- Page 1 ECH8GRN_1C ECH8GRN Refrigeration Package INSTALLATION, CARE AND USE MANUAL (630) 574-8484 Elkay Manufacturing Company Page 1 2000000696 (Rev. A - 07/22)
- Page 2 General ......3 ECH8GRN Series ..... . 7 Safety Alert Symbol.
-
Page 3: Think Safety
1.1 General injury. The signal word that CAUTION Elkay Manufacturing Company (Elkay) cannot indicates a hazard with anticipate every possible circumstance that might a low level of risk which, if not avoided, could result in involve a potential hazard during the installation of minor or moderate injury. this product. The warnings and instructions in this The signal word that indicates Installation / Use &... - Page 4 Placing fingers in or around the cutting blades Prior to any maintenance, make sure the unit is could result in serious personal injury. unplugged and circuit breakers are turned OFF. Elkay Manufacturing Company (630) 574-8484 Page 4 2000000696 (Rev. A - 07/22)
-
Page 5: General Information
Website: http://www.elkay.com a properly ventilated, non-visible location. USA/Canada Customer Care This manual contains installation, Use & Care Phone: 800.476.4106 instructions for the ECH8GRN series Remote Chiller Email: CustCare@Elkay.com units. Followed carefully, these instructions will result International Customer Care in trouble-free installation of this Elkay Manufacturing Phone: 630.575.4755 Company (Elkay) product. - Page 6 A = 1/4" O.D. TUBE WATER OUTLET B = 1/4" O.D. TUBE WATER INLET C = TEMPERATURE ADJUSTMENT 1 3/4" REF. D = ELECTRICAL 95mm 17 3/8" 441mm 3 3/4” 57mm Elkay Manufacturing Company (630) 574-8484 Page 6 2000000696 (Rev. A - 07/22)
-
Page 7: Tools And Supplies
• If inlet pressure is above 100 psig (0.69 MPa), Protective gloves a pressure regulator must be installed in water Hex driver supply line. Any damage caused by the water pressure outside its rated pressure is not covered by warranty. 5. Ratings 5.1 ECH8GRN Series Description ECH8GRN Electrical 115VAC, 60Hz, (See nameplate for Amperage), 1 phase Ambient Air Temp. 50-90 °F (10-32 °C) Water Pressure 20-100 psig (0.14-0.69 MPa) -
Page 8: Installation: Electrical Connection
This chiller is manufactured in such a manner that it does not in any way cause Ground taste, odor, color or sediment problems. Wire 8. Connect chiller to building supply with a shut-off valve and install the in-line strainer between the valve and chiller. 9. Electrical: Make sure power supply is identical in voltage, cycle, and phase to that specified on chiller serial plate. Never wire the compressor directly to the power supply. Elkay Manufacturing Company (630) 574-8484 Page 8 2000000696 (Rev. A - 07/22) - Page 9 O-ring seal. To remove the plug from Chiller, relieve the water pressure, pull the collar towards the fitting and then pull the fitting from the tube. To install the plug, push the fitting straight onto the tubing until it reaches a positive stop, which should be approximately 3/4” (19mm). Refer page 10 for quick connect fittings. (630) 574-8484 Elkay Manufacturing Company Page 9 2000000696 (Rev. A - 07/22)
- Page 10 TUBE TO ATTACH PUSHING TUBE IN BEFORE PULLING IT OUT HELPS TO Fig. 2 RELEASE TUBE Wiring Diagram COMPRESSOR OVERLOAD COLD CONTROL ( WATER ) RELAY CAPACITOR Fig. 3 Elkay Manufacturing Company (630) 574-8484 Page 10 2000000696 (Rev. A - 07/22)
- Page 11 NOTE: All correspondence pertaining to any of the above wa- ter chiller or orders for repair parts MUST include model number 4, 5 and serial number of chiller, name and part number of replacement part. Fig. 4 (630) 574-8484 Elkay Manufacturing Company Page 11 2000000696 (Rev. A - 07/22)
