PRODUCT NO.
BASE MODEL NO.
FGF316WGSC
FGF316WG
FGF316WGTC
FGF316WG
WIRING DIAGRAM # - 316002152
OWNER'S GUIDE # - 316000646
INSTALLATION GUIDE # - 316105805
P.O. Box 212378
Augusta, Georgia 30917
© 1998 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
COLOR
MARKET
WHITE/WHITE
USA
ALMOND/ALMOND USA
Publication No.
5995320115
990324
-EN/SERVICE /VLM
369
GAS RANGE
GAS - RANGE
FGF316WGSC
FGF316WGTC
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FGF316WGSC
Summary of Contents for Frigidaire FGF316WGSC
- Page 1 PRODUCT NO. BASE MODEL NO. FGF316WGSC FGF316WG FGF316WGTC FGF316WG WIRING DIAGRAM # - 316002152 OWNER’S GUIDE # - 316000646 INSTALLATION GUIDE # - 316105805 P.O. Box 212378 Augusta, Georgia 30917 © 1998 White Consolidated Industries, Inc. All rights reserved FACTORY PARTS CATALOG...
- Page 2 Publication number 5995320115 FGF316WGSC, FGF316WGTC CAUTION: Use the part number on all orders, not the position number. BACKGUARD 04/99...
- Page 3 Shield-backguard,rear wall 316043611 Trim-splasher,white 316043615 Trim-splasher,almond 316083716 Trim-wrapper,white 316083717 Trim-wrapper,almond 5303271464 Thermostat-oven 5303131237 Support-backguard,(2) 316034130 PANEL-CONTROL WHITE FRIGIDAIRE,metal , white 316034132 PANEL-CONTROL ALMOND FRIGIDAIR,metal , PAINT,almond 316005608 Switch-rocker,oven light ,almond 316005607 Switch-rocker,oven light ,white 316064300 Nut,nylon 316102303 Knob-thermostat,black 316102315 Knob-thermostat...
- Page 4 Publication number 5995320115 FGF316WGSC, FGF316WGTC CAUTION: Use the part number on all orders, not the position number. BURNER 04/99...
- Page 5 CAUTION: Use the part number on all orders, not the position number. FGF316WG (FGF316WGSC) FGF316WG (FGF316WGTC) POS. NO 10 # 10A# 11 # 11A# 14 # 17 # 18 # 19 # # - Fast Moving Parts * - Non Illustrated Parts...
- Page 6 Publication number 5995320115 FGF316WGSC, FGF316WGTC CAUTION: Use the part number on all orders, not the position number. BODY 04/99...
- Page 7 CAUTION: Use the part number on all orders, not the position number. FGF316WG (FGF316WGSC) FGF316WG (FGF316WGTC) POS. NO 170* # - Fast Moving Parts * - Non Illustrated Parts FGF316WGSC, FGF316WGTC BODY PART NO DESCRIPTION 316021108 Screw,cup pt ,#8-18 x 3/8 ,hinge ,...
- Page 8 Publication number 5995320115 FGF316WGSC, FGF316WGTC CAUTION: Use the part number on all orders, not the position number. TOP/DRAWER 04/99...
- Page 9 CAUTION: Use the part number on all orders, not the position number. FGF316WG (FGF316WGSC) FGF316WG (FGF316WGTC) POS. NO 20 # # - Fast Moving Parts * - Non Illustrated Parts FGF316WGSC, FGF316WGTC TOP/DRAWER PART NO DESCRIPTION 316021108 Screw,cup pt ,#8-18 x 3/8 ,hinge ,...
- Page 10 Publication number 5995320115 FGF316WGSC, FGF316WGTC CAUTION: Use the part number on all orders, not the position number. DOOR 04/99...
- Page 11 CAUTION: Use the part number on all orders, not the position number. FGF316WG (FGF316WGSC) FGF316WG (FGF316WGTC) POS. NO # - Fast Moving Parts * - Non Illustrated Parts FGF316WGSC, FGF316WGTC DOOR PART NO DESCRIPTION 316021110 Screw-8-18x1/2 Tr Sqd black 5303271648...
-
Page 12: Wiring Diagram
Publication number 5995320115 FGF316WGSC, FGF316WGTC CAUTION: Use the part number on all orders, not the position number. WIRING DIAGRAM 04/99...
