PRODUCT NO.
BASE MODEL NO.
FGF345BHWB
FGF345BH
WIRING DIAGRAM - #316002174
OWNER'S GUIDE - # 316135900
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
SERIES
COLOR
Frigidaire
white
Publication No.
5995345526
001023
-EN/SERVICE /ECL
369
RANGE
MARKET
North America
GAS
RANGE
Model No.
FGF345BH
©2001 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FGF345BH
Summary of Contents for Frigidaire FGF345BH
- Page 1 PRODUCT NO. BASE MODEL NO. FGF345BHWB FGF345BH WIRING DIAGRAM - #316002174 OWNER’S GUIDE - # 316135900 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. BOX 212378, Augusta, GA 30917 FACTORY PARTS CATALOG SERIES COLOR Frigidaire white Publication No. 5995345526 ©2001 White Consolidated Industries, Inc.
- Page 2 Publication No. FGF345BHWB 5995345526 BACKGUARD 01/01...
- Page 3 316109507 Knob-top valve,black ,(4) 316062325 Panel-manifold 316083300 Trim-vent 316096900 Bezel-nameplate,black 316095420 Nameplate,Frigidaire ,black 316074907 Deflector-flue, black 316021105 Screw,hex head cup pt ,8-18 x 0.375 ,black,back/bodyside 316021108 Screw,cup pt ,8-18 x 0.375 ,chrm,hng,ind light,manifold panel 316021110 Screw,8-18 x 0.500 ,black Publication No.
- Page 4 Publication No. FGF345BHWB 5995345526 BURNER 01/01...
- Page 5 POS. NO 10 # 10A# 11 # 11A# 14 # 17 # 18 # 19 # # = Fast-moving Parts * = Non-Illustrated Parts FGF345BHWB BURNER PART NO DESCRIPTION 316113500 Manifold Pipe 316098600 Valve-top burner,2-position ,(4) 316048200 Screw-,hex washer head ,1/4-20 x 0.31 ,valve mounting,w/gasket 316001828 Wiring Harness,ignitor ,with switches 5303209931...
- Page 6 Publication No. FGF345BHWB 5995345526 BODY 01/01...
- Page 7 POS. NO 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FGF345BHWB BODY PART NO DESCRIPTION 316029416 Back-main,1 316081034 Panel-bodyside,white ,RH 316081035 Panel-bodyside,white ,LH 316067206 Burner Box 316129200 Screw-leveling,plastic ,with stop 316067902 Rack-oven 316007001 Hinge-oven door,(2) 5303300701 Panel-oven bottom 316064600 Support-oven bottom 316116400...
- Page 8 Publication No. FGF345BHWB 5995345526 TOP/DRAWER 01/01...
- Page 9 POS. NO 20 # # = Fast-moving Parts * = Non-Illustrated Parts FGF345BHWB TOP/DRAWER PART NO DESCRIPTION 316110201 Carriage, broiler 316110101 Liner-low broil 316110800 Shield-broiler 316056205 Panel-drawer,white 316021112 Screw,8-18 x 0.500 ,white 316129100 Fastener-spacer,push-in nut ,nylon 316073800 Pan-broiler 3205234 Insert-broiler pan 316111502 Glide-low broil,inner 316111600...
- Page 10 Publication No. FGF345BHWB 5995345526 DOOR 01/01...
- Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FGF345BHWB DOOR PART NO DESCRIPTION 316067802 Trim-oven door,black 316089000 Glass-oven door,black ,outer 316088403 Shield-wool 316076401 Insulation,oven door 316088600 Glass-oven door,inner 316066610 Liner-oven door 5303280308 Screw-handle mtg,wafer hd sq dr ,10-24T x 2.00 316008401 Washer,3/4 OD x 1/4 ID ,steel 5303202011...
-
Page 12: Wiring Diagram
Publication No. FGF345BHWB 5995345526 WIRING DIAGRAM 01/01...
