User's Manual
Welcome
Thank you very much for purchasing this product. Before you start, you are
recommended to read this manual step by step to obtain the best results with your
new Pico projector. We wish you enjoy it.
About the product
This is the latest generation of Pico projector with DLP technology inside. Known for
great cinema projectors, the DLP technology provides rich colors and enhances the
contrast of the image. Integrated with WLAN, the Pico projector provides cable-free
connection from your notebook, tablet, or smartphone to the Pico projector by
streaming pictures, videos, websites, and documents wirelessly and projecting the
images up to 120'' (300 cm) in size. With its support to multiple media files, Office and
PDF documents, and versatile connection options including HDMI, MHL, AV-in, VGA,
USB and SD card slot, this Pico projector is the best solution for mobile use in
business and entertainment.
Safety Notice
1. Keep the device and packaging materials out of the reach of infants and children.
2. Avoid subjecting the power adapter and other contacts to dripping or splashing
water and dry your hands before you use it. Do not place objects filled with liquids
such as vases, etc. on or near the device.
3. Make sure that the used power outlet is always readily available and never hidden.
In case of emergency, use the power adapter to separate the device from the power
network.
4. Keep your device away from all flames such as candles and do not set them up in
the vicinity of the device.
5. Keep the unit at least 10 cm away from other objects. Make sure the ventilation is
not covered by newspapers, tablecloths, curtains, etc.
6. For your own safety, do not use the projector during thunderstorms or lightning.
7. Relative Humidity is 20% ~ 80%, non-condensing.
8. The battery is integrated with the device. Do not dissemble and modify. The battery
should be replaced by an authorized service center only.
9. Ensure that the ambient room temperature is within 5 ~ 35°C.
10. Wait before using if the device has been moved from a cold location into a warm one.
Any condensation that has formed may in certain circumstances destroy the device.
As soon as the device has reached room temperature it can be used without risk.
11. Handle the product with care. Avoid contact with sharp objects. Keep device away
from metallic objects.
12. Place the projector on a flat surface. Any collision or falling to the ground is likely to
damage the product.
Page 1
Advertisement
Table of Contents
Related Manuals for AIPTEK RV7001
Summary of Contents for AIPTEK RV7001
-
Page 1: About The Product, Safety Notice
User’s Manual Welcome Thank you very much for purchasing this product. Before you start, you are recommended to read this manual step by step to obtain the best results with your new Pico projector. We wish you enjoy it. About the product This is the latest generation of Pico projector with DLP technology inside. - Page 2 User’s Manual 13. Do not drop or disassemble the product otherwise the warranty voids. Opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to an authorized service center. 14. Use only the accessories supplied by the manufacturer. 15.
- Page 3 User’s Manual FCC Compliance Statement: This device complies with Part 15 of the FCC Rules. Operation is subjected to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with limits for a Class B digital device, pursuant to Part 15 of the FCC rules.
-
Page 4: Table Of Contents
User’s Manual Table of Content About the Product, Safety Notice Package Content Knowing Your Device Getting Started Charging the product Selecting the language Projecting from External Video Input Source HDMI, VGA, AV-IN Smartphone & Tablets Charging the external mobile devices Projecting from Memory Main Menu Video... -
Page 5: Package Content
User’s Manual Package Content Please check if the following items are located in your packaging: Pico Projector Power Adapter Exchangeable Power Plug Remote Control HDMI Cable (A to A type) MHL Cable (HDMI A to USB D type) ... -
Page 6: Knowing Your Device
User’s Manual Knowing your Device Projector Projection Lens Ventilation Focus Lever Speaker Keypad Ventilation Tripod Socket VGA Port HDMI / MHL Connector SD/ SDHC/ SDXC Card Slot DC IN USB Connector Infrared Receiver Micro USB Connector AV jack / Speaker Connector Control Panel Menu Exit... - Page 7 User’s Manual Remote Control Source Power Brightness Scene Mode Lens Mode Exit (one menu step back) Menu Left Previous Right Next Down Volume Down Volume Up Installing the Remote Control Battery 1. Remove the battery holder by holding down the side release firmly and pulling out the battery holder.
-
Page 8: Getting Started
User’s Manual Operating Range with Remote Control 7m / 22.97 feet Note: Actual operating range may slightly differ from the diagram. Additionally, a weak battery reduces or eliminates the operating range of the remote control. Getting Started Charging the product The projector is built in a Li-Polymer battery for mobile use. -
Page 9: Selecting The Language
User’s Manual Adjusting the Focus according to distance Place the projector on a flat surface and toward a wall or a projection screen. The projectional distance and projectional size are: Distance: 50 cm ~ 425 cm (20 ” ~ 167 ”) Image size: 36 cm ~ 305 cm (14 ”... -
Page 10: Hdmi, Vga, Av-In
User’s Manual HDMI Use the HDMI cable to connect the HDMI port on the rear panel of the projector to the external HDMI signal source. After connected, the screen switches to HDMI source automatically. Use a VGA cable to connect the VGA port on the rear panel of the projector to the external VGA signal source. - Page 11 User’s Manual Changing Playback Setting for External Video Source Press /Menu on control panel or remote control to enter the playback setting. 1. Aspect ratio When the video file is in 4:3 aspect ratio, this function allows you to adjust how the image should appear on the 16: 9 screen.
- Page 12 User’s Manual Eco: This mode is recommended when the projector is operated under battery mode to save power. Note: The projector is automatically switched to Enhanced mode when It’s powered by the power adapter. 3. Projection (Lens) mode It allows you to select the projection mode, depending upon how the projector is mounted.
-
Page 13: Smartphone & Tablets
User’s Manual Projecting from Smartphones or Tablets 1. Connect smartphones supported MHL (Mobile High-Definition Link) for projection. Connect Samsung Galaxy S2, Note; new HTC one, one X+, one X, one S; or Sony Xperia Z with the projector via MHL (A to USB D type HDMI) cable. -
Page 14: Projecting From Memory
User’s Manual Projecting from Memory Projecting from Internal Memory The projector has 2 GB internal memory and 1.2 GB is free for file storage. Please download media files from your PC or Notebook to the internal memory for projection: 1. Turn on the PC and the projector. 2. -
Page 15: Main Menu
User’s Manual Main Menu Press the navigation key to highlight the desired item and press ◎/OK to enter the submenu; press /Exit to return to Main Menu. Icon Function Description This function allows users to select video file Video for projection. - Page 16 User’s Manual Projecting Videos Select and project video files. 1. Select and press OK to enter ‘Video’ on the main menu. 2. In the file list, use to select the folder and press ◎ /OK to open the selected folder.
-
Page 17: Photo
User’s Manual My Favorite: The file will be marked ★ icon and be grouped into “My Favorite” folder for easy access (like a bookmark). (Please refer to page 21, “My Favorite” section introduction.) You may also select a file in the file list and press ◎/OK for 2 seconds to mark the file. - Page 18 User’s Manual Please see the detail operation as following <Table B>. <Table B> Zoom in / Zoom out (Photo: The Magnification levels are 1x ~ 4x. Zoom Document: The Magnification levels are 1x ~ 8x.) Previous / Next picture (page) ◎...
-
Page 19: Document
User’s Manual My Favorite: The file will be marked ★ icon and be grouped into “My Favorite” folder for easy access (like a bookmark). (Please refer to page 21, “My Favorite” section introduction.) Note: The projector supports the following photo formats: File Format Max. -
Page 20: Music
User’s Manual 2. When opening, magnifying or panning a file, it may take a few seconds to open the page due to large file size or multiple photos on one page. 3. The projector has limited font support. Opening a document with unsupported fonts, the document viewer automatically substitutes unsupported fonts with default fonts. -
Page 21: Myfavorite
User’s Manual 2. Navigate the file list, select a file, and press ◎ /OK to start projecting. 3. To manage the files, highlight a file on the list and press (Menu) key to enter ‘Copy & Delete’ function. Copying file Select and press ◎ /OK “Copy”... - Page 22 User’s Manual Note: The projector is automatically switched to Enhanced mode when It’s powered by the power adapter. 2. Projection (Lens) mode Allow you to select the projection mode, depending upon how the projector is mounted. Please see the detail operation on page 12. 3.
-
Page 23: Enable Wirelss Connection
User’s Manual Enable Wireless Connection For first-time use, please follow the steps below to install wireless application software for your PC or smartphone. Install the wireless application software on your computer 1. Select and enter ‘Wi-Fi’ on the main menu to launch the wireless function of the projector. - Page 24 User’s Manual Note: 1. Your computer must have wireless network function to detect the connection. 2. Disconnect the Ethernet cable from your computer to avoid affecting the wireless network connection. 3. When you connect to the projector’s wireless network, you will loss wireless connectivity with other wireless networks.
- Page 25 User’s Manual 8. Double click the driver EZ_View to install. Click <Next> and follow on-Screen instructions to complete the setup and reboot the computer. When the installation is completed, an icon, labeled EZ View will appear on your computer desktop. Note: To rename your projector network name (SSID) or change the wireless security (password is disabled as default), you can type the projector's IP address (192.168.111.1) into your web browser to open its configuration...
- Page 26 User’s Manual Peer-to-Peer Wireless connection with the projector Peer-to-peer wireless connection from your computer with the projector allows you quickly start the presentation or watch a movie wirelessly from your PC, tablet, or smartphone but without the access to an available Wi-Fi network (without Internet access).
- Page 27 User’s Manual 6. After successfully logged in, the wireless projection between the computer and the projector has been established. Advanced functions of EZ View Item Descriptions 1~4 : Allow 4 different devices to project in the same screen L, R : Move the screen to the left A.
-
Page 28: Wireless App On Apple Or Android Devices
User’s Manual Install the wireless application software on Apple or Android devices EZ View for Android smartphone and Apple iDevice EZ View is an application that runs on your Android smartphone or Apple iDevice and transmits still images or presentations to the projector. The EZ View is only used for a wireless connection. - Page 29 User’s Manual Installing EZ View from Apple App Store (For Apple i-device) 1. Connect your iPhone to the Internet and Launch the App Store. 2. In the search bar, type EZ View. (Or scan the QR code directly from the installation page.) 3.
- Page 30 User’s Manual 2. The W-Fi Display shows the wireless status (Wi-Fi connected or disconnected) and password for connecting the projector. 3. Enable your WLAN on smartphone. Select the access point labeled ‘WiFi_projector-XX’ to connect the projector Wireless network. Opening EZ View and Logging into the projector 1.
- Page 31 User’s Manual 4. Press <OK> to continue. 5. Select the type of files on your smartphone for projection. EZ View app function Description Projecting Photos stored on your smartphone. Projecting Office Documents and PDFs stored on your smartphone. Projecting Web pages. (Home Network mode only) * Please see page 31 to enable Client mode.
- Page 32 User’s Manual Sketch the image from EZ View A sketch tool is built in Photo / Document /Web modes, to let presenter make note on the projected page. You can draw, highlight in color or erase by touch easily. All the sketched images can be saved in camera roll at once. Connect the projector to available Wi-Fi network (Home Network Mode) for Internet access You are recommended to connect the projector to a Wi-Fi network so your computer,...
- Page 33 User’s Manual 3. Select the Wi-Fi network you would like to connect and confirm with ◎ “OK”. 4. If wireless security is enabled on your Wi-Fi network, press ◎ “OK” to display the keyboard and enter the password (network key) by using the navigation keys on the projector or the remote control.
- Page 34 User’s Manual Note: Internet access (Home Network mode) performance is affected by a variety of factors, such as the CPU performance of your smartphone/ notebook, the distance between the access point, and walls/obstacles that obstruct direct line-of-sight. Cordless phones, bluetooth devices, microwaves, and anything that may cause RF interference in the 2.4GHz frequency range can affect the WLAN performance as well.
-
Page 35: Troubleshooting
User’s Manual Troubleshooting If your projector does not seem to be functioning properly, check the items below before you contact an authorized service center. Symptom Check Point 1. Check if the HDMI cable is plugged correctly. The projector does not 2. -
Page 36: Specifications
User’s Manual Specifications Item Description Optical Technology Light Source RGB LED Aspect ratio 16:9 Resolution 854 x 480 Pixels (WVGA) Contrast Ratio 1000:1 Projection Image Size 36 cm ~ 300 cm (14” ~ 120”) Projection Distance 50 cm ~ 425 cm (20” ~ 167”) Throw Ratio 1.6 (Projection Distance/Width of Image) (Diagonal: Distance)
