PRODUCT NO.
BASE MODEL NO.
FGF311PHSE
fgf311ph
WIRING DIAGRAM - #316002153
OWNER'S GUIDE - # 316135912
INSTALLATION INSTRUCTIONS - # 316105805
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
COLOR
MARKET
white
North America
Publication No.
5995362372
011214
-EN/SERVICE /ECL
369
RANGE
GAS
RANGE
Model No.
FGF311PH
©2001 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FGF311PH
Summary of Contents for Frigidaire FGF311PH
- Page 1 PRODUCT NO. BASE MODEL NO. FGF311PHSE fgf311ph WIRING DIAGRAM - #316002153 OWNER’S GUIDE - # 316135912 INSTALLATION INSTRUCTIONS - # 316105805 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. BOX 212378, Augusta, GA 30917 FACTORY PARTS CATALOG COLOR MARKET white North America Publication No.
- Page 2 Publication No. FGF311PHSE 5995362372 BACKGUARD 12/01...
- Page 3 POS. NO 12 # # = Fast-moving Parts * = Non-Illustrated Parts FGF311PHSE BACKGUARD PART NO DESCRIPTION 316133501 Trim,splasher ,white ,lower 316057003 Trim,wrapper ,white 316032404 Thermostat 316097602 Insulator 316034130 Panel,control ,white 316064300 Nut,nylon 316102303 Knob,thermostat ,white 316009009 Knob,top valve ,white ,(4) 316086820 Panel,manifold ,white 3131468...
- Page 4 Publication No. FGF311PHSE 5995362372 BURNER 12/01...
- Page 5 POS. NO 10 # 10A# 11A# 14 # 17 # 18 # 19 # # = Fast-moving Parts * = Non-Illustrated Parts FGF311PHSE BURNER PART NO DESCRIPTION 316134400 Pipe,manifold 5303935189 Valve,top burner ,2 position ,w/ mtg screw 316134300 Screw,10-24 ,valve mounting 316001828 Wiring Harness,ignitor ,with switches 316135700...
- Page 6 Publication No. FGF311PHSE 5995362372 BODY 12/01...
- Page 7 POS. NO 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FGF311PHSE BODY PART NO DESCRIPTION 316029416 Panel,main back 316081034 Panel,bodyside ,white ,RH 316081035 Panel,bodyside ,white ,LH 316067206 Burner Box 316129200 Screw,leveling ,plastic ,with stop 316067902 Rack,oven 316007007 Hinge,oven door ,(2) 5303300701 Panel,oven bottom...
- Page 8 Publication No. FGF311PHSE 5995362372 TOP/DRAWER 12/01...
- Page 9 POS. NO 20 # # = Fast-moving Parts * = Non-Illustrated Parts FGF311PHSE TOP/DRAWER PART NO DESCRIPTION 316110201 Carriage,low broil 316110101 Liner,low broil 316110800 Shield,broiler 316056205 Panel,drawer ,white 316129100 Fastener,push-in nut ,nylon ,spacer 316081900 Pan,broiler 316082000 Insert,broiler pan 316111502 Glide,low broil ,chassis 316111600 Glide,low broil ,inner 316111501...
- Page 10 Publication No. FGF311PHSE 5995362372 DOOR 12/01...
- Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FGF311PHSE DOOR PART NO DESCRIPTION 316066611 Liner,oven door 5303281378 Screw,wafer head ,10-24F x 3 ,handle mtg 316008401 Washer,3/4 OD x 1/4 ID ,steel 5303202011 Seal,oven door ,non self clean 3202315 Panel,oven door ,white 316020202 Handle,oven door ,white...
-
Page 12: Wiring Diagram
Publication No. FGF311PHSE 5995362372 WIRING DIAGRAM 12/01...
