PRODUCT NO.
BASE MODEL NO.
FEF312BSA
FEF312B
WIRING DIAGRAM - #316255169
OWNER'S GUIDE - # 316257101
INSTALLATION INSTRUCTIONS -# 316259200
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
COLOR
MARKET
white
North America
Publication No.
5995384962
030130
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
ELECTRIC
RANGE
Model No.
FEF312B
©2003 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FEF312B
Summary of Contents for Frigidaire FEF312B
- Page 1 PRODUCT NO. BASE MODEL NO. FEF312BSA FEF312B WIRING DIAGRAM - #316255169 OWNER’S GUIDE - # 316257101 INSTALLATION INSTRUCTIONS -# 316259200 ELECTROLUX HOME PRODUCTS, INC. P.O. Box 212378, Augusta, GA 30917 COLOR MARKET white North America Publication No. 5995384962 030130 -EN/SERVICE /ECL ©2003 Electrolux Home Products, Inc.
- Page 2 Publication No. FEF312BSA 5995384962 BACKGUARD 01/03...
- Page 3 POS. NO 12 # 54 # 54A# # = Fast-moving Parts * = Non-Illustrated Parts FEF312BSA BACKGUARD PART NO DESCRIPTION 5303289640 Shield,backguard ,rear wall 316032403 Thermostat 316022503 Light/Lamp,indicator ,surface ,250 V 316263404 End Cap,white ,RH 316263405 End Cap,white ,LH 316263304 Panel,backguard ,white 316223000 Knob,control ,white...
- Page 4 Publication No. FEF312BSA 5995384962 BODY 01/03...
- Page 5 POS. NO 12 # 62 # 66 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FEF312BSA BODY PART NO DESCRIPTION 316201300 Back,main 316230114 Panel,bodyside ,white ,RH 316230115 Panel,bodyside ,white ,LH 316021131 Screw,bodyside ,8-18 X 11/16 ,white 316201401 Burner Box 316129200...
- Page 6 Publication No. FEF312BSA 5995384962 TOP/DRAWER 01/03...
- Page 7 POS. NO 15 # 15A# 19 # 19A# 27 # # = Fast-moving Parts * = Non-Illustrated Parts FEF312BSA TOP/DRAWER PART NO DESCRIPTION 316011503 Drawer 316231500 Liner,drawer 316231305 Panel,drawer ,white 3051163 Glide,drawer ,rear 3051450 Element,surface ,8" large 3051449 Element,surface ,6" small 316245402 Main Top,white 316066900...
- Page 8 Publication No. FEF312BSA 5995384962 DOOR 01/03...
- Page 9 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FEF312BSA DOOR PART NO DESCRIPTION 316222705 Shield,wool ,oven door 316236801 Insulation,oven door 316230603 Liner,oven door 316001009 Screw,waf hd sq ,10-24 x 1.88 ,(2) ,handle mtg 316008401 Washer,3/4 OD x 1/4 ID ,steel 316239700 Seal,oven door 316202603...
-
Page 10: Wiring Schematic
Publication No. FEF312BSA 5995384962 WIRING SCHEMATIC 01/03... -
Page 11: Wiring Diagram
FEF312BSA Publication No. 5995384962 WIRING DIAGRAM # = Fast-moving Parts 01/03 * = Non-Illustrated Parts...
