Installation / Care / Use Manual
A = 1/4" O.D. TUBE WATER OUT
B = 1/4" O.D. TUBE WATER INLET
C = TEMPERATURE ADJUSTMENT
D = ELECTRICAL
E = 1/4" O.D. TUBE TANK DRAIN
A) WHITE
BLANCO
BLANC
B) BLACK
NEGRO
NOIR
C) GROUND
TIERRA
MISE À LA TERRE
D) FAN
ABANICO
VENTILATEUR
E) COLD CONTROL
CONTROL DE FRÍO
THERMOSTAT
F) Internal Overload Protector
PROTECTOR INTERNO DEL SOBRECARGADOR
SYSTEME DE PROTECTION DE SURCHAGE INTERNE
G) PTC STARTER
INICIADOR CPT (CONTROL POSITIVO DE TEMPERATURA)
DEMARREUR CTP
All manuals and user guides at all-guides.com
MODELS: ERS1-2F TRCS1-2F
230V Refrigeration Packages
WIRING DIAGRAM
DIAGRAMA DE CONEXIÓN DE ALAMBRES
SCHÉMA DE CÂBLAGE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Elkay ERS1-2F
Summary of Contents for Elkay ERS1-2F
- Page 1 All manuals and user guides at all-guides.com Installation / Care / Use Manual MODELS: ERS1-2F TRCS1-2F 230V Refrigeration Packages A = 1/4" O.D. TUBE WATER OUT B = 1/4" O.D. TUBE WATER INLET C = TEMPERATURE ADJUSTMENT D = ELECTRICAL E = 1/4"...
- Page 2 All manuals and user guides at all-guides.com 4.Conecte la electricidad.
- Page 3 All manuals and user guides at all-guides.com INSTALLATION OPERATION OF QUICK CONNECT FITTINGS FUNCIONAMIENTO DE LOS ACCESORIOS DE CONEXIÓN RÁPIDA FONCTIONNEMENT DES RACCORDS RAPIDES Simply Push In Tube To Attach Push In Collet To Release Tube Tube Is Secured In Position Pushing Tube In Before Pulling It Out Helps To Release Tube.
- Page 4 All manuals and user guides at all-guides.com ITEM NO. PART NO. NOTE: NOTA: NOTE : A) AIR VENT ORIFICIO PARA VENTILACION BOUCHE d’AERATION B) CONDENSER SIDE FORWARD LADO DEL CONDENSADOR HACIA EL FRENTE PARTIE LATERALE DU CONDENSEUR VERS L’AVANT C) CAN BE MOUNTED FLUSH AGAINST EITHER SIDE OF CABINET PUEDE INSTALARSE NIVELADO CONTRA CUALQUIER LADO DEL GABINETE...
