Frigidaire FEF314A Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Ranges
  5. FEF314A
  6. Factory parts catalog
Frigidaire FEF314A Factory Parts Catalog

Frigidaire FEF314A Factory Parts Catalog

Electric
Hide thumbs

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FEF314AUA
FEF314A
FEF314AWA
FEF314A
SERVICE DATA SHEET - # 316259157
WIRING DIAGRAM - #316255102
OWNER'S GUIDE - # 316257101
INSTALLATION INSTRUCTIONS -# 316259200
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
COLOR
MARKET
black/bisque
North America
black/white
North America
Publication No.
5995358248
010828
-EN/SERVICE /ECL
369
FACTORY
PARTS CATALO
ELECTRIC
RANGE
Model No.
FEF314A
©2001 White Consolidated Industries, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FEF314A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FEF314A

Summary of Contents for Frigidaire FEF314A

  • Page 1 PRODUCT NO. BASE MODEL NO. FEF314AUA FEF314A FEF314AWA FEF314A SERVICE DATA SHEET - # 316259157 WIRING DIAGRAM - #316255102 OWNER’S GUIDE - # 316257101 INSTALLATION INSTRUCTIONS -# 316259200 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O. Box 212378, Augusta, GA 30917 COLOR...
  • Page 2 Publication No. FEF314A 5995358248 BACKGUARD 08/01...
  • Page 3 A = FEF314A (FEF314AWA) B = FEF314A (FEF314AUA) POS. NO 12 # 24 # 54 # 54A# # = Fast-moving Parts * = Non-Illustrated Parts FEF314A BACKGUARD PART NO DESCRIPTION 316133504 Trim,splasher ,white ,lower 316133510 Trim,splasher ,bisque ,lower 316057002 Trim,wrapper ,black...
  • Page 4 Publication No. FEF314A 5995358248 BODY 08/01...
  • Page 5 A = FEF314A (FEF314AWA) B = FEF314A (FEF314AUA) POS. NO 14 # 62 # 66 # 67 # 170* 170* 170* # = Fast-moving Parts * = Non-Illustrated Parts FEF314A BODY PART NO DESCRIPTION 316080805 Panel,main back ,dipped ,black ,short...
  • Page 6 Publication No. FEF314A 5995358248 TOP/DRAWER 08/01...
  • Page 7 A = FEF314A (FEF314AWA) B = FEF314A (FEF314AUA) POS. NO 15 # 15A# 19 # 19A# 27 # # = Fast-moving Parts * = Non-Illustrated Parts FEF314A TOP/DRAWER PART NO DESCRIPTION 316011503 Drawer 316231400 Liner,drawer 316231205 Panel,drawer ,white 316231209 Panel,drawer ,bisque...
  • Page 8 Publication No. FEF314A 5995358248 DOOR 08/01...
  • Page 9 A = FEF314A (FEF314AWA) B = FEF314A (FEF314AUA) POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FEF314A DOOR PART NO DESCRIPTION 316050300 Glass,oven door ,white ,outer 316050306 Glass,oven door ,bisque ,outer 316222709 Shield,oven door ,wool 316076401 Insulation,oven door...

  • Page 10: Wiring Diagram

    Publication No. FEF314A 5995358248 WIRING DIAGRAM 08/01...
