Velleman DVR4MQAE Manual

DVR4MQAE – DIGITAL 4-CHANNEL MULTIPLEXER QUAD MPEG-4 RECORDER + ETHERNET
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that disposal of the device after its lifecycle could harm
the environment.
Do not dispose of the unit (or batteries) as unsorted municipal waste; it should be taken to a specialised
company for recycling.
This device should be returned to your distributor or to a local recycling service.
Respect the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for buying the DVR4MQAE! Please read the manual thoroughly before bringing this device into service. If
the device was damaged in transit, don't install or use it and contact your dealer. Contents: 1 digital video recorder, 1
power adapter, software, accessories, HDD key and this manual.
2. Safety Instructions
Be very careful during the installation: touching live wires can cause life-threatening electroshocks.
Keep this device away from rain and moisture.
Be aware of the presence of uninsulated dangerous voltage.
Damage caused by disregard of certain guidelines in this manual is not covered by the warranty and the dealer will
not accept responsibility for any ensuing defects or problems.
3. Features
• General:
o MPEG4 real-time compression format
o high-resolution recording:
Frame: 720 x 480 pixels @ 30 IPS <NTSC> / 720 x 576 pixels @ 25 IPS <PAL>
CIF: 352 x 240 pixels @ 120 IPS <NTSC> / 352 x 288 pixels @ 100 IPS <PAL>
o 1 built-in HDD base supporting 250GB / more than 400GB with IDA
o recording audio with 4-channel input and 2-channel output
o image quality setting: Best, High, Normal and Basic
o supports PELCO-D protocol
o system auto recovery after power is reconnected
• Operation:
o Pentaplex functions (live display, record, playback, backup, and network)
o supports manual / timer / motion / alarm / remote recording functions
o possibility to cover the screen under recording
o watermark function ensures authentication of recorded images
o supports daylight saving function
o easy system upgrade via USB
o easy file backup methods with USB and network remote recording backup
• Event:
o advanced motion detection function and scheduled motion detection recording (4 different adjustable factors of
motion detection sensitivity) and convenient search function.
o alarm trigger recording will send alert with images to designated email and FTP address
o supports pre-alarm recording (8MB).
DVR4MQAE - 1 - VELLEMAN
