
GLCS376ABB
GLCS376A
GLCS376ASA
GLCS376A
GLCS376ASB
GLCS376A
WIRING DIAGRAM - # 318045050 = A/#318045072 = B
OWNER'S GUIDE - # 318200861
TIMER INSTRUCTION SHEET - # 318200191
INSTALLATION INSTRUCTIONS - # 318201657
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
FACTORY NO.
COLOR
37956383G1061
black
37956383G1062
black
37956383G1011
white
37956383G1012
white
Publication No.
5995363131
020102
-EN/SERVICE /ECL
377
RANGE
MARKET
North America
North America
North America
North America
DUAL FUEL
RANGE
Model No.
GLCS376A
©2002 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Related Manuals for Frigidaire GLCS376A
Summary of Contents for Frigidaire GLCS376A
- Page 1 PRODUCT NO. BASE MODEL NO. GLCS376ABA GLCS376A GLCS376ABB GLCS376A GLCS376ASA GLCS376A GLCS376ASB GLCS376A WIRING DIAGRAM - # 318045050 = A/#318045072 = B OWNER’S GUIDE - # 318200861 TIMER INSTRUCTION SHEET - # 318200191 INSTALLATION INSTRUCTIONS - # 318201657 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O.
- Page 2 Publication No. GLCS376A 5995363131 BACKGUARD 01/02...
- Page 3 A = GLCS376A (GLCS376ASA) B = GLCS376A (GLCS376ASB) C = GLCS376A (GLCS376ABA) D = GLCS376A (GLCS376ABB) POS. NO 14 # 20 # 20 # 24 # 24 # 24C# 24C# # = Functional Parts * = Non-Illustrated Parts GLCS376A BACKGUARD...
- Page 4 Publication No. GLCS376A 5995363131 BURNER 01/02...
- Page 5 A = GLCS376A (GLCS376ASA) B = GLCS376A (GLCS376ASB) C = GLCS376A (GLCS376ABA) D = GLCS376A (GLCS376ABB) POS. NO 2A # 2B # 10 # 10A# 10B# 14 # 74 # 76 # 76A# # = Functional Parts * = Non-Illustrated Parts...
- Page 6 Publication No. GLCS376A 5995363131 BODY 01/02...
- Page 7 A = GLCS376A (GLCS376ASA) B = GLCS376A (GLCS376ASB) C = GLCS376A (GLCS376ABA) D = GLCS376A (GLCS376ABB) POS. NO 14 # 15 # 37 # 62 # 66 # 67 # 89 # 89 # 89*# 108# 125# 141# 219# # = Functional Parts...
- Page 8 Publication No. GLCS376A 5995363131 TOP/DRAWER 01/02...
- Page 9 A = GLCS376A (GLCS376ASA) B = GLCS376A (GLCS376ASB) C = GLCS376A (GLCS376ABA) D = GLCS376A (GLCS376ABB) POS. NO # = Functional Parts * = Non-Illustrated Parts GLCS376A TOP/DRAWER PART NO DESCRIPTION 5303310500 A B C D Drawer 318134011 A B - -...
- Page 10 Publication No. GLCS376A 5995363131 DOOR 01/02...
- Page 11 A = GLCS376A (GLCS376ASA) B = GLCS376A (GLCS376ASB) C = GLCS376A (GLCS376ABA) D = GLCS376A (GLCS376ABB) POS. NO # = Functional Parts * = Non-Illustrated Parts GLCS376A DOOR PART NO DESCRIPTION 318043100 A B C D Bracket,trim ,handle ,(2) 318180310...
-
Page 12: Wiring Diagram
Publication No. GLCS376AB/SA 5995363131 WIRING DIAGRAM 01/02... - Page 13 GLCS376AB/SB Publication No. 5995363131 WIRING DIAGRAM # = Functional Parts 01/02 * = Non-Illustrated Parts...
