Summary of Contents for Motif Medical Motif Luna

  • Page 1 Motif Luna ® Operational Manual...
  • Page 2 All Motif Medical® products purchased from authorized retailers come with a manufacturer’s warranty stating that product will be free from defects in workmanship and materials; for 2-years on double-electric breast pumps, for 1-year on internal batteries, and for 90-days on breast pump parts.
  • Page 3 MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 4 Index Introduction Highlights Intended Use (Indications of Use) Symbols Safety Prohibitions, Warnings, and Cautions Parts What’s Included Buttons and Features Settings and Modes Sterilization and Cleaning Operating Your Breast Pump Breast Shield Sizing Assembling The Luna Pump How to Use The Dual Pump Turning On/Off The Luna Pump...
  • Page 5 Using Your Motif Luna Pump Pumping Guide Getting Ready to Pump Aligning the Breast Shield Expressing Your Milk After Pumping Storing Breast Milk 10. Troubleshooting 10.1 Troubleshooting 10.2 Disposal 10.3 When to Replace Parts Warranty...
  • Page 7 2. Highlights The Motif Luna® is proven to provide More Milk in Less Time®. Based on a 3rd-party study, 5 out of 6 moms agree the Luna pumps More Milk In Less Time®! You can read the full report at motifmedical.com/more-milk-less-time.
  • Page 8 3. Intended Use (Indications of Use) The Motif Luna® Double Electric Breast Pump is intended for use by lactating women to express and collect breast milk. The Luna can be used as a single or double pump and is only intended for personal use.
  • Page 9 This product should not be mixed with other commercial waste for disposal Power Increase the level of suction or cycle Decrease the level of suction or cycle Changes of operation mode LED night light Battery-power MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 10 If damage is found, immediately discontinue use of power adapter or battery pack and call Motif Medical® Customer Service. • The Motif Medical Luna® should not be positioned so that it is difficult to operate the adapter.
  • Page 11 Do not thaw frozen breast milk in a microwave or in a pan of boiling water. • If tubing becomes moldy, discontinue use and replace with new tubing. • If breast milk backup occurs you must clean tubing before your next pumping session. MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 12 5. SAFETY Caution: To avoid minor injury • Do not wrap cord around adapter body. • Use only the power adapter that comes with the powered breast pump. • Pump only with the breast pump in an upright position. • Do not shorten tubing.

  • Page 13: Table Of Contents

    24mm & 28mm Breast Shields (2) Valve (2) Bottle (2) Bottle Cap (2) Nipple (2) Bottle Cover (2) Bottle Disk (2) Air Flow Port Power Adapter - DC12V, 2A (2) Milk Collection Kits (2) MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 14 6. PARTS Additional accessories and parts available for the Luna breast pump: • Full resupply kit with replacement parts • 21mm and 32mm Breast Shields • Individual parts • Luna pump cooler set Find replacement parts and additional supplies for the Luna at: motifmedical.com/replacement-supplies/...
  • Page 15 50% - 75% 0% - 25% It is recommended to charge the battery as soon as battery gets to 0% - 25%. If the battery dies, your Motif Luna® will automatically shut down. MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 16 6. PARTS Button Control Mode Button LED Night Light (Use to switch between Massage Mode/ Increase/ Increase/ Expression Decrease Decrease Mode) Buttons Buttons Power (Adjust Cycle (Adjust Vaccum Button Level) Level) Night Light • The LED light appears by pressing the button. •...
  • Page 17 Suction Settings The suction level on your breast pump refers to the suction strength; this is measured in mm-Hg. When you are using your Motif Luna®, you will usually find that expressing is most effective on the highest suction level that you are comfortable with.

  • Page 18: Diaphragm

    7. Sterilization and Cleaning Before initial use sterilize each part of the: • Diaphragms • Breast Shields • Bottle Caps • Valves • Bottles • Nipples *Do not sterilize or wash the tubing. Repeat sterilization of other listed parts once daily after pump use. Sterilization Instructions 1.
  • Page 19 It is not recommended to wash and dry Motif Breast Pump parts in the dishwasher. There is no standard temperature for dishwashers and some may warp parts. Parts damaged in the dishwasher are not covered under warranty. MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 20 7. STERILIZATION AND CLEANING After Every Use 1. Thoroughly wash your hands before handling each breast pump component. 2. Disassemble each part that comes into contact with breast milk including the valve, bottle, bottle nipple, breast shield, bottle disk, and bottle cover. 3.
  • Page 21 Example: If your nipple size measures 26 mm in diameter, the recommended *1 cm = 10 mm breast shield size is 30 mm. Do not include the areola. MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 22 8. OPERATING YOUR BREAST PUMP See below for the recommended breast shield size based on your measurements Test your breast shield size Too Small During pumping some or your entire nipple rubs against the sides of the breast shield tunnel. Good Fit During pumping your nipple is able to move freely in the breast shield tunnel.
  • Page 23 If you need a breast shield size other than the 24mm or 28mm that come in this set, 21mm and 32mm breast shields are also available. You can find them at: motifmedical.com/pump-supplies/luna-breast-shields MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 24 8. OPERATING YOUR BREAST PUMP 8.2 Assembling The Luna Pump 1. Wash hands before touching breast pump components. 2. Insert the diaphragm into the diaphragm bottom (the component that connects to the breast shield). Ensure that it fits securely and that the diaphragm edge fits around the rim of the diaphragm bottom.
  • Page 25 When changing back to Single-Pump mode make sure to cover the air flow port with the plug. MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 26 8. OPERATING YOUR BREAST PUMP 8.4 Turning On/Off The Luna Pump Press the Power button. The device will power ON, indicated by the screen lighting up. The Luna will begin in Massage Mode to help with faster letdown. Press the Mode button to change to Expression Mode once your milk starts flowing.
  • Page 27 9. Using Your Motif Luna Pump 9.1 Pumping Guide Even when you are using the breast pump, it is recommended to breastfeed your baby whenever you can. • Gently massage your breasts or apply warm compresses from the breast toward the nipple before starting your pumping session.
  • Page 28 9. USING YOUR MOTIF LUNA PUMP 9.2 Getting Ready to Pump 1. Check to see if you are using the correct size breast shield. See section 8.1 Breast Shield Sizing for more details. 2. Wash hands thoroughly. 3. Connect your assembled collection kit to the tubing port on your breast pump.
  • Page 29 If you are unsure about breast shield sizing, please contact a healthcare professional or Motif Medical® representative who can help you get a proper fit. MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 30 9. USING YOUR MOTIF LUNA PUMP 9.4 Expressing Your Milk 1. Press the POWER button to start pumping. The breast pump begins with the last used setting, so you may need to press the MODE button to switch back to Massage Mode.
  • Page 31 3. Remove the tubing from the diaphragm assembly and breast pump. 4. Make sure no moisture comes in contact with or gets inside the tubing. Store the tubing in a clean bag/container. Do not wrap tubing around the breast pump. MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 32 9. USING YOUR MOTIF LUNA PUMP 9.6 Storing Breast Milk When storing breast milk in a milk storage bag, make sure to only use non-toxic markers when writing on the bag. Storage Locations / Temperatures Room Freezer Temperature Refrigerator 0°F (-18°C) 77°F (25°C)
  • Page 33 7. After thawing, milk should be stored in the refrigerator for no more than 24 hours. 8. Never refreeze thawed milk. Throw away previously frozen milk that is not used within 24 hours. MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 34 10. Troubleshooting 10.1 Troubleshooting Below you will find general conditions that may occur with your Motif Luna® and corresponding troubleshooting solutions. Condition Possible Causes Checks Solutions Plug into the outlet. If it has damage, Check if the contact Motif power cord is not Adapter customer service connected or is...
  • Page 35 Check if there is a Visit motifmedical. Breast Shield problem with the breast shield. Check if there is Valve damage in valve Replace the valve. head. MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 36 12 hours. If you need additional help troubleshooting your breast pump, please reach out to the Motif Medical® Costumer Service Department. You can access them online at motifmedical.com via chat, through email at hello@motifmedical.com or by phone...
  • Page 37 10.4 Disposal Please send components that are no longer used to Motif Medical® or properly dispose of the device in accordance with local, state, and federal regulations. As electrical and electronic equipment, the device must be disposed of according to a specialized procedure for...
  • Page 38 10. TROUBLESHOOTING 10.5 When to Replace Parts How often you should replace your breast pump supplies can vary based on how often you use your breast pump. For example, a mom that exclusively breast pumps about 9 times a day and sanitizes their pump more frequently than a mom that only pumps 3 to 4 times per day will need to replace her parts more often.
  • Page 39 However, keep an eye out for any cracks, tears, or warping because that could indicate that need to be replaced sooner. • The discoloration will not affect how well your pump works but may not be pleasing to the eye. MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 40 1-Year on Internal Battery (when applicable) and 90-days on breast pump parts. All Motif Medical® products purchased from authorized retailers come with a manufacturer’s warranty stating that product will be free from defects in workmanship and materials; for 2-years on double-electric breast pumps, for 1-year on internal batteries, and for 90-days on breast pump parts and the Manual Breast Pump.
  • Page 41 Manufactured for: Phone: (844) 272-8390 Motif Medical®, LLC Email: info@motifmedical.com 8 The Green, Suite 5601 Web: www.motifmedical.com Dover, DE 19901 MOTIF MEDICAL® | THE LUNA BREAST PUMP | OPERATION MANUAL...
  • Page 42 Thank you for choosing the Motif Luna Double Electric ® Breast Pump. (844) 272-8390 Motif Medical® info@MotifMedical.com 8 The Green, Suite 5601 www.motifmedical.com Dover, DE 19901...
