7-2716 SCFH
90-200 PSIG
Installation, Operation &
Maintenance Manual
This manual contains important safety information and should be made available to
all personnel who operate and/or maintain this product. Carefully read this manual
before attempting to operate or perform maintenance on this equipment.
Manual No. 65086-1A
June 2005 Edition
Advertisement
Table of Contents
Related Manuals for Quincy Compressor DEFENDER 7-2716 SCFH
Summary of Contents for Quincy Compressor DEFENDER 7-2716 SCFH
- Page 1 7-2716 SCFH 90-200 PSIG Installation, Operation & Maintenance Manual This manual contains important safety information and should be made available to all personnel who operate and/or maintain this product. Carefully read this manual before attempting to operate or perform maintenance on this equipment. Manual No.
-
Page 3: Table Of Contents
Change Filter Elements ~ Premium Filtration – Annually ..........13 Change Carbon ........................ 14 Change Filter Elements ~ Standard Filtration – Annually ..........14 Maintenance Schedule ..................... 15 Section VII - Spare Parts List Spare Parts Lists ........................ 16 Quincy Compressor-DEFENDER™... -
Page 5: Section I - General Information
WARNING! NOTICE! This symbol identifies hazards or Identifies important installation, unsafe practices which could result in operation or maintenance information personal injury, death or substantial which is not hazard related. property damage. Quincy Compressor-DEFENDER™... -
Page 6: Introduction
Quincy Compressor maintains replacement equipment previously or subsequently parts for all Quincy compressor products. sold. Not responsible for typographical A repair parts list for the Quincy errors. DEFENDER™ can be found in the back of this manual. -
Page 7: Limited Warranty
Section I - General Information LIMITED WARRANTY Warranties and Limitation of Liability Quincy Compressor (“the Company”) warrants that it will, at it sole discretion, repair or This warranty does not extend to products or replace products and/or parts of products sold... -
Page 8: Section Ii - Description System Description
fi nal dust fi lter (#4), installed after downstream pressure. A non-return check the carbon bed, removes any charcoal valve keeps nitrogen in the system from dust before the air reaches the membrane venting back into the generator when unit is bundles. stopped. Quincy Compressor-DEFENDER™... - Page 9 Two pressure gauges are installed on the front panel. One is for displaying inlet For systems with the built-in N2 analyzer pressure and the other for system (outlet) installed, a 3-way valve and regulator are pressure. Quincy Compressor-DEFENDER™...
-
Page 10: Section Iii - Safety Safety
M e n t a l f a i l u r e , f a i n t i n g , unconsciousness, ashen face, blueness of lips, nausea, and vomiting. 4-6%: Coma in 40 seconds, convulsions, respiration ceases, cardiac arrest, death. Quincy Compressor-DEFENDER™... -
Page 11: Combustion
fiercely in the presence of oxygen-rich air. It is imperative that vented gas be discharged only in safe, well-ventilated areas. If the unit is located in a poorly ventilated room, the waste gas must be piped to a ventilated atmosphere for release. Quincy Compressor-DEFENDER™... -
Page 12: Section Iv - Installation Installation Instructions
Connection Sizes DEFENDER™ Model Feed Air Inlet Outlet Connection N2GEN 25-70 ¼” NPT ¼” NPT N2GEN 270-520 ½“ NPT ¼” NPT N2GEN 870 ½“ NPT ½“ NPT N2GEN 1800 1“ NPT ½“ NPT Quincy Compressor-DEFENDER™... -
Page 13: Pre-Start Inspection
A rule of position. thumb is to fill the tank and purge two times to near atmospheric pressure, allowing the tank to re-pressurize after each purge. The nitrogen can be delivered to the system after the initial purging procedure. Quincy Compressor-DEFENDER™... -
Page 14: Section V - Operating Instructions
2. Place selector switch to the desired gas to be analyzed NOTICE! 3. Allow the reading to settle ( 30 For Calibration, refer to Initial Startup seconds ) – Nitrogen Purity Sampling 4. Press the POWER button to turn the analyzer OFF Quincy Compressor-DEFENDER™... -
Page 15: Auto Start/Stop Pilot Valve Operation
When one is manually switch between the open/ adjusted it changes closed states. the setting of the other. When ever adjusting AIR IN the Pilot Valve use small increments and keep the differential at 15-20 psig. Quincy Compressor-DEFENDER™... -
Page 16: Flow & Purity Controller Operation
flow, counterclockwise will time of order. increase flow. If an analyzer is installed, make gradual adjustments, allowing 120 seconds between adjustments to allow for flow change and the analyzer to settle. Quincy Compressor-DEFENDER™... -
Page 17: Section Vi - Servicing
5. Repeat this process for all three (3) 3. Auto drain – Each filter is fitted with filters (1, 2 & 3 - standard/1, 2 & 4 - an internal automatic float drain to premium). Quincy Compressor-DEFENDER™... -
Page 18: Change Carbon
Once pressurized, check for leaks the carbon vessel to allow access at the inlet and outlet of the Carbon to the carbon. Drain the carbon into Vessel. a container and replace with fresh Quincy Compressor-DEFENDER™... -
Page 19: Maintenance Schedule
*The sensor’s life will decrease faster with larger percentages of oxygen running over it. Keep Selector switch on N2 OUT or OFF (if equipped) whenever it is not being calibrated. NOTICE! Failure to follow these maintenance and service recommendations may adversely affect your warranty. Quincy Compressor-DEFENDER™... -
Page 20: Section Vii - Spare Parts List
, 2.5” D ., P RESSURE AUGE PSIG ANEL OUNT QRG-02700 EMBRANE ITROGEN QVA-00085 , 1/4” EEDLE ALVE URITY ONTROLLER CSNT-00030 . 1 C OALESCING ILTER OMPLETE CXNT-00030 .2 C OALESCING ILTER OMPLETE ACNT-00030 . 3 C DSORBING ILTER OMPLETE Quincy Compressor-DEFENDER™... - Page 21 ILTER LEMENT MICRON QVA-02870 , 1/2” HECK ALVE QRG-02672 EMBRANE ITROGEN QVA-00086 , 1/2” EEDLE ALVE URITY ONTROLLER CSNT-00150 . 1 C OALESCING ILTER OMPLETE CXNT-00150 .2 C OALESCING ILTER OMPLETE ACNT-00150 . 3 C DSORBING ILTER OMPLETE Quincy Compressor-DEFENDER™...
- Page 22 Seller is not responsible for loss or damage in transit after having received “In Good Order” receipt from the carrier. All claims for loss or damage in transit should be made to the carrier. Quincy Compressor-DEFENDER™...
- Page 23 ENVIRONMENTAL AND OSHA REQUIREMENTS: At the time of shipment of the equipment from the factory, Quincy Compressor / Ortman Fluid Power will comply with the various Federal, State and local laws and regulations concerning occupational health and safety and pollution. However, in the installation...
- Page 24 Notes ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ Quincy Compressor-DEFENDER™...
