PRODUCT NO.
BASE MODEL NO.
FGF377WJCA
FGF377WJ
FGF377WJCB
FGF377WJ
WIRING DIAGRAM - #316002180
OWNER'S GUIDE - # 316135903
INSTALLATION INSTRUCTIONS - # 316105837
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917
This Publication Supercedes
Publication # 5995346318
FACTORY PARTS CATALOG
COLOR
MARKET
stainless
North America
stainless
North America
Publication No.
5995380077
021022
-EN/SERVICE /ECL
369
RANGE
GAS
RANGE
Model No.
FGF377WJ
©2002 Electrolux Home Products, Inc.
All rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FGF377WJ
Summary of Contents for Frigidaire FGF377WJ
- Page 1 PRODUCT NO. BASE MODEL NO. FGF377WJCA FGF377WJ FGF377WJCB FGF377WJ WIRING DIAGRAM - #316002180 OWNER’S GUIDE - # 316135903 INSTALLATION INSTRUCTIONS - # 316105837 ELECTROLUX HOME PRODUCTS, INC. P.O. BOX 212378, Augusta, GA 30917 This Publication Supercedes Publication # 5995346318 FACTORY PARTS CATALOG...
- Page 2 Publication No. FGF377WJ 5995380077 BACKGUARD 10/02...
- Page 3 A = FGF377WJ (FGF377WJCA) B = FGF377WJ (FGF377WJCB) POS. NO 20 # 24 # # = Fast-moving Parts * = Non-Illustrated Parts FGF377WJ BACKGUARD PART NO DESCRIPTION 316028700 Shield,backguard ,galv ,rear wall 316051600 Shield,backguard ,inner 316053800 Shield,backguard ,inner top 316083718...
- Page 4 Publication No. FGF377WJ 5995380077 BURNER 10/02...
- Page 5 A = FGF377WJ (FGF377WJCA) B = FGF377WJ (FGF377WJCB) POS. NO 2A # 2A # 2B # 2B # 10 # 13 # 14 # 16 # 17 # 18 # 19 # 22 # 23 # 24 # 26 #...
- Page 6 Publication No. FGF377WJ 5995380077 BODY 10/02...
- Page 7 A = FGF377WJ (FGF377WJCA) B = FGF377WJ (FGF377WJCB) POS. NO 12 # 14 # 18 # 37 # 39 # 89 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FGF377WJ BODY PART NO DESCRIPTION 316029416 Panel,main back...
- Page 8 Publication No. FGF377WJ 5995380077 TOP/DRAWER 10/02...
- Page 9 A = FGF377WJ (FGF377WJCA) B = FGF377WJ (FGF377WJCB) POS. NO 22B# # = Fast-moving Parts * = Non-Illustrated Parts FGF377WJ TOP/DRAWER PART NO DESCRIPTION 316011501 Drawer 5303288582 Liner,drawer ,galv steel ,front panel 316079401 Panel,drawer ,stainless 3051163 Glide,drawer ,rear 316114803 Maintop,black...
- Page 10 Publication No. FGF377WJ 5995380077 DOOR 10/02...
- Page 11 A = FGF377WJ (FGF377WJCA) B = FGF377WJ (FGF377WJCB) POS. NO 12 # # = Fast-moving Parts * = Non-Illustrated Parts FGF377WJ DOOR PART NO DESCRIPTION 316079300 Panel,oven door ,stainless ,outer 316083900 Glass,oven door ,outer 316088601 Glass,oven door ,inner 316088405 Shield,wool...
-
Page 12: Wiring Diagram
Publication No. FGF377WJ 5995380077 WIRING DIAGRAM 10/02...
