G39LI / G39LID
D I R E C T V E N T F I R E P L A C E - I P I
OWNER'S MANUAL
WARNING:
fire or explosion may result causing property damage, personal injury
or loss of life. Installation and service must be performed by a qualified
C#4001609
Version Française: www.enviro.com/fr.html
If the information in this manual is not followed exactly, a
installer, service agency or the gas supplier.
CERTIFIED TO: ANSI Z21.88 / CSA 2.33 VENTED GAS FIREPLACE HEATERS
CSA 2.17 GAS FIRED APPLIANCES FOR HIGH ALTITUDES
50-3581
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G39LID and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enviro G39LID

Summary of Contents for Enviro G39LID

  • Page 1 G39LI / G39LID D I R E C T V E N T F I R E P L A C E - I P I OWNER’S MANUAL WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

  • Page 2: Safety Precautions

    Safety Precautions WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapours and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
  • Page 3 Safety Precautions FOR SAFE INSTALLATION AND OPERATION OF YOUR “ENVIRO” HEATER, PLEASE CAREFULLY READ THE FOLLOWING INFORMATION: • All ENVIRO gas-fired appliances must be installed in • A barrier designed to reduce the risk of burns from the accordance with their instructions. Carefully read all the hot viewing glass is provided with this appliance and shall instructions in this manual first.

  • Page 4: Table Of Contents

    Table of Contents Safety Precautions ..........................2 Codes And Approvals ........................... 5 Specifications ............................6 Dimensions: ..............................6 Rating Label & Lighting Instructions Location: ....................6 Operating Instructions ........................7 Lighting and Instructions:..........................7 Remote Control Operations:...........................8 System Description:............................8 Technical Data:.............................8 Remote Transmitter:.............................8 Integrated Fireplace Controller (IFC):......................9 Operating Procedure:...........................10 Normal Sounds During Operation:........................13...

  • Page 5: Codes And Approvals

    TESTED TO: ANSI Z21.88 / CSA 2.33 VENTED GAS FIREPLACE HEATERS CSA 2.17 GAS FIRED APPLIANCES FOR HIGH ALTITUDES This ENVIRO G39 Fireplace: • Has been certified for use with either natural gas or propane (see rating label). • Is not for use with solid fuels.

  • Page 6: Specifications

    Specifications G39 D imensions 27 3 18 3 18 1 1041 18 1 29 3 39 3 30 1 34 1 34 1 1066 1008 35 1 ELECTRICAL 38 3 39 1 Figure 1. G39 Dimensions & L atinG abeL iGhtinG nstRuctions ocation...

  • Page 7: Operating Instructions

    Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OF LOSS OF LIFE. iGhtinG anD nstRuctions FOR YOUR SAFETY READ BEFORE OPERATING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION...

  • Page 8: Remote Control Operations

    Operating Instructions For G39LID models refer to the separate Dexen user manual supplied for remote control operations. ystem escRiption The Proflame 2 Remote Control System consists of two (2) elements: 1. Proflame 2 Transmitter. 2. Integrated Fireplace Controller (IFC) and wiring harness to connect to the gas valve, stepper motor battery holder, convection fan, and lights.

  • Page 9: Integrated Fireplace Controller (Ifc)

    Operating Instructions WARNING: Fire Hazard. Can cause severe injury or death. The Transmitter causes ignition of the appliance. The appliance can turn on suddenly. Keep away from the appliance burner when operating the remote system. Key Lock Transmission Low battery alarm Thermostat OFF/ Room ON/SMART...

  • Page 10: Operating Procedure

    Operating Instructions peRatinG RoceDuRe Initializing The System Install the four (4) supplied AA batteries into the IFC battery holder. The remote transmitter should come from the manufacturer with the batteries already installed. Press the reset button on the IFC (see Figure 5) and listen for three (3) beeps.
  • Page 11 Operating Instructions Room Thermostat (Transmitter Operation) Room Temperature The remote transmitter acts as a room thermostat. The thermostat can be set to a desired temperature to control the comfort level in a room. Press the THERMOSTAT key to activate this function. The transmitter display will indicate the thermostat is ON and the set temperature can be adjusted with the UP/DOWN key.
  • Page 12 Operating Instructions Fan Control The Proflame 2 remote control system has six (6) fan speed levels. Adjust the fan speed using the UP/DOWN key; each time the button is pressed the IFC will beep to confirm your command. The remote display will show which level the fan speed is currently at.

  • Page 13: Normal Sounds During Operation

    Operating Instructions Top Light Control The top light is used to illuminate the log set in the fireplace, even when the flame is off. The on/off operation can be controlled using the remote transmitter. Use the MODE key to select the auxiliary icon and use the UP/DOWN key to activate the top light;...

  • Page 14: Pilot Light

    Operating Instructions G39LiD iLot iGht Does not appLy to moDeLs The pilot flow adjustment is set to maximum at the factory and Flame Sensor should not need to be adjusted. The pilot flame should cover ⅜” to ½” (10 to 13mm) of the flame sensor (see Figure 16).

  • Page 15: Maintenance And Service

    Do not operate with the glass front removed, cracked or broken. Removal and replacement of the glass from the door must be done by a licensed or qualified service person. The glass must be purchased from an ENVIRO dealer. No substitute materials are allowed. To remove the door (see m ).

  • Page 16: Cleaning Decorative Surfaces

    Maintenance And Service LeaninG ecoRatiVe uRFaces Painted and porcelain faces should be wiped with a damp cloth periodically. If a plated face has been purchased, it should be unpacked carefully to avoid getting anything on the surface of the finish, including cleaners, polish and finger prints.

  • Page 17: Door Cover Removal

    Maintenance And Service oVeR emoVaL To remove the door cover, remove the two (2) wing nuts using your fingers then lift up and outward. Wing nuts are only for shipping and do not need to be reinstalled. WARNING: Do not touch or attempt to remove the glass door if the fireplace is not completely cold. Figure 19.

  • Page 18: Front Burner Removal

    Maintenance And Service The burner will need to be removed for maintenance and fuel conversion, also liner removal or installation. Follow the procedure carefully. Proceed only when the unit has completely cooled down. uRneR emoVaL 1. Remove the surround panel (see m aIntenance anD erVIce urrounD...

  • Page 19: Ember Lights Removal

    Maintenance And Service mbeR iGhts emoVaL 1. Disconnect electrical power to the unit. 2. Remove burner (see m aIntenance anD erVIce ront urner emoVal 3. Remove glass media (if installed). 4. Remove light tray by removing the four (8) T-20 screws (see Figure 22). Figure 22.

  • Page 20: Top Light Replacement

    6. Remove the light cover by removing the four (4) T-20 Light Assembly screws. If light gasket is damaged, contact your ENVIRO dealer for replacement. 7. Replace the light assembly as necessary and assemble back into unit.

  • Page 21: Fuel Conversion

    Maintenance And Service onVeRsion TO BE INSTALLED BY A QUALIFIED SERVICE AGENCY ONLY Please read and understand these instructions before installing. Warning: This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction.
  • Page 22 9. Reconnect electrical power to the unit. 10. Light the pilot and recheck for leaks in the aluminum pilot line. If a leak is evident, contact your ENVIRO dealer for a pilot line replacement. WARNING: DO NOT ATTEMPT TO FIX THIS LINE, IT MUST BE REPLACED IF DAMAGED.

  • Page 23: Initial Installation

    Initial Installation QUALIFIED INSTALLERS ONLY ntRoDuction This section of the owner’s manual is for the use of qualified technicians only. There are several installation safety guidelines that must be adhered to; carefully read the safety precautions at the front of this manual.
  • Page 24 CAUTION: DO NOT DRILL INTO THE BOARD ANY FURTHER OR IT MAY CRACK. This board is mandatory unless the c is activated, if it is damaged urFace ystem contact you ENVIRO dealer. Figure 35: Non-combustible board DETAIL DETAIL SCALE 1 : 2...

  • Page 25: Placement And Framing

    Initial Installation QUALIFIED INSTALLERS ONLY Lacement anD RaminG 42” 72” (1,067mm) (1,830mm) Natural Gas* 41½” (1,054mm) NOTE: When framing the unit, care must be taken to consider the final floor thickness, the bottom of the fireplace must sit flush with the fin- ished floor to ensure proper fit of the surround components.

  • Page 26: Finishing A Fireplace

    Initial Installation QUALIFIED INSTALLERS ONLY inishinG a iRepLace There are multiple ways to finish a G39 fireplace. Here is what you need to know to properly install the desired finishing material. There are three finishing edge options. 1. Outer Finishing Edge (Short) - This finishing edge comes mounted to the unit with screws.

  • Page 27: Cool Surface Activation

    Initial Installation QUALIFIED INSTALLERS ONLY ONLY Combustible material may be brought up to any finishing edge if the Cool Surface System (CSS) has been correctly activated allowing heat in the chase to be vented. This system keeps the front wall cool enough for any combustible materials. The supplied non-combustible board can still be used but is not mandatory when the CSS is activated, combustible material may overlap in this situation.
  • Page 28 Initial Installation QUALIFIED INSTALLERS ONLY Standard Install: the Non-combustible is Cool Surface System (CSS) Install: Image shows the short finishing edge, combustible mandatory. Image shows single layer finishing material using the short finishing edge. can be brought right down to the finishing edge. 1 "...

  • Page 29: Cool Surface Install Options

    Initial Installation QUALIFIED INSTALLERS ONLY uRFace nstaLL ptions This fireplace is manufactured with a built-in heat distribution kit, referred to as the Cool Surface System (CSS). The purpose of the CSS is to dramatically reduce the front wall temperatures above your fireplace. This is very useful when delicate objects such as a TV or artwork are mounted above the unit.
  • Page 30 Initial Installation QUALIFIED INSTALLERS ONLY Option 3: Side Discharge (built-out installations) - Construct the framing in a way that provides inch (64mm) opening on each side of the chase. The top of the a minimum 17 inch (432mm) by 2 opening must be 1 1/2”...
  • Page 31 Initial Installation QUALIFIED INSTALLERS ONLY Option 5: Valance - A valance may be desired to accentuate or hide the CSS outlet. Consider framing option 1 or 4 to utilize the valance feature. This is an optional decorative feature that covers up the CSS outlet gap.

  • Page 32: Flat Wall Installation

    Initial Installation QUALIFIED INSTALLERS ONLY nstaLLation These are the minimum allowable dimensions required to safely operate the fireplace. Plan your entire installation before proceeding. These are minimum dimensions associated with natural gas only; adjust the ceiling dimensions by adding 10.5” (266 mm) if using propane. 4"...

  • Page 33: Recess Installation

    Initial Installation QUALIFIED INSTALLERS ONLY ecess nstaLLation These are the minimum allowable dimensions required to safely operate the fireplace. Plan your entire installation before proceeding. The maximum allowable depth for a recess in 3 ” (90mm) + Finishing material thickness. 4"...

  • Page 34: Corner Installation

    Initial Installation QUALIFIED INSTALLERS ONLY oRneR nstaLLation These are the minimum allowable framing dimensions required to safely operate the fireplace in a corner install. Plan your entire installation before proceeding. " 853mm " 1" 554mm 25mm 15" " 382mm 1206mm 1"...

  • Page 35: Floor Protection

    Initial Installation QUALIFIED INSTALLERS ONLY LooR Rotection The fireplace must be placed on a solid and level floor; plywood is recommended for basic installations. A protective hearth in front of the unit is not required but highly recommended for the longevity of sensitive flooring materials in front of the fireplace.

  • Page 36: Minimum Venting Requirements

    Initial Installation QUALIFIED INSTALLERS ONLY inimum entinG equiRements This appliance uses a 4” (102mm) exhaust / 6 ” (168mm) air intake vent pipe system. For safe and proper operation of the appliance follow the venting instructions exactly. Deviation from the minimum vertical length can create difficulty in burner start-up and sooting.

  • Page 37: Flex Venting

    Use 4X7 Flex Adapter Kit [50-3788]: This kit will allow you to adapt co-axial flex to the fireplace, make your Any Enviro Approved vent run, then adapt back to rigid venting (flex not Rigid Venting included).

  • Page 38: Clearances & Noncombustible

    Initial Installation QUALIFIED INSTALLERS ONLY & n LeaRances ombustibLe When installing the fireplace as a zero clearance fireplace the correct clearances and materials must be used. : The supplied noncombustible board is required above the unit up to the header 9” MIN. boVe However this not required if the Cool Surface System has been properly installed.

  • Page 39: Tv Installation Considerations

    Initial Installation QUALIFIED INSTALLERS ONLY tV i nstaLLation onsiDeRations Use of the Cool Surface System is highly recommended when mounting a TV or delicate artwork above the fireplace. If the system is not desired, some considerations must be made to ensure above objects are protected from the heat.

  • Page 40: Direct Vent

    Initial Installation QUALIFIED INSTALLERS ONLY iRect WARNING: - Follow the venting instructions exactly for safe and proper appliance operation. - Use Mill Pac or high temp RTV silicone for all venting connections. - Risk of fire, explosion, or asphyxiation if improper venting setup. -Risk of fire, do not allow loose materials or insulation to contact vent pipe.

  • Page 41: General Venting Clearances

    Initial Installation QUALIFIED INSTALLERS ONLY 12 in (30 cm) Clearance to non-mechanical air supply inlet to building, or the combustion air inlet to any other appliance. 6 ft (1.83 m) 3 ft (91 cm) above if within 10 Clearance to mechanical air supply inlet. ft (3 m) horizontally 7 ft (2.13 m )t 7 ft (2.13 m) *t...

  • Page 42: Approved Venting Parts

    Initial Installation QUALIFIED INSTALLERS ONLY ppRoVeD entinG aRts This fireplace has been tested and certified Table 6A: Approved Vent Manufacturers for use with the venting brand names liste Manufacturer Brand Name Nominal Sizes above in table 6A. Refer to table 6B below EXCELDirect 4”...

  • Page 43: Allowable Co-Axial Vent Configurations

    Initial Installation QUALIFIED INSTALLERS ONLY LLoWabLe xiaL onFiGuRations 40’ This shows the range of venting options (12.2m) using either vertical or horizontal terminations; any layout that remains NG Vent within the shaded area is acceptable. Having the fewest number of elbows RESTRICTOR 5 RESTRICTOR 5 35’...
  • Page 44 Initial Installation QUALIFIED INSTALLERS ONLY 40’ (12.2m) ONLY use this venting diagram if your fireplace has been converted LP Vent to LP. Restrictor Setting: Find the point on RESTRICTOR 5 RESTRICTOR 5 35’ Position (10.7m) the graph where your vent configuration will terminate.

  • Page 45: Exhaust Restrictor Setting

    Initial Installation QUALIFIED INSTALLERS ONLY xhaust estRictoR ettinG WARNING: Improperly set restrictor setting can cause overheating issues which can lead to building fire. It may be necessary to adjust the exhaust restrictor in order to control combustion quality and flame appearance.

  • Page 46: Horizontal Termination

    Initial Installation QUALIFIED INSTALLERS ONLY oRizontaL eRmination . A minimum of 12”(NG) or 24”(LP) vertical rise before an elbow is required when horizontally terminating with an approved venting cap. 2. Horizontal pipes must not be level. For every 12” (305 mm) of horizontal travel there should be at least ¼”...

  • Page 47: Vertical Termination

    Initial Installation QUALIFIED INSTALLERS ONLY Step 4. The vent pipe must extend into the vent cap at least 1¼” (320 mm). Secure the connection between the vent cap and the pipe by attaching the two (2) sheet metal straps, which extend from the vent cap assembly to the outer wall of the vent pipe.
  • Page 48 Initial Installation QUALIFIED INSTALLERS ONLY Table 8: Minimum ‘H’ for Figure 63. Roof Pitch Minimum Height (H) Feet Meters Dimension ‘H’ obtained from table below Flat to 7/12 Over 7/12 to 8/12 0.46 Over 8/12 to 9/12 0.61 Over 9/12 to 10/12 0.76 Over 10/12 to 11/12 3.25...

  • Page 49: Gas Line Connection And Testing

    Pressure Tap pressure test. Figure 66: Fully Labeled Gas Valve. See Dexen User Manual for G39LID valve details TO TEST VALVE PRESSURES The pressure taps are located on the top right of the valve shown in Figure 66. • Turn set screw 1 turn counter clockwise to loosen, •...

  • Page 50: Electrical Requirements

    18 AWG wire with a temperature rating of 105°C. Note: For G39LID specific wiring diagram refer to the Dexen user manual supplied and label attached to the fireplace.

  • Page 51: Secondary Installation

    If the liners arrive damaged, please contact your ENVIRO dealer for replacement. Step 5. Replace liners back into position starting with the rear. Please note that any liner options containing brick will have to be aligned with each other.

  • Page 52: Log Set Installation

    Wear vinyl gloves when handling the logs, the ceramic material can irritate your skin. Take care not to damage the logs as they are very fragile and can chip easily. If any logs arrive damaged, please contact your ENVIRO dealer for replacement. LOG 4...
  • Page 53 Secondary Installation Step 3 Place Log 3 on the right side in front of the grate arms. Line up the Log 3 bottom sockets with the points on the ember bed. Step 4 Place Log 4 to the right, on the top of Log 1 and Log 2.
  • Page 54 Secondary Installation Step 7 Rest Log 7 at an angle on top of the log grate and Log 6. Step 8 Place Log 8 between the grate arms, with the bottom of the log resting on the edge of the ember bed. Step 9 Place Log 9 between the grate arms, with the bottom of the log resting on the edge of...

  • Page 55: Troubleshooting

    Troubleshooting Table 10: Troubleshooting Note: For G39LID specific troubleshooting refer to the Dexen user manual supplied Problem Possible Cause Solution · Turn the system off by pressing the ON/OFF button on the transmitter · After approximately 2 seconds press the ON/OFF button on the transmitter again.

  • Page 56: Parts List

    Parts List Note: For G39LID specific replacement parts refer to the Dexen user manual supplied Table 11: Parts List Reference # Part Descrip�on Part # Convec�on Fan Only 50-3577 Top Light Assembly 50-3516 Log Burner 50-3585 S.I.T IPI Valve 50-2682...

  • Page 57: Parts Diagram

    Parts Diagram...
  • Page 58 Notes...

  • Page 59: Warranty

    Sherwood Industries Ltd. (“Sherwood”) hereby warrants, subject to the terms and conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.enviro.com/help/warranty.html during the specified warranty period starting from the date of original purchase at retail.
  • Page 60 _________________________________________ _________________________________________ NATURAL GAS (NAT) PROPANE(LPG) _________________________________________ INLET GAS PRESSURE:_________in wc PHONE:___________________________________ MAIN BURNER ORIFICE:__________# DMS PILOT ORIFICE #_________OR________in diam. INSTALLER’S SIGNATURE: _________________________________________ MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.enviro.com Winter 2021 C-15559...
