- Page 1 ECP8_1J ECP8_2J ECP8_3J ECP8 Refrigeration Packages INSTALLATION, CARE AND USE MANUAL (630) 574-8484 Elkay Manufacturing Company Page 1 2000000698 (Rev. A - 07/22)
- Page 2 General ......3 ECP8 Series ......7 Safety Alert Symbol.
-
Page 3: Think Safety
1.1 General injury. The signal word that CAUTION Elkay Manufacturing Company (Elkay) cannot indicates a hazard with anticipate every possible circumstance that might a low level of risk which, if not avoided, could result in involve a potential hazard during the installation of minor or moderate injury. this product. The warnings and instructions in this The signal word that indicates Installation / Use &... - Page 4 OFF. Placing fingers in or around the cutting blades could result in serious personal injury. Elkay Manufacturing Company (630) 574-8484 Page 4 2000000698 (Rev. A - 07/22)
-
Page 5: General Information
USA/Canada Customer Care Phone: 800.476.4106 This manual contains installation, Use & Care Email: CustCare@Elkay.com instructions for the ECP8 series Remote Chiller units. Followed carefully, these instructions will result in International Customer Care trouble-free installation of this Elkay Manufacturing Phone: 630.575.4755 Company (Elkay) product. - Page 6 ECP8_1J ECP8_2J ECP8_3J Elkay Manufacturing Company (630) 574-8484 Page 6 2000000698 (Rev. A - 07/22)
-
Page 7: Tools And Supplies
Protective gloves • If inlet pressure is above 100 psig (0.69 MPa), a pressure regulator must be installed in water Hex driver supply line. Any damage caused by the water pressure outside its rated pressure is not covered by warranty. 5. Ratings 5.1 ECP8 Series Description ECP8 Electrical 115VAC, 60Hz, (See nameplate 220VAC, 50/60Hz, (See nameplate for Amperage), 1 phase for Amperage), 1 phase Ambient Air Temp. -
Page 8: Installation
6. Preparation 7. Installation 6.1 General Information 1. Connect chiller to building supply with a shut-off valve and install a 3/8” (10 mm) unplated water line 1. ECP8- type Chillers are not fully-enclosed. They between the valve and chiller. Remove burrs from are designed to be installed in a metal enclosure outside of water line. Insert water line into bulkhead (Mounting Box MB23A, MB232A, etc.). This is union until it reaches a positive stop, approximately typically seen with Legacy In-Wall applications. - Page 9 TO RELEASE TUBE PUSHING TUBE IN BEFORE PULLING IT OUT HELPS TO Fig. 1 RELEASE TUBE OVERLOAD Wiring Diagram COMPRESSOR COLD CONTROL (WATER) RELAY BLACK WHITE GROUND Fig. 2 (630) 574-8484 Elkay Manufacturing Company Page 9 2000000698 (Rev. A - 07/22)
- Page 10 NOTE: All Correspondence Pertaining to any of the above water chillers or orders for repair parts must include model no., serial no. of chiller, name and part no. of replacement part. Fig. 3 Elkay Manufacturing Company (630) 574-8484 Page 10 2000000698 (Rev. A - 07/22)
