Parking Brake Lever Free Play Adjustment - Yamaha YXZ1000R Owner's Manual

1. Accelerator pedal
2. Accelerator pedal free play
EBU35194
Parking brake lever free play adjust-
ment
Periodically check the parking brake lever
free play and adjust it if necessary.
1. Shift the transmission into first gear.
2. Check the parking brake lever free play.
The maximum free play is equal to one
click of the parking brake lever. If neces-
sary, adjust the free play as follows.
1
2
8-52
1. Parking brake lever free play
3. Remove panel B. (See page 8-11.)
4. Release the parking brake lever.
5. Slide the rubber cover back on the park-
ing brake cable.
6. Loosen the locknut.
1
8
