FES355E.eps la20bg0043.eps BFES355ESA.eps LA20CT0045.eps D79046592500.eps
318271906.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FES355EBA
37954335E5061 37954335E5011
Series
30" elec
Color
black
Market
North America
Wiring Diagram
318271906
Owner's Guide
318203804
Installation Instructions 318201611
Timer Guide
318200184
Publication No.
5995439386
05/06/15
(EN/SERVICE/ECL)
377
FES355ESA
30" elec
white
North America
318271906
318203804
318201611
318200184
30-INCH SLIDE-IN
ELECTRIC RANGE
Model No.
FES355E
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FES355E
Summary of Contents for Frigidaire FES355E
- Page 1 Product No. Series Color Market Wiring Diagram Owner's Guide Installation Instructions 318201611 Timer Guide FES355E.eps la20bg0043.eps BFES355ESA.eps LA20CT0045.eps D79046592500.eps 318271906.eps Electrolux Major Appliances North & Latin America P.O. BOX 212378 AUGUSTA, GA 30917 FES355EBA FES355ESA 37954335E5061 37954335E5011 30" elec 30" elec...
- Page 2 Publication No: 5995439386 FES355E BACKGUARD 06/05...
- Page 3 318224812 318224815 08016432 5303300265 5303311333 # Functional Parts * Non-Illustrated Parts FES355E BACKGUARD A FES355E (FES355ESA) B FES355E (FES355EBA) DESCRIPTION Light, indicator, 125v, (2) Console, assy., white Console, assy., black Clip, console, (2) Panel, control, white Panel, control, black Panel, control mtg.
- Page 4 Publication No: 5995439386 FES355E BODY 06/05...
- Page 5 08016432 108A 318251300 119# 318005202 # Functional Parts * Non-Illustrated Parts FES355E BODY A FES355E (FES355ESA) B FES355E (FES355EBA) DESCRIPTION Back, main Panel, main back, upper Shield, insulation, upper Panel, bodyside, upper RH Panel, bodyside, upper LH Panel, subtop Screw, leveling...
- Page 6 Publication No: 5995439386 FES355E BODY 06/05...
- Page 7 318235300 3051050 3201861 5303211311 5303307980 5304415832 5304436875 # Functional Parts * Non-Illustrated Parts FES355E BODY A FES355E (FES355ESA) B FES355E (FES355EBA) DESCRIPTION Adapter Assembly, vent tube, w/converter Box, vent Plate, shield Deflector Box, extension Spacer, (4) Plate, shield Shield, heat Bracket, base support, (4) Anti-tip &...
- Page 8 Publication No: 5995439386 FES355E TOP/DRAWER 06/05...
- Page 9 318122500 318301000 5303325173 5303211311 5303300265 5303311333 # Functional Parts * Non-Illustrated Parts FES355E TOP/DRAWER A FES355E (FES355ESA) B FES355E (FES355EBA) DESCRIPTION Drawer Panel, drawer, white, front Panel, drawer, black, front Spacer Washer, plastic Bracket, drawer support, (2) Channel, drawer, RH Channel, drawer, LH Element, surface, 8", large...
- Page 10 Publication No: 5995439386 FES355E DOOR 06/05...
- Page 11 316221001 5304415832 # Functional Parts * Non-Illustrated Parts FES355E DOOR A FES355E (FES355ESA) B FES355E (FES355EBA) DESCRIPTION Trim, oven door, black, upper Trim, oven door, side, (2) Glass Assy., oven door, white, outer, w/trim Glass Assy., oven door, black, outer, w/trim...
-
Page 12: Wiring Diagram
Publication No: 5995439386 FES355E WIRING DIAGRAM 06/05...
