JL Audio Stealthbox SB-GM-S10STD/8W1 Installation Manual

SB-GM-S10STD/8W1 Stealthbox™
Fits 1995-1999 Standard Cab
GM S-series Pickup Trucks
Installation Guide:
This Stealthbox is a product which requires professional installation skills and tools. Please read this
installation guide thoroughly before beginning the project. It will guide you step by step through the
installation. Several of the steps in this process may require two people to accomplish.
It is absolutely vital that the enclosure be properly mounted to the vehicle according to these instruc-
tions. Failure to mount the enclosure properly presents two problems: 1) the sub-bass performance
will suffer due to the movement of the enclosure caused by the force exerted by the woofer and 2) A
loose enclosure presents a serious safety hazard in the event of a collision or sudden deceleration.
STEP 1: Push both seat backs forward and slide the seats
completely forward.
STEP 2: Place the supplied 3" X 3" wax square, sticky side
down, as shown in the picture at right. The edge of the wax
square should be 5" from the side of the factory jack cover.
STEP 3: Insert the supplied " X 1 " bolt into the
3/8 1/4
threaded insert in the bottom of the Stealthbox. Tighten snugly.
SB-GM-S10STD/8W1, JL AUDIO, Inc 1997 • Page 1 Sheet SKU#011117 Revision 9/13/00
