Mini Nature Wild Cam TX-117
The Declaration of Conformity for this device is under the Internet link:
www.technaxx.de/ (in bottom bar "Konformitätserklärung"). Before using the device
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
Keep this user manual for future reference or product sharing carefully. Do the same
with the original accessories for this product. In case of warranty, please contact the
dealer or the store where you bought this product.
Enjoy your product * Share your experience and opinion on one
Contents
Features ........................................................................................................ 1
Camera overview........................................................................................... 2
Power supply ................................................................................................. 3
Inserting the memory card ............................................................................. 3
Basic Operations ........................................................................................... 3
Download Files to a computer (2 ways) ......................................................... 9
Technical specifications ................................................................................. 9
Features
Security camera battery operated for indoor and outdoor use
Ideal for recording and observing the wildlife and for monitoring houses
FullHD video resolution 1080p
1.9" TFT LCD display (384x160)
1/4" CMOS sensor with 2MP
Select functions: video, photo, video & photo
PIR sensor (~15m) & IR range (~18m) for night recordings
Triggering time 0.6 seconds
Built-in micophone & speaker
MicroSD card** up to 32GB (**not included in delivery)
Camera protection class IP56 (dust proof & heavy splash water proof)
®
Technaxx
the first time, read the user manual carefully.
Free Email: support@technaxx.de
of the well-known internet portals
* User Manual
1
Warranty 2 years
Advertisement
Related Manuals for Technaxx TX-117
Summary of Contents for Technaxx TX-117
-
Page 1: Table Of Contents
Mini Nature Wild Cam TX-117 The Declaration of Conformity for this device is under the Internet link: www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before using the device the first time, read the user manual carefully. Service phone No. for technical support: 01805 012643 (14 cent/minute from German fixed-line and 42 cent/minute from mobile networks). -
Page 2: Camera Overview
Camera overview Front view Bottom view Rear view Display screen Playback button Infrared LEDs DC adapter port Lens Tripod Slot Up button / Video button Microphone Down button / Capture button Battery compartment PIR sensor (motion sensor) On-TEST-OFF button OK / Record button Mini USB connector Menu button MicroSD card slot... -
Page 3: Power Supply
Power supply Before use, install 4x pieces of AA batteries* 1.5V (*included) in the correct polarity. Open the camera case and remove the battery cover. Extended Information for Power supply The device does not work with a battery voltage lower than 4V. The battery life with default video length of 30 seconds will be: 7.5 hours in day mode or 1.8 hours in night mode &... - Page 4 Setup menu and function as below: Mode: [Photo] / [Video] / [Photo & Video] (default). Select and press OK button to confirm. Capture mode Camera only takes pictures. Set the Video mode Camera only records video. working mode Capture & Video mode Camera will take a photo first, (default) and then start to record video.
- Page 5 IR Distance: (set the distance of infrared induction): [Near] / [Middle] (default) / [Far]. Select and press OK button to confirm. Note: Maybe you have to adjust the right option for your personal use. Sensitivity Motion Sensors options: [Low] / [Middle] (default) / [High]. Select and press OK button to confirm.
- Page 6 TL (Time Lapse) Video You can set the interval time. The Settings time range is from 3 second to 24 hours. Set time lapse Hr Min ： ： For example, set the interval to 1 00 30 hour, the camera will take a photo Notification:Motion each hour.
- Page 7 Password Protection: [On] / [Off] (default). Select and press OK button to confirm. Set the power-on password of the camera. The password is four digits, each digit ranges from 0 to 9. Attention: If you set the password, write it down to make sure that you do not forget it! Beep Sound: [On] / [Off] (default).
- Page 8 Select from the following options: Delete the current Options: [Cancel] / [Delete] photo or video Press OK to confirm Delete all photo and video Options: [Cancel] / [Delete] Delete all files files saved on the memory Press OK to confirm card.
-
Page 9: Download Files To A Computer (2 Ways)
Download Files to a computer (2 ways) Inserting the MicroSD card into a card reader. Connecting the camera to a computer using the supplied USB cable. Using a Card Reader Pop-up the memory card from the camera and insert it into a card reader adapter. - Page 10 –7°C up to +40°C Weight & 141g (without batteries) / (L) 8.7 x (W) 4.4 x (H) 10.7cm Dimensions Mini Nature Wild Cam TX-117, Mini USB cable, Package contents Mounting belt, 4x AA batteries, User Manual Warnings Do not attempt to disassemble the device, it may result in short-circuit or even damage.
