Frigidaire FEF316A Factory Parts Catalog

Frigidaire FEF316A Factory Parts Catalog

Electric
Hide thumbs

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FEF316AQA
FEF316A
FEF316ASA
FEF316A
WIRING DIAGRAM - #316255124
OWNER'S GUIDE - # 316257101
INSTALLATION INSTRUCTIONS -# 316259200
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
COLOR
MARKET
bisque
North America
white
North America
Publication No.
5995357679
010816
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
ELECTRIC
RANGE
Model No.
FEF316A
©2001 White Consolidated Industries, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FEF316A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FEF316A

Summary of Contents for Frigidaire FEF316A

  • Page 1 PRODUCT NO. BASE MODEL NO. FEF316AQA FEF316A FEF316ASA FEF316A WIRING DIAGRAM - #316255124 OWNER’S GUIDE - # 316257101 INSTALLATION INSTRUCTIONS -# 316259200 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. Box 212378, Augusta, GA 30917 COLOR MARKET bisque North America white North America Publication No.
  • Page 2 Publication No. FEF316A 5995357679 BACKGUARD 08/01...
  • Page 3 A = FEF316A (FEF316ASA) B = FEF316A (FEF316AQA) POS. NO 12 # 14 # 24 # 24 # 54 # 54A# # = Fast-moving Parts * = Non-Illustrated Parts FEF316A BACKGUARD PART NO DESCRIPTION 5303289640 Shield,backguard ,rear wall 316133501 Trim,splasher ,white ,lower...
  • Page 4 Publication No. FEF316A 5995357679 BODY 08/01...
  • Page 5 A = FEF316A (FEF316ASA) B = FEF316A (FEF316AQA) POS. NO 14 # 62 # 66 # 67 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FEF316A BODY PART NO DESCRIPTION 316201300 Back,main 316230102 Panel,bodyside ,white ,RH...
  • Page 6 Publication No. FEF316A 5995357679 TOP/DRAWER 08/01...
  • Page 7 A = FEF316A (FEF316ASA) B = FEF316A (FEF316AQA) POS. NO 15 # 15A# 19 # 19A# 27 # # = Fast-moving Parts * = Non-Illustrated Parts FEF316A TOP/DRAWER PART NO DESCRIPTION 316011503 Drawer 316231500 Liner,drawer 316231305 Panel,drawer ,white 316231309 Panel,drawer ,bisque...
  • Page 8 Publication No. FEF316A 5995357679 DOOR 08/01...
  • Page 9 A = FEF316A (FEF316ASA) B = FEF316A (FEF316AQA) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FEF316A DOOR PART NO DESCRIPTION 316050300 Glass,oven door ,white ,outer 316050306 Glass,oven door ,bisque ,outer 316222709 Shield,oven door ,wool 316076401 Insulation,oven door...

  • Page 10: Wiring Diagram

    Publication No. FEF316A 5995357679 WIRING DIAGRAM 08/01...
