INSTALLATION INSTRUCTIONS
Wall S leeve Brands:
4
8
8
3
4
3
#2 Fedders
Remove existing rear grille as shown on Page
1.
6 of this manual and replac e with provided
louvered rear panel. Install as shown here.
NOTE:
You may need to drill holes in flange
of existing sleeve to match new rear grille.
/
1
/
/
1
2. Attach(2)4 x3 x1
2
2
2
one on each side wall. Place in center of side
wall with the tapered end facing the opening.
3. Cut (2) 17 Tapered Spacer Blocks as shown
below into two pieces.
3
/
Ta pered Space r Block
4
Cut He re
4. The 4 section is placed in front of the rib on
base with the tapered end facing the bac k of
the sleeve. The remaining portion will be
plac ed behind the rib again s loping toward
the rear of the s leeve. This helps induce a
rearward slope on the unit.
5. Attach (1)1
x3/8 x25 long seal in the c enter
at the top of the sleeve. Remove the back ing
paper and press into position.
6. Attach (2) 1
x3/8 x14 seals to the left and
right sides of the sleeve.
7. Cut (2) 1
x3/8 x 25 long seals to 14 long
and attach it to the vertical sections of the rear
grille as shown.
8. Gently slide unit into sleeve.
9. Before sliding all-the-way back, rem ove 2nd
screw from front on left side of unit.
10. Remove the plastic washer from the screw.
11. Screw and attach the other end of the ground
wire to the unit as shown in picture. Make sure
that the toothed washer is against the cabinet.
12.Slide the unit completely to the rear to ensure
a good seal, making sure the ground wire does
not become tangled.
13.Seal & Frame the unit as described on page 17.
14. If you have difficulty with mounting the grill to
the sleeve, follow the instructions for direct
mounting on P age 16.
8
3 4 /
19
Deep
/
/
1
c entering/support blocks
2
2
17
1
4
Protection P aper
Backing
