PRODUCT NO.
BASE MODEL NO.
FEF314BUA
FEF314B
FEF314BWA
FEF314B
SERVICE DATA SHEET - # 316218501
WIRING DIAGRAM - #316255102
OWNER'S GUIDE - # 316257101
INSTALLATION INSTRUCTIONS -# 316259200
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
COLOR
MARKET
black/bisque
North America
black/white
North America
Publication No.
5995384004
030113
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
ELECTRIC
RANGE
Model No.
FEF314B
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FEF314B
Summary of Contents for Frigidaire FEF314B
- Page 1 PRODUCT NO. BASE MODEL NO. FEF314BUA FEF314B FEF314BWA FEF314B SERVICE DATA SHEET - # 316218501 WIRING DIAGRAM - #316255102 OWNER’S GUIDE - # 316257101 INSTALLATION INSTRUCTIONS -# 316259200 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917 COLOR MARKET...
- Page 2 Publication No. FEF314B 5995384004 BACKGUARD 01/03...
- Page 3 A = FEF314B (FEF314BWA) B = FEF314B (FEF314BUA) POS. NO 12 # 24 # 54 # 54A# # = Fast-moving Parts * = Non-Illustrated Parts FEF314B BACKGUARD PART NO DESCRIPTION 316032409 Thermostat 316022503 Light/Lamp,indicator ,surface ,250 V 316263402 End Cap,black ,RH...
- Page 4 Publication No. FEF314B 5995384004 BODY 01/03...
- Page 5 A = FEF314B (FEF314BWA) B = FEF314B (FEF314BUA) POS. NO 62 # 66 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FEF314B BODY PART NO DESCRIPTION 316080805 Panel,main back ,dipped ,black ,short 316230114 Panel,bodyside ,white ,RH...
- Page 6 Publication No. FEF314B 5995384004 TOP/DRAWER 01/03...
- Page 7 A = FEF314B (FEF314BWA) B = FEF314B (FEF314BUA) POS. NO 15 # 15A# 27 # # = Fast-moving Parts * = Non-Illustrated Parts FEF314B TOP/DRAWER PART NO DESCRIPTION 316011503 Drawer 316231400 Liner,drawer 316231205 Panel,drawer ,white 316231209 Panel,drawer ,bisque 3051163 Glide,drawer ,rear 3051450 Element,surface ,8"...
- Page 8 Publication No. FEF314B 5995384004 DOOR 01/03...
- Page 9 A = FEF314B (FEF314BWA) B = FEF314B (FEF314BUA) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FEF314B DOOR PART NO DESCRIPTION 316050307 Glass,oven door ,white ,outer 316222709 Shield,oven door ,wool 316236801 Insulation,oven door 316088600 Glass,oven door ,inner 316230604...
-
Page 10: Wiring Schematic
Publication No. FEF314B 5995384004 WIRING SCHEMATIC 01/03... -
Page 11: Wiring Diagram
FEF314B Publication No. 5995384004 WIRING DIAGRAM # = Fast-moving Parts 01/03 * = Non-Illustrated Parts...
