  • Page 1 Advanced Networking Appendices Product Manual v2.1 For RF Module Part Numbers: XC09-009… XC09-038… Low Power, Low Cost OEM RF Modules by MaxStream, Inc. MaxStream 355 South 520 West, Suite 180 Lindon, UT 84042 Phone: (801) 765-9885 Fax: (801) 765-9895 rf-xperts@maxstream.net M100043 www.MaxStream.net (live chat support)
  • Page 2 9XCite™ OEM RF Module ‐ Product Manual v2.1 [2007.01.04] © 2007 MaxStream, Inc. All rights reserved No part of the contents of this manual may be transmitted or reproduced in any  form or by any means without the written permission of MaxStream, Inc. XCite™ is a trademark of MaxStream, Inc. Technical Support:  Phone: (801) 765‐9885 Live Chat: www.maxstream.net E‐mail: rf‐xperts@maxstream.net © 2007 MaxStream, Inc.      ii...

  • Page 3: Table Of Contents

    2. RF Module Operation 1-Year Warranty 35 2.1. Serial Communications 8 Ordering Information 35 2.1.1. UART-Interfaced Data Flow 8 Contact MaxStream 36 2.1.2. RS-232 and RS-485/422 Data Flow 8 2.1.3. Serial Data 9 2.2. Modes of Operation 10 2.2.1. Idle Mode 10 2.2.2.

  • Page 4: Xcite Oem Rf Module

    Free & Unlimited Technical Support 1.1.1. Worldwide Acceptance FCC Certified (USA) [Refer to Appendix A for FCC Requirements] Systems that contain XCite Modems inherit MaxStream's FCC Certification IC (Industry Canada) Certified ISM (Industrial, Scientific & Medical) license-free 902-928 MHz frequency band Manufactured under ISO 9001:2000 registered standards © 2007 MaxStream, Inc.

  • Page 5: Specifications

    Commercial (0 to 70º C) or Industrial (-40 to 85º C) Antenna Connector (optional) RPSMA (Reverse-polarity SMA) Type ¼ Wave Monopole, 3" (7.62 cm) integrated wire, 1.9 dBi Impedance 50 ohms unbalanced Certifications (partial list) FCC Part 15.247 OUR-9XCITE Industry Canada (IC) 4214A-9XCITE 1.3. Mechanical Drawings Figure 1‐01. Mechanical Drawings (measured in inches) © 2007 MaxStream, Inc.      5...

  • Page 6: Block Diagram

    9XCite™ OEM RF Module – Product Manual v2.1 [2007.01.04] 1.4. Block Diagram Figure 1‐02. XCite OEM RF Module Block Diagram MaxStream's proprietary XII™ (Interference Immunity Technology) is contained in the 'Interfer- ence Filter' of the block diagram. The filter blocks interference from pagers and cellular. 1.5. Pin Signals XCite Module pin signals and their functions: Table 1‐02.

  • Page 7: Electrical Characteristics

    Input Leakage Vcc = 5.5V, pin high (absolute µA Current I/O Pin value) CTS, DO, RESET (Vcc – VI) / 10 ** CONFIG (Vcc – VI) / 47 ** (Vcc – VI) / 10 ** * Reset pulse must last at least 250 nanoseconds ** VI = the input voltage on the pin © 2007 MaxStream, Inc.      7...

  • Page 8: Rf Module Operation

    XCite Module pins. The XCite Module then converts the data into FCC-approved RF data. Once transmitted, the RF data can be detected by receiving XCite Modules, checked for integrity and then sent to a receiving device. Figure 2‐02. Data Flow in RS‐232 and RS‐485/422 environments.  (Low‐asserted signals distinguished with a horizontal line over signal name.) © 2007 MaxStream, Inc.      8...

  • Page 9: Serial Data

    9XCite™ OEM RF Module – Product Manual v2.1 [2007.01.04] 2.1.3. Serial Data Data enters the MaxStream RF module through the DI Pin as an asynchronous serial signal. The signal should idle high when no data is being transmitted. The UART performs tasks (such as timing and parity checking) needed for communication. Serial communication consists of two UARTs which must be configured with compatible parameters (Baud rate, parity, start bits, stop bits, data bits) to have successful communication.

  • Page 10: Modes Of Operation

    After the channel is initialized, data in the DI buffer is grouped into packets (up to 64 bytes in each packet) and is transmitted. The modem continues to transmit data packets until the DI buffer is empty. Once transmission is finished, the modem returns to Idle Mode. This progression is shown below: Figure 2‐05. Transmission of data © 2007 MaxStream, Inc.      10...

  • Page 11: Receive Mode

    If serial data-to-transmit is stored in the DI buffer while the modem is giving precedence to Receive Mode, the data will be transmitted after the modem finishes receiving data and returns to Idle Mode. © 2007 MaxStream, Inc.      11...

  • Page 12: Sleep Modes

    Mode. The return into Idle Mode is triggered by the de-assertion of the Sleep pin or the arrival of a serial byte through Data In pin. The following table lists MaxStream's Sleep Mode configurations and the requirements needed to transition into and out of Sleep Mode: Table 2‐01.
  • Page 13 The cyclic interval time defined by the SM (Sleep Mode) command must be shorter than the interval time defined by LH (Wake-up Initializer Timer) command. Figure 2‐07. Correct Configuration (LH > SM):  The length of the wake‐up initializer exceeds the time interval of Cyclic Sleep. The receiver is  guaranteed to detect the wake‐up initializer and receive the accompanying payload data. © 2007 MaxStream, Inc.      13...

  • Page 14: Command Mode

    Timeout) Command, the module automatically returns to Idle Mode. [OR] Send ATCN (Exit Command Mode) Command. For an example of programming the RF module using AT Commands and descriptions of each config- urable parameter, refer to the "RF Module Configuration" chapter. © 2007 MaxStream, Inc.      14...

  • Page 15: Rf Module Configuration

    • 900 MHz, 38400 Baud, Single Channel mode XCite Modems can operate in both Single Channel and Hopping modes. Mode is selectable using the "Function Set" dropdown list of the "XCite Configuration" tab of the MaxStream-provided X- CTU Software. The XCite Module is shipped with a unique parameter set in its memory. Parameters within the set are organized under the following categories: AT Commands &...

  • Page 16: Configuration Software

    A shortcut for editing PC Setting values is available by clicking on any of the values. Installation Double-click the "setup_X-CTU.exe" file and follow prompts of the installation screens. This file is located in the 'software' folder of the MaxStream CD and also under the 'Downloads' section of the following web page: www.maxstream.net/support/downloads.php Setup To use the X-CTU software, a module assembly (An RF module mounted to an interface Board) must be connected to a serial port of a PC.

  • Page 17: Command Reference Tables

    [Read-only] Firmware Version. Read firmware version currently loaded on 0 – 0xFFFF Diagnostic radio modem. [Read-only] Write. Write parameters to radio modem’s non-volatile memory in order for changes to persist through next power-up (Special) or reset. © 2007 MaxStream, Inc.      17...
  • Page 18 Time before Sleep. Set time period of inactivity (no serial or RF data is sent or received) before activating Sleep Mode. 0x10 – 0xFFFF Sleep 0x64 Use with Cyclic Sleep and Serial Port Sleep [refer to SM [x 100 ms] (Low Power) (100d) Command] © 2007 MaxStream, Inc.      18...

  • Page 19: Automatic Dip Switch Configurations

    ATCD 2 (DO3 - RX LED = low) AT Commands sent: ATCS 3 (RS-485 or RS-422 Operation) If SW1 is OFF (down) ATCD 2 (DO3 - RX LED = low) Exit AT Command Mode Always AT Commands sent: ATCN (Exit AT Command Mode) © 2007 MaxStream, Inc.      19...

  • Page 20: Command Descriptions

    7 bits Setting 7 bits and Mark or Space parity (NB Parameter) will result in a setting of 7 bits and no 8 bits parity. Default Parameter Value: 1 Number of bytes returned: 1 © 2007 MaxStream, Inc.      20...
  • Page 21 Number of bytes returned: 1 CN (Exit AT Command Mode) Command <AT Command: AT Command Mode Options> CN Command allows users to explicitly exit AT Com- mand Mode and return the radio modem into Idle Mode. AT Command: CN © 2007 MaxStream, Inc.      21...
  • Page 22 AT Command: DT Parameter Range: 0 - 0xFFFF # of bytes returned: 2 Default Parameter Value: 0 Related Commands: ID (Modem ID), HP (Channel), MK (Address Mask) © 2007 MaxStream, Inc.      22...
  • Page 23 If Default Parameter Value: 0 channels used on different radio modems can be Number of bytes returned: 1 separated more they should be. This will provide for more isolation and less interference. © 2007 MaxStream, Inc.      23...
  • Page 24 ID (Modem VID) Parameter <Non-AT Settable Parameter: Networking> ID Parameter reads and edits the module's VID. VID is a MaxStream-specific acronym that stands for "Vendor Identification Number". RF modules can only communicate with other modems having the same VID. Parameter Range: 0 - 0x7FFF (above this range is Read-only)
  • Page 25 Figure 3‐02. Incorrect Configuration (LH < SM) The length of the wake-up initializer is shorter than the time interval of Cyclic Sleep. This configu- ration is vulnerable to the receiver waking and missing the wake-up initializer (and therefore also the accompanying payload data). © 2007 MaxStream, Inc.      25...
  • Page 26 However, RE Command will not write the default values to non-volatile mem- ory. Unless the WR (Write) Command is issued after the RE Command, the default settings will not be saved in the event of radio modem reset or power-down. AT Command: RE Related Command: WR (Write) © 2007 MaxStream, Inc.      26...
  • Page 27 SL (Serial Number Low) Command <AT Command: AT Command Options> SL Command reads and reports the RF module serial number low word. AT Command: SL Parameter Range: 0 - 0xFFFF [Read-only] # of bytes returned: 2 Related Command: SH (Serial Number High) © 2007 MaxStream, Inc.      27...
  • Page 28 <AT Command: (Special)> WR Command writes all configurable parameters to non-volatile mem- ory. Using WR Command saves parameters to the radio modem's persistent memory. (This means that the parameters remain in the radio modem's memory until explicitly overwritten by future uses of WR Command.) AT Command: WR © 2007 MaxStream, Inc.      28...

  • Page 29: Advanced Networking

    Only modems with matching VIDs can communicate with each other. VID addressing ensures that radio modems ignore transmissions and receptions of XCite Radio Modems having a different VID in the same vicinity. To request a unique VID, contact MaxStream to obtain the VID Request Form.

  • Page 30: Channel (Athp)

    Refer to the “Bit-wise AND Truth” table for the Pseudo 'C' Code that qualifies the Destination Addresses and address masks. The Pseudo Code uses the bit-wise "AND" operation, "&". This operation is performed bit by bit on each of the 16 bits in the TXDT, RXDT and RXMK parameters. © 2007 MaxStream, Inc.       30...
  • Page 31 Destination Address of the Receiver, or if it matches the Receiver Address Mask, the packet is accepted. Otherwise, the packet is discarded. Note:When performing this comparison, any "0" values in the Receiver Address Mask are treated as irrelevant and are ignored. © 2007 MaxStream, Inc.       31...

  • Page 32: Appendix A: Agency Certifications

    The XCite OEM RF Module complies with Part 15 of the FCC rules and regulations. Compliance with the labeling requirements, FCC notices and antenna usage guidelines is required. In order to operate under MaxStream’s FCC Certification, OEMs/integrators must comply with the following regulations: The OEM/integrator must ensure that the text provided with this device [Figure A-01] is placed on the outside of the final product and within the final product operation manual.

  • Page 33: Limited Modular Approval

    Section 15.203 (unique antenna connectors) and Section 15.247 (emissions). Fixed Base Station and Mobile Applications MaxStream RF Modules are pre-FCC approved for use in fixed base station and mobile applica- tions. When the antenna is mounted at least 20cm (8") from nearby persons, the application is considered a mobile application.

  • Page 34: Ic (Industry Canada) Certification

    900 MHz Radio Modems (including "Mag Mount", "Dome", "Multi-path" and "Panel" antennas). Because of the large number of approved antennas, MaxStream requests that you send specific information about an antenna you would like to use with the modem and MaxStream will evaluate whether the antenna is covered under our FCC filing.

  • Page 35: Appendix B: Additional Information

    1-year from the date of purchase. In the event of a product failure due to materials or workmanship, MaxStream will repair or replace the defec- tive product. For warranty service, return the defective product to MaxStream, shipping prepaid, for prompt repair or replacement.

  • Page 36: Contact Maxstream

    9XCite™ OEM RF Module – Product Manual v2.1 [2007.01.04] Contact MaxStream Free and unlimited technical support is included with every MaxStream Radio Modem sold. For the best in wireless data solutions and support, please use the following resources: Documentation: www.maxstream.net/support/downloads.php Technical Support: Phone. (866) 765-9885 toll-free U.S.A. & Canada (801) 765-9885 Worldwide Live Chat.

This manual is also suitable for:
