PRODUCT NO.
BASE MODEL NO.
FGF376WECJ
FGF376WE
FGF376WESH
FGF376WE
FGF379WESJ
FGF376WE
WIRING DIAGRAM # - 316002166
OWNER'S GUIDE # - 316000253
INSTALLATION GUIDE # - 316002974
P.O. Box 212378
Augusta, Georgia 30917
© 1998 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
COLOR
MARKET
CHROME
USA
WHITE
USA
WHITE
USA
Publication No.
5995303871
980731
-EN/SERVICE /VLM
369
GAS RANGE
GAS - RANGE
FGF379WECJ
FGF379WESH
FGF379WESJ
Advertisement
Related Manuals for Frigidaire FGF379WECJ
Summary of Contents for Frigidaire FGF379WECJ
- Page 1 INSTALLATION GUIDE # - 316002974 P.O. Box 212378 Augusta, Georgia 30917 © 1998 White Consolidated Industries, Inc. All rights reserved FACTORY PARTS CATALOG COLOR MARKET CHROME WHITE WHITE Publication No. 5995303871 980731 -EN/SERVICE /VLM GAS RANGE GAS - RANGE FGF379WECJ FGF379WESH FGF379WESJ...
- Page 2 Publication number 5995303871 FGF379WECJ, FGF379WESH, FGF379WESJ CAUTION: Use the part number on all orders, not the position number. BACKGUARD 03/98...
- Page 3 316082301 316074907 316021105 316069700 5303500001 218490900 316001435 316021108 5303288574 # - Fast Moving Parts * - Non Illustrated Parts FGF379WECJ, FGF379WESH, FGF379WESJ BACKGUARD DESCRIPTION Shield-backguard,rear wall Shield-backguard,inner Switch-warmer,infinite ,drawer/zone Light-indicator,warmer dwr/zone Support-backguard,RH Support-backguard,LH Plate,instrument mtg End Cap,black ,RH End Cap,white ,RH...
- Page 4 Publication number 5995303871 FGF379WECJ, FGF379WESH, FGF379WESJ CAUTION: Use the part number on all orders, not the position number. BURNER 03/98...
- Page 5 26 # 5308067970 316089500 5303210090 316011100 316074700 5303307190 # - Fast Moving Parts * - Non Illustrated Parts FGF379WECJ, FGF379WESH, FGF379WESJ BURNER DESCRIPTION Manifold Pipe Valve-top burner Screw-,hex washer head ,1/4-20 x 0.31 , w/gasket Valve-top burner,large ,(2) Switch-ignitor,(4) Tube-burner,red ,RF Tube-burner,green ,LF Tube-burner,nat.
- Page 6 Publication number 5995303871 FGF379WECJ, FGF379WESH, FGF379WESJ CAUTION: Use the part number on all orders, not the position number. BODY 03/98...
- Page 7 3131732 3131903 3051124 5303288579 08067973 316047705 316054200 3131304 5303285692 # - Fast Moving Parts * - Non Illustrated Parts FGF379WECJ, FGF379WESH, FGF379WESJ BODY DESCRIPTION Back-main Shield-oven top Panel-bodyside,black ,RH Panel-bodyside,white ,RH Shield-insulation Panel-bodyside,black ,LH Panel-bodyside,white ,LH Shield-heat,body side Burner Box...
- Page 8 Publication number 5995303871 FGF379WECJ, FGF379WESH, FGF379WESJ CAUTION: Use the part number on all orders, not the position number. BODY 03/98...
- Page 9 316026400 89 # 316028103 316095201 316021108 316045000 # - Fast Moving Parts * - Non Illustrated Parts FGF379WECJ, FGF379WESH, FGF379WESJ BODY Rail-drawer RH,outer Rail-drawer RH,outer Rod-latch,auto Motor-latch/lock Shield-drawer,front warmer Screw,cup pt ,#8-18 x 3/8 ,hinge , ind lght brkt,manifold pnl...
- Page 10 Publication number 5995303871 FGF379WECJ, FGF379WESH, FGF379WESJ CAUTION: Use the part number on all orders, not the position number. TOP/DRAWER 03/98...
- Page 11 316093600 316095800 316091902 3203618 218490900 316021108 316089500 316105500 5303280311 5303288567 5303288574 # - Fast Moving Parts * - Non Illustrated Parts FGF379WECJ, FGF379WESH, FGF379WESJ TOP/DRAWER DESCRIPTION Drawer-warmer Liner,drawer Panel-drawer,stainless Glide-drawer,rear,RH Channel-drawer,rh,inner Glide-drawer,inner, LH Channel drawer,lh,inner Plug-button,glide Main Top,black Main Top,white...
- Page 12 Publication number 5995303871 FGF379WECJ, FGF379WESH, FGF379WESJ CAUTION: Use the part number on all orders, not the position number. DOOR 03/98...
- Page 13 316008401 218490900 316065301 316085500 5303212671 5303271648 5303280311 5303285179 5303288567 # - Fast Moving Parts * - Non Illustrated Parts FGF379WECJ, FGF379WESH, FGF379WESJ DOOR DESCRIPTION Panel-oven door,stainless ,outer Glass-oven door,outer Glass-oven door,inner Shield-wool Insulation,oven door Glass-oven door,airwash Liner-oven door Screw-handle mtg,#10-32...
-
Page 14: Wiring Diagram
Publication number 5995303871 FGF379WECJ, FGF379WESH, FGF379WESJ CAUTION: Use the part number on all orders, not the position number. WIRING DIAGRAM 03/98...
