Frigidaire FEF402B Factory Parts Catalog
Frigidaire FEF402B Factory Parts Catalog

Frigidaire FEF402B Factory Parts Catalog

Electric

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
FEF402BWA
FEF402B
WIRING DIAGRAM - # 318045317
OWNER'S GUIDE - # 318200706
TIMER INSTRUCTION SHEET - # 318200140
INSTALLATION INSTRUCTIONS - # 318200870
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917
FACTORY PARTS CATALOG
FACTORY NO.
COLOR
38154515C2011
white
Publication No.
5995371852
020510
-EN/SERVICE /ECL
377
RANGE
MARKET
North America
ELECTRIC
RANGE
Model No.
FEF402B
©2002 Electrolux Home Products, Inc.
All rights reserved
