30" GAS RANGE INSTALLATION INSTRUCTIONS
INSTALLATION AND SERVICE MUST BE PERFORMED BY A QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
If the information in this manual is not followed
exactly, a fire or explosion may result causing property damage,
personal injury or death.
FOR YOUR SAFETY:
— Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in
your building.
• Immediately call your gas supplier from a neighbor's phone.
Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
* 30" minimum clearance between the top of the cooking
surface and the bottom of an unprotected wood or metal
cabinet; or 24" minimum when bottom of wood or metal
cabinet is protected by not less than ¼" flame retardant
millboard covered with not less than no. 28 MSG sheet
steel, 0.015" stainless steel, 0.024" aluminum or 0.020"
copper. The minimum clearance is 0" for the rear of the
range. Follow all dimension requirements provided above
to prevent property damage, potential fire hazard, and
incorrect countertop and cabinet cuts.

Clearances and Dimensions

1. Location—Check location where the range will be
installed. Check for proper electrical and gas supply, and
the stability of floor.
Printed in United States
Note: For appliance installed in the
State of Massachusetts see page 2.
Avoid locating cabinet storage space above the
surface burners to eliminate the possibility of cabinets
catching on fire, or personal burns from reaching for
the cabinets over the heated units. Avoid locating
cabinet storage space above the surface burners.
The absence of cabinets will eliminate the chance of
cabinets catching on fire, and eliminate the possibility
of receiving personal burns from reaching for the
cabinets over flaming surface burners. If cabinet
storage is to be provided, risk can be reduced by
installing a range hood that projects horizontally a
minimum of 5" beyond the bottom of the cabinets.
2. Dimensions that are shown must be used. Given
dimensions provide minimum clearance. Contact
surface must be solid and level.
1
•
All appliances can tip.
• Injury to persons
could result.
• Install anti-tip
bracket packed with
your appliance.
• See Installation
Instructions.
318201792 (1005) Rev. A
