LY71 Change of display resolution (polarity)
The operation method for changing the display resolution differs depending on the purpose and conditions of the change.
Select the purpose and conditions to be changed from the table below and perform the operation.
Purpose of change
Change the polarity for the input axis
using the 2-axes addition / subtraction
function in the input axis selection
Change the measurement unit resolution
Change the display resolution
Change the display polarity
(Counting direction is reversed)
* If you do not know the output resolution of the measurement unit, refer to the separate "Initial setup manual".
Combination with optional unit and settings items
Initial Item
setup
1-axis input
Not used Not used
Basic Addition /
settings subtraction
function
Advanced Display A axis
Settings resolution
Basic settings ⇒ Input axis ⇒ Change
①
Set to basic settings mode.
Turn key "ON" while the AC adapter is energized.
Press and hold key for 3 seconds after the lamp changes from blinking to off.
Power ON
②
With the display , press
The display will be . (Selection of input axis)
Press key to select a condition.
When you have made your selection, press
To finish the basic settings, follow steps ② and ③ below.
③
Switch from basic settings to normal count mode.
Press key once and the display will change to
Press key once and the display will change to
④
Press key once to automatically switch to advanced settings mode.
The display will be
Press key, the display becomes the normal display.
Operation
Basic settings ⇒ Input axis ⇒ Change
Basic settings ⇒ Measurement unit resolution ⇒ Change
Advanced Settings ⇒ Display resolution ⇒ Change
Advanced Settings ⇒ Display resolution ⇒ Change polarity
No option
2-axes 2-axes 1-axis
input input input
Not
use
used
A axis A axis A axis
B axis
About 2 sec
key once
key to save your settings.
.
.
LY71 Change of display resolution (polarity)
BCD unit BCD unit (LZ71-B)
(LZ71-B) Comparator unit (LZ71-KR)
2-axes 2-axes
input input
Not used use
A axis A axis
B axis
LY71
.
Explanation
Change the input axis choices in the basic
settings
Change the length measurement unit resolution in
the basic settings. And check the display
resolution in the detailed settings.
Change the display resolution in the detailed
settings
Change the display resolution in the detailed
settings
Comparator unit
(LZ71-KR)
1-axis input 1-axis input
Not used Not used
A axis A axis
Input axis selection
(addition / subtraction function)
Input 1
Input 1, input 2 (independent)
Input 1 +Input 2
Input 1 – Input 2
-Input 1 +input 2
-(Input 1 + Input 2)
NOTE: When using comperate unit, 2-axis
independent display is not possible.
Ver.1 (2021.1) CS&S
2-axes input
use
A axis
