Frigidaire FGF365D Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Ranges
  5. FGF365D
  6. Factory parts catalog
Frigidaire FGF365D Factory Parts Catalog

Frigidaire FGF365D Factory Parts Catalog

30-inch freestanding gas range
Hide thumbs

Advertisement

Quick Links

Download this manual
Product No.
Series
Color
Market
Wiring Diagram
Owner's Guide
Installation Instructions 316259336
Service Data Sheet
FGF365D.eps T24G0011.eps T24B0001.eps T24V0025.eps T24T0001.eps T24D0005.eps
316417800d.eps 316417800s.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FGF365DQA FGF365DSA FGF365DUA FGF365DWA
30" f/s gas
30" f/s gas
30" f/s gas
bisque
white
black/bisque
North America North America North America North America
316417800
316417800
316417800
316417104
316417104
316417104
316259336
316259336
316417605
316417605
316417605
Publication No.
5995422952
04/11/24
(EN/SERVICE/ECL)
369
Copyright
30" f/s gas
black/white
316417800
316417104
316259336
316417605
30-INCH FREE-
STANDING GAS
RANGE
Model No.
FGF365D
©
2004 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FGF365D and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FGF365D

Summary of Contents for Frigidaire FGF365D

  • Page 1 Color Market Wiring Diagram Owner's Guide Installation Instructions 316259336 Service Data Sheet FGF365D.eps T24G0011.eps T24B0001.eps T24V0025.eps T24T0001.eps T24D0005.eps 316417800d.eps 316417800s.eps ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917 FGF365DQA FGF365DSA FGF365DUA FGF365DWA 30" f/s gas 30" f/s gas 30"...
  • Page 2 Publication No: 5995422952 FGF365D BACKGUARD 11/04...
  • Page 3 316021105 316021108 316021109 316021110 # Functional Parts * Non-Illustrated Parts FGF365D BACKGUARD A FGF365D (FGF365DQA) B FGF365D (FGF365DSA) C FGF365D (FGF365DUA) D FGF365D (FGF365DWA) DESCRIPTION A B C D Shield, backguard, rear wall A B C D Shield, backguard, inner...
  • Page 4 Publication No: 5995422952 FGF365D BURNER 11/04...
  • Page 5 GRLP2 316248105 316253700 5303271648 # Functional Parts * Non-Illustrated Parts FGF365D BURNER A FGF365D (FGF365DQA) B FGF365D (FGF365DSA) C FGF365D (FGF365DUA) D FGF365D (FGF365DWA) DESCRIPTION A B C D Pipe, manifold A B C D Valve, 9.5K burner, w/mtg screw A B C D Screw, valve mtg., 1/4 - 20...
  • Page 6 Publication No: 5995422952 NOTE: Oven Liner N/A Ass. du four N/A 11/04 FGF365D BODY T24V0025...
  • Page 7 316021108 316021110 316089500 5303271648 5303285179 # Functional Parts * Non-Illustrated Parts FGF365D BODY A FGF365D (FGF365DQA) B FGF365D (FGF365DSA) C FGF365D (FGF365DUA) D FGF365D (FGF365DWA) DESCRIPTION A B C D Back, main A B C D Shield, oven top A B C D...
  • Page 8 Publication No: 5995422952 FGF365D TOP/DRAWER 11/04...
  • Page 9 316099500 316021105 316021108 316021109 316021110 # Functional Parts * Non-Illustrated Parts FGF365D TOP/DRAWER A FGF365D (FGF365DQA) B FGF365D (FGF365DSA) C FGF365D (FGF365DUA) D FGF365D (FGF365DWA) DESCRIPTION A B C D Drawer, utility A B C D Liner, drawer A - C -...
  • Page 10 Publication No: 5995422952 FGF365D DOOR 11/04...
  • Page 11 316433603 316021109 5303271648 5303285179 # Functional Parts * Non-Illustrated Parts FGF365D DOOR A FGF365D (FGF365DQA) B FGF365D (FGF365DSA) C FGF365D (FGF365DUA) D FGF365D (FGF365DWA) DESCRIPTION A - - - Trim, oven door, bisque - B - - Trim, oven door, white...

  • Page 12: Wiring Schematic

    Publication No: 5995422952 FGF365D WIRING SCHEMATIC 11/04...

  • Page 13: Wiring Diagram

    FGF365D Publication No: 5995422952 WIRING DIAGRAM 11/04 # Functional Parts * Non-Illustrated Parts...
